SIST EN 15816:2011

Polymer-modified bituminous thick coatings - Resistance to rain

This European Standard specifies a procedure for determining the resistance to rain of polymer modified bituminous thick coatings for waterproofing.

Kunststoffmodifizierte Bitumendickbeschichtungen - Beständigkeit gegen Regen

Diese Europäische Norm legt ein Verfahren zur Bestimmung der Beständigkeit gegen Regen von kunststoffmodifizierten Bitumendickbeschichtungen fest.

Revêtements bitumineux épais modifiés aux polymères pour imperméabilisation - Résistance à la pluie

La présente Norme européenne spécifie une méthode permettant de déterminer la résistance à la pluie des revêtements bitumineux épais modifiés aux polymères pour imperméabilisation.

Bitumenske debeloslojne prevleke za tesnjenje, modificirane s polimeri - Odpornost proti dežju

Ta evropski standard opredeljuje postopek za določanje odpornosti bitumenskih debeloslojnih prevlek za tesnjenje, modificiranih s polimeri, proti dežju, da se zagotovi hidroizolacija.

General Information

• Status: Published
• Publication Date: 10-May-2011
• ICS: 91.100.50 - Binders. Sealing materials
• Technical Committee: VLA - Water proofing
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 13-Apr-2011
• Due Date: 18-Jun-2011
• Completion Date: 11-May-2011
• Directive: 305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
• Directive: 89/106/EEC - Construction products
• Mandate: M/102 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on membranes
• Ref Project: EN 15816:2011 - Polymer-modified bituminous thick coatings for waterproofing - Resistance to rain

Overview

SIST EN 15816:2011 is a European Standard developed by CEN specifying a test procedure to determine the resistance to rain of polymer-modified bituminous thick coatings used for waterproofing. This standard ensures that bituminous coatings applied on buildings can withstand rain exposure, providing durability and protection for construction elements. The standard focuses on assessing the coating's behavior immediately after application to simulate real-world rain conditions on site.

Key Topics

• Scope: SIST EN 15816:2011 details a laboratory method to evaluate the rain resistance of thick, polymer-modified bituminous coatings for waterproofing purposes.
• Test Specimens: Coated concrete slabs (approx. 150 mm × 150 mm) with a layer thickness of about 3 mm ± 0.3 mm are prepared and conditioned before testing.
• Test Equipment:
  • Sprinkler system with a standard conical nozzle operating at 2 bar water pressure.
  • Specimen holder positioning the test surface at a 45° angle.
  • Stopwatch and water mains connection for controlled water flow.
• Test Procedure:
  • Specimens conditioned up to 8 hours at 23°C and 50% relative humidity.
  • Exposure to simulated rain for 15 minutes under controlled water flow and temperature.
  • Observation for discoloration or surface erosion during water runoff as indicators of coating degradation.
• Results Expression:
  • The shortest conditioning time for which two specimens show no degradation and no discoloration is recorded.
  • Maximum conditioning period capped at 8 hours.
• Test Report Requirements:
  • Reference to SIST EN 15816:2011.
  • Product identification and application details.
  • Description of test conditions and deviations.
  • Recorded test results.
  • Date of testing.

Applications

SIST EN 15816:2011 plays a critical role in quality assurance and product development for waterproofing materials, specifically:

• Construction Industry: Ensures that polymer-modified bituminous coatings provide effective protection against rain during the vital curing phase on-site.
• Waterproofing Manufacturers: Helps validate and differentiate products with superior rain resistance performance.
• Building Inspectors & Specifiers: Provides confidence in selecting coatings tested to withstand early rain exposure.
• Durability Assessments: Assists in lifecycle forecasting and maintenance planning of waterproofing systems on concrete structures.
• Regulatory Compliance: Supports adherence to European waterproofing standards and building codes relating to moisture protection.

By adhering to SIST EN 15816:2011, stakeholders can improve the reliability and lifespan of waterproofing coatings, reducing risks of water ingress and structural damage.

Related Standards

• FprEN 15814:2011 – Definitions and requirements for polymer-modified bituminous thick coatings for waterproofing.
• EN 206-1 – Concrete specification, performance, and production that applies to concrete substrates used in testing.
• ISO 228-1 – Specifies thread dimensions and tolerances for pipes used in test equipment setup.
• ISO 554 – Standard atmospheres for conditioning and testing materials.

Keywords

polymer-modified bituminous thick coatings, waterproofing, resistance to rain, SIST EN 15816:2011, European Standard, bituminous coatings, construction waterproofing, rain resistance test, waterproofing durability, concrete coatings, waterproof membrane testing, CEN standards, building protection, coating quality assurance, bitumen coatings testing.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Bitumenske debeloslojne prevleke za tesnjenje, modificirane s polimeri - Odpornost proti dežjuKunststoffmodifizierte Bitumendickbeschichtungen - Beständigkeit gegen RegenPolymer-modified bituminous thick coatings - Resistance to rain91.100.50Veziva. Tesnilni materialiBinders. Sealing materialsICS:Ta slovenski standard je istoveten z:EN 15816:2011SIST EN 15816:2011en,fr,de01-junij-2011SIST EN 15816:2011SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 15816
March 2011 ICS 91.100.50 English Version
Polymer-modified bituminous thick coatings for waterproofing - Resistance to rain
Revêtements bitumineux épais modifiés aux polymères pour imperméabilisation - Résistance à la pluie
Kunststoffmodifizierte Bitumendickbeschichtungen zur Bauwerksabdichtung - Widerstand gegen Regen This European Standard was approved by CEN on 13 February 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2011 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 15816:2011: ESIST EN 15816:2011
...
