ASTM E3022-18

Standard Practice for Measurement of Emission Characteristics and Requirements for LED UV-A Lamps Used in Fluorescent Penetrant and Magnetic Particle Testing

SIGNIFICANCE AND USE
4.1 UV-A lamps are used in fluorescent penetrant and magnetic particle examination processes to excite fluorophores (dyes or pigments) to maximize the contrast and detection of discontinuities. The fluorescent dyes/pigments absorb energy from the UV-A radiation and re-emit visible light when reverting to its ground state. This excitation energy conversion allows fluorescence to be observed by the human eye.
4.2 The emitted spectra of UV-A lamps can greatly affect the efficiency of dye/pigment fluorescent excitation.
4.3 Some high-intensity UV-A lamps can produce irradiance greater than 10 000 μW/cm2 at 15 in. (381 mm). All high-intensity UV-A light sources can cause fluorescent dye fade and increase exposure of the inspector’s unprotected eyes and skin to high levels of damaging radiation.
4.4 UV-A lamps can emit unwanted visible light and harmful UV radiation if not properly filtered. Visible light contamination above 400 nm can interfere with the inspection process and must be controlled to minimize reflected glare and maximize the contrast of the indication. UV-B and UV-C contamination must also be eliminated to prevent exposure to harmful radiation.
4.5 Pulse Width Modulation (PWM) and Pulse Firing (PF) of UV-A LED circuits are not permitted.
Note 1: The ability of existing UV-A radiometers and spectroradiometers to accurately measure the irradiance of pulse width modulated or pulsed fired LEDs and the effect of pulsed firing on indication detectability is not well understood.
SCOPE
1.1 This practice covers the procedures for testing the performance of ultraviolet A (UV-A), light emitting diode (LED) lamps used in fluorescent penetrant and fluorescent magnetic particle testing (see Guides E709 and E2297, and Practices E165/E165M, E1208, E1209, E1210, E1219, E1417/E1417M and E1444).2 This specification also includes reporting and performance requirements for UV-A LED lamps.
1.2 These tests are intended to be performed only by the manufacturer to certify performance of specific lamp models (housing, filter, diodes, electronic circuit design, optical elements, cooling system, and power supply combination) and also includes limited acceptance tests for individual lamps delivered to the user. This test procedure is not intended to be utilized by the end user.
1.3 This practice is only applicable for UV-A LED lamps used in the examination process. This practice is not applicable to mercury vapor, gas-discharge, arc or luminescent (fluorescent) lamps or light guides (for example, borescope light sources).
1.4 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
1.5 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.6 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Published
• Publication Date: 30-Jun-2018
• ICS: 19.100 - Non-destructive testing
• ICS: 29.140.01 - Lamps in general
• Technical Committee: E07 - Nondestructive Testing
• Drafting Committee: E07.03 - Liquid Penetrant and Magnetic Particle Methods

Relations

• Refers: ASTM E1316-24 - Standard Terminology for <?Pub Dtl?>Nondestructive Examinations
• Effective Date: 01-Feb-2024
• Refers: ASTM E1316-19b - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Dec-2019
• Refers: ASTM E1316-19 - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Mar-2019
• Refers: ASTM E1316-18 - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Jan-2018
• Refers: ASTM E1316-17a - Standard Terminology for Nondestructive Examinations
• Effective Date: 15-Jun-2017
• Refers: ASTM E1316-17 - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Feb-2017
• Refers: ASTM E1316-16a - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Aug-2016
• Refers: ASTM E1316-16 - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Feb-2016
• Refers: ASTM E1316-15a - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Dec-2015
• Refers: ASTM E1348-15 - Standard Test Method for Transmittance and Color by Spectrophotometry Using Hemispherical Geometry
• Effective Date: 01-Nov-2015
• Refers: ASTM E1316-15 - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Sep-2015
• Refers: ASTM E1316-14e1 - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Jun-2014
• Refers: ASTM E1316-14 - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Jun-2014
• Refers: ASTM E1316-13d - Standard Terminology for Nondestructive Examinations
• Effective Date: 01-Dec-2013
• Refers: ASTM E1316-13c - Standard Terminology for Nondestructive Examinations
• Effective Date: 15-Jun-2013

Overview

ASTM E3022-18 is the standard practice issued by ASTM International for the measurement of emission characteristics and requirements for LED UV-A lamps used in fluorescent penetrant and magnetic particle testing. These lamps play a crucial role in nondestructive testing (NDT) by providing ultraviolet A (UV-A) radiation to excite fluorescent dyes or pigments, enhancing contrast and the detection of surface discontinuities in materials.

This standard specifies methods for evaluating and certifying the performance of UV-A LED lamps, with detailed test procedures and requirements. It is intended for manufacturers to certify specific lamp models and includes guidance for the acceptance testing of individual lamps delivered to users. Importantly, this document is not applicable to mercury vapor, gas-discharge, arc, or luminescent lamps.

Key Topics

• Emission Characteristics: Defines test procedures for evaluating emission spectra, maximum irradiance, beam uniformity, and excitation irradiance in the 347-382 nm range, critical for optimal fluorescent excitation.
• Lamp Types: Covers line-powered and battery-powered hand-held and overhead LED lamps applicable exclusively to fluorescent penetrant and magnetic particle testing.
• Contamination Control: Emphasizes the need for proper filtering to eliminate unwanted visible light (>400 nm) and hazardous UV-B/UV-C emissions, which can interfere with inspection processes or pose health risks.
• Performance Testing: Outlines requirements for thermal stability, current ripple minimization (pulse width modulation and pulse firing are not permitted), beam irradiance profiles, and filter transmittance.
• Battery Performance: Specifies battery discharge testing for portable lamp models to ensure performance consistency throughout use.
• Safety and Certification: Requires conformance certification be provided with each lamp, including test results and confirmation that safety, health, and regulatory considerations have been addressed.
• Measurement and Calibration: Details equipment and calibration requirements for UV-A radiometers, spectroradiometers, and spectrophotometers used in lamp testing.

Applications

LED UV-A lamps tested to ASTM E3022-18 are essential in:

• Fluorescent Penetrant Inspection (FPI): Used extensively in the aerospace, automotive, and manufacturing industries for the detection of surface-breaking flaws and discontinuities in non-porous materials.
• Fluorescent Magnetic Particle Testing (FMT): Critical for inspecting ferromagnetic components, ensuring detection of cracks or defects.
• Quality Assurance: Standardization ensures lamps deliver reliable, repeatable UV-A emission characteristics needed for high-contrast inspection environments.
• Manufacturing and Maintenance: Enables manufacturers and maintenance providers to verify the suitability and safety of UV-A LED lamps that are integral to NDT operations.
• Compliance and Procurement: Provides a standardized basis for lamp procurement, ensuring products meet industry-recognized minimum performance requirements.

Related Standards

ASTM E3022-18 references and complements several other key standards in the nondestructive testing field:

• ASTM E165/E165M: Liquid Penetrant Examination for General Industry
• ASTM E709: Magnetic Particle Testing
• ASTM E2297: Guide for Use of UV-A and Visible Light Sources in Liquid Penetrant and Magnetic Particle Testing
• ASTM E1417/E1417M, E1208, E1209, E1210, E1219: Practices for various penetrant testing processes
• ASTM E1316: Terminology for Nondestructive Examinations
• ANSI/ISO/IEC 17025 and ANSI/NCSL Z540.3: Requirements for calibration and testing laboratory competence

Keywords: ASTM E3022-18, LED UV-A lamp, fluorescent penetrant testing, magnetic particle inspection, nondestructive testing, emission characteristics, UV-A radiometer, lamp certification, filter transmittance, quality assurance.
