ASTM F2952-22

Standard Guide for Determining the Mean Darcy Permeability Coefficient for a Porous Tissue Scaffold

SIGNIFICANCE AND USE
4.1 This document describes the basic principles that need to be followed to obtain a mean value of the Darcy permeability coefficient for structures that consist of a series of interconnected voids or pores. The coefficient is a measure of the permeability of the structure to fluid flowing through it that is driven by a pressure gradient created across it.
4.2 The technique is not sensitive to the presence of closed or blind-end pores (Fig. 1).
FIG. 1 Schematic of the Different Pores Types Found in Tissue Scaffolds. Fluid Flow Through the Structure is via the Open Pores
4.3 Values of the permeability coefficient can be used to compare the consistency of manufactured samples or to determine what the effect of changing one or more manufacturing settings has on permeability. They can also be used to assess the homogeneity and anisotropy of tissue scaffolds. Variability in the permeability coefficient can be also be indicative of:
4.3.1 Internal damage within the sample, for example, cracking or permanent deformation.
4.3.2 The presence of large voids, including trapped air bubbles, within the structure.
4.3.3 Surface effects such as a skin formed during manufacture.
4.3.4 Variable sample geometry.
4.4 This test method is based on the assumption that the flow rate through a given sample subjected to an applied pressure gradient is constant with time.
Note 1: If a steady-state flow condition isn’t reached, then this could be due to structural damage (that is, crack formation or the porous structure deformed as a result of the force being placed upon it by the fluid flowing through it). Sample deformation in the form of stretching (bowing) can also occur for less resilient structures as a result of high fluid flow rates. This topic is discussed in more detail in Section 7.
4.5 Care should be taken to ensure that hydrophobic materials are fully wetted out when using water or other aqueous-based liquids as permeants.
4.6 Conventionally, the p...
SCOPE
1.1 This guide describes test methods suitable for determining the mean Darcy permeability coefficient for a porous tissue scaffold, which is a measure of the rate at which a fluid, typically air or water, flows through it in response to an applied pressure gradient. This information can be used to optimize the structure of tissue scaffolds, to develop a consistent manufacturing process, and for quality assurance purposes.
1.2 The method is generally nondestructive and non-contaminating.
1.3 The method is not suitable for structures that are easily deformed or damaged. Some experimentation is usually required to assess the suitability of permeability testing for a particular material/structure and to optimize the experimental conditions.
1.4 Measures of permeability should not be considered as definitive metrics of the structure of porous tissue scaffolds and should complement measures obtained by other investigative techniques, for example, scanning electron microscopy, gas flow porometry, and micro-computer X-ray tomography (Guides F2450, F2603, and F3259).
1.5 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.6 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Published
• Publication Date: 31-Mar-2022
• ICS: 11.100.99 - Other standards related to laboratory medicine
• Technical Committee: F04 - Medical and Surgical Materials and Devices
• Drafting Committee: F04.42 - Biomaterials and Biomolecules for TEMPs

Relations

• Refers: ASTM F2603-06(2020) - Standard Guide for Interpreting Images of Polymeric Tissue Scaffolds
• Effective Date: 01-Aug-2020
• Refers: ASTM F2450-18 - Standard Guide for Assessing Microstructure of Polymeric Scaffolds for Use in Tissue-Engineered Medical Products
• Effective Date: 15-Nov-2018
• Refers: ASTM F3259-17 - Standard Guide for Micro-computed Tomography of Tissue Engineered Scaffolds
• Effective Date: 01-May-2017
• Refers: ASTM D737-04(2016) - Standard Test Method for Air Permeability of Textile Fabrics
• Effective Date: 01-Jul-2016
• Refers: ASTM F2603-06(2012) - Standard Guide for Interpreting Images of Polymeric Tissue Scaffolds
• Effective Date: 01-Oct-2012
• Refers: ASTM D737-04(2012) - Standard Test Method for Air Permeability of Textile Fabrics
• Effective Date: 01-Jul-2012
• Refers: ASTM F2450-10 - Standard Guide for Assessing Microstructure of Polymeric Scaffolds for Use in Tissue Engineered Medical Products
• Effective Date: 01-Mar-2010
• Refers: ASTM F2450-09 - Standard Guide for Assessing Microstructure of Polymeric Scaffolds for Use in Tissue Engineered Medical Products
• Effective Date: 01-Jun-2009
• Refers: ASTM D737-04(2008)e1 - Standard Test Method for Air Permeability of Textile Fabrics
• Effective Date: 01-Jul-2008
• Refers: ASTM D737-04(2008)e2 - Standard Test Method for Air Permeability of Textile Fabrics
• Effective Date: 01-Jul-2008
• Refers: ASTM F2603-06 - Standard Guide for Interpreting Images of Polymeric Tissue Scaffolds
• Effective Date: 01-Dec-2006
• Refers: ASTM D2434-68(2006) - Standard Test Method for Permeability of Granular Soils (Constant Head) (Withdrawn 2015)
• Effective Date: 01-Feb-2006
• Refers: ASTM D737-04 - Test Method for Air Permeability of Textile Fabrics
• Effective Date: 01-Dec-2004
• Refers: ASTM F2450-04 - Standard Guide for Assessing Microstructure of Polymeric Scaffolds for Use in Tissue Engineered Medical Products
• Effective Date: 01-Nov-2004
• Refers: ASTM D2434-68(2000) - Standard Test Method for Permeability of Granular Soils (Constant Head)
• Effective Date: 01-Jan-2000

Overview

ASTM F2952-22 is the standard guide for determining the mean Darcy permeability coefficient for porous tissue scaffolds. Developed by ASTM International, this guide outlines key test methods for measuring the permeability, or the rate at which a fluid (commonly air or water) flows through a porous scaffold in response to an applied pressure gradient. Understanding the permeability coefficient is vital for optimizing the design, manufacturing process, and quality assurance of tissue scaffolds used in biomedical applications. The method is generally nondestructive and non-contaminating, ensuring that sample integrity is maintained throughout testing.

Key Topics

• Darcy Permeability Coefficient: This measures the resistance of a scaffold material to fluid flow, governed by the structure’s interconnected open pores. Accurate measurement helps assess consistency and identify structural changes due to damage or manufacturing variations.
• Open vs. Closed Pores: The method assesses flow only through open (interconnected) pores, as closed or blind-end pores do not contribute to overall permeability.
• Sample Suitability: Not all samples are ideal - highly deformable or easily damaged scaffolds may not be suitable for permeability testing, and initial experimentation may be needed to ensure valid results.
• Complementary Techniques: Permeability measurements should not be the sole metric for scaffold assessment and are best used in conjunction with imaging (e.g., scanning electron microscopy, micro-CT) and porometry data to provide a complete structural profile.
• Experimental Considerations: Factors such as sample geometry, material hydrophobicity, mounting technique, and fluid selection (air or water) can all influence results and should be carefully controlled.
• Data Interpretation: Attention must be paid to possible hysteresis (differences during cycles of increasing and decreasing pressure) and deviations from ideal Darcy behavior to ensure valid, reproducible data.

Applications

• Tissue Engineering: Permeability coefficients inform scaffold design, particularly for tissues requiring efficient nutrient and waste exchange, such as in regenerative medicine and tissue-engineered medical products.
• Manufacturing Quality Control: By comparing permeability values, manufacturers can assess batch consistency, optimize processing parameters, and detect defects such as cracks, voids, or inconsistent porosity.
• Research & Development: Scientists use permeability data to evaluate new scaffold materials, study the effects of degradation over time, and tailor scaffolds for specific cell or tissue requirements.
• Failure Analysis: Variability in permeability may indicate internal damage, trapped air, or geometric inconsistencies, aiding in diagnostics and process improvement.

Related Standards

ASTM F2952-22 should be used alongside other relevant testing and characterization standards to ensure comprehensive evaluation of tissue scaffolds:

• ASTM F2450: Guide for assessing microstructure of polymeric scaffolds
• ASTM F2603: Guide for interpreting images of polymeric tissue scaffolds
• ASTM F3259: Guide for micro-computed tomography of tissue engineered scaffolds
• ASTM F3510: Guide for characterizing fiber-based constructs for tissue-engineered medical products
• ASTM D2434: Test methods for measurement of hydraulic conductivity of coarse-grained soils
• API RP-27: Recommended practice for determining permeability of porous media

Conclusion

ASTM F2952-22 provides a standardized approach for measuring the mean Darcy permeability coefficient in porous tissue scaffolds, supporting biomedical product development, process optimization, and quality assurance. By following this guide and considering complementary analytical techniques, stakeholders can ensure reliable measurement and interpretation of scaffold permeability, leading to improved performance in tissue engineering and related fields.

Keywords: ASTM F2952-22, Darcy permeability coefficient, tissue scaffold permeability, porous materials, quality control, tissue engineering scaffolds, permeability test method, scaffold characterization.
