EN ISO 3188:1994

Starches and derived products - Determination of nitrogen content by the Kjeldahl method - Titrimetric method (ISO 3188:1978)

The found value only includes free amino acids, compounds producing amino acids on hydrolysis and ammonium compounds. The principle consists in destruction of organic matter by sulphuric acid in the presence of a compound catalyst (see ISO 1871), alkalization of the reaction products, distillation of the liberated ammonia and collection in a boric acid solution, followed by titration with a standard volumetric sulphuric acid solution. The method applies to contents greater than 0,01 % (m/m). For products with contents less than 0,025 % (m/m), see ISO 5378.

Stärken und Stärkederivate - Bestimmung des Stickstoffgehaltes nach dem Kjeldahl-Verfahren - Volumetrisches Verfahren (ISO 3188:1978)

Diese Internationale Norm legt ein volumetrisches Verfahren zur Bestimmung des Stickstoffgehalts nach dem Kjeldahl-Verfahren fest. Das Verfahren ist bei Stärke und Stärkederivaten anwendbar, deren Stickstoffgehalt voraussichtlich mehr als 0,01% beträgt.

Amidons, fécules et produits dérivés - Dosage de l'azote selon la méthode de Kjeldahl - Méthode titrimétrique (ISO 3188:1978)

La présente Norme internationale spécifie une méthode titrimétrique de dosage de l'azote selon la méthode de Kjeldahl, dans les amidons, fécules et leurs produits dérivés, dont la teneur présumée en azote est supérieure à 0,01 % (m/m).1)
NOTE - Dans les amidons, fécules et dérivés n'ayant pas reçu d'adjonctions azotées, l'azote est présent essentiellement sous forme de protides et/ou d'amino-acides.

Škrobi in škrobni derivati - Določevanje dušika po Kjeldahlovi metodi - Titrimetrijska metoda (ISO 3188:1978)

General Information

• Status: Published
• Publication Date: 24-Aug-1994
• Withdrawal Date: 27-Feb-1995
• ICS: 67.180.20 - Starch and derived products
• Technical Committee: CEN/SS C10 - Starch
• Drafting Committee: CEN/SS C10 - Starch
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 13-Oct-1999
• Completion Date: 13-Oct-1999
• Ref Project: SIST EN ISO 3188:1998 - Starches and derived products - Determination of nitrogen content by the Kjeldahl method - Titrimetric method (ISO 3188:1978)

Standards Content (Sample)

SLOVENSKI STANDARD
SIST EN ISO 3188:1998
01-november-1998
âNURELLQãNUREQLGHULYDWL'RORþHYDQMHGXãLNDSR.MHOGDKORYLPHWRGL
7LWULPHWULMVNDPHWRGD,62
Starches and derived products - Determination of nitrogen content by the Kjeldahl
method - Titrimetric method (ISO 3188:1978)
Stärken und Stärkederivate - Bestimmung des Stickstoffgehaltes nach dem Kjeldahl-
Verfahren - Volumetrisches Verfahren (ISO 3188:1978)
Amidons, fécules et produits dérivés - Dosage de l'azote selon la méthode de Kjeldahl -
Méthode titrimétrique (ISO 3188:1978)
Ta slovenski standard je istoveten z: EN ISO 3188:1994
ICS:
67.180.20 Škrob in izdelki iz njega Starch and derived products
SIST EN ISO 3188:1998 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------

SIST EN ISO 3188:1998

---------------------- Page: 2 ----------------------

SIST EN ISO 3188:1998

---------------------- Page: 3 ----------------------

SIST EN ISO 3188:1998

---------------------- Page: 4 ----------------------

SIST EN ISO 3188:1998
INTERNATIONAL STANDARD
INTERNATIONAL ORGANIZATION FOR STANDARDIZATIONWlEIKJjYHAPO,QHAR OPrAHM3AL&lR fl0 CTAH~APTM3AL&WWORGANISATION INTERNATIONALE DE NORMALISATION
Starches and derived products - Determination of nitrogen
content by the Kjeldahl method - Titrimetric method
Amidons, fdcules et produits d&iv& - Dosage de l’azote selon Ia methode de Kjeldahl - Mt!thode titrimetrique
First edition - 1978-08-15
Ei
-
UDC 664.2 : 546.17 : 543.24
Ref. No. ISO 3188-1978 (E)
Descriptors : starches, Chemical analysis, determination of content, nitrogen, volumetric analysis, Kjeldahl method.
Price based on 3 pages

---------------------- Page: 5 ----------------------

SIST EN ISO 3188:1998
FOREWORB
ISO (the International Organization for Standardization) is a worldwide federation
of national Standards institutes (ISO member bodies). The work of deweloping
International Standards is carried out through ISO technical committees. Ewery
member body interested in a subject for which a technical committee has been set
up has the right to be represented on that committee. International organizations,
governmental and non-governmental, in liaison with ISO, also take part in the work.
Draft International Standards adopted by the technical committees are circulated
to the member bodies for approval before their acceptance as International
Standards by the ISO Council.
International Standard ISO 3188 was developed by Technicai Committee
ISO/TC 93, Starch (including derivatives and by-products), and was circulated
to the member bodies in August 1975.
lt has been approved by the member bodies of the following countries :
Australia 1 ran Thailand
Czechoslovakia Netherlands Turkey
France Poland United Kingdom
Germany Romania Yugoslavia
Hungary South Africa, Rep. of
The member body of the following country expressed d isapprova I of the docume nt
on technical grounds :
U.S.A.
@ International Organisation for Standard ization, 9 978 l
Printed in Switzerland

---------------------- Page: 6 ----------------------

SIST EN ISO 3188:1998
ISO 31884978 (E)
INTERNATIONAL STANDARD
Starches and derived products - Determination of nitrogen
content by the Kjeldahl method - Titrimetric method
5 REAGENTS
1 SCOPE AND FIELD OF APPLICATION
The reagents shall be of recognized analytical quality.
This International Standard specifies a titrimetric method
Ammonia-free distilled water or water of at least equivalent
for the determination, by the Kjeldahl method, of the
purity shall be used.
nitrogen content of starch and its derived products whose
presumed nitrogen content is greater than 0,Ol % (mlm)? )
5.1 Sulphuric acid, concentrated, p20 1,84 g/ml [96 %
NOTE - In starches and derived products to which nitrogenous
(mhd].
materials have not been added, the nitrogen is present essentially
in the form of Protein and/or amino acids.
5.2 Sodium hydroxide, solution 30 % (mlm), p20
1,33 g/ml.
2 REFERENCES
NOTE - This Solution may be more concentrated.
ISO 1227fAdd. 2, Starch, including derivatives and by-
products - Vocabulary.
5.3 Boric acid, 20 g/ solution.3)
ISO 1871, Agricultural food products - General directions
for the determination of nitrogen by the Kjeldahlmethod.
5.4 Compound catalyst4), consisting of, for example :
ISO 5378, Starches and derived products - Determination
- potassium sulphate : 97 g;
of nitrogen content by the Kjeldahl method - Spectro-
- copper( II) sulphate, anhydrous : 3 g.
pho tome tric me thod,
5.5 Sulphuric acid,
approximately 0,02 N or 0,l N
-
3 DEFINITION
Standard volumetric Solution,
nitrogen content : The value found using the procedure
5.6 Colorimetric indicator, prepared by mixing 2 Parts
specified. lt includes the nitrogen content of free amino
by volume of a cold saturated Solution of neutral methyl
acids, of compo
...
