EN 2306:2017

Aerospace series - Heat resisting - Nickel base alloy Ni-Cr20Co3Fe3 - Annealed - Bars

This standard specifies the requirements relating to:
This European Standard specifies the requirements relating to:
Heat resisting
Nickel base alloy Ni-Cr20Co3Fe3
Annealed
Bars
for aerospace applications.

Luft- und Raumfahrt - Hochwarmfeste Nickelbasislegierung Ni-Cr20Co3Fe3 - Geglüht - Stangen

Série aérospatiale - Alliage résistant à chaud à base de nickel Ni-Cr20Co3Fe3 - Recuit - Barres

Aeronavtika - Toplotno odporna - Zlitina na nikljevi osnovi Ni-Cr20Co3Fe3 - Žarjena - Palice

Ta standard določa zahteve glede:
Ta evropski standard določa zahteve za:
Toplotno odporna
zlitina na nikljevi osnovi Ni-Cr20Co3Fe3
Žarjene
palice
za uporabo v aeronavtiki.

General Information

• Status: Published
• Publication Date: 24-Oct-2017
• Withdrawal Date: 29-Apr-2018
• ICS: 49.025.15 - Non-ferrous alloys in general
• Technical Committee: ASD-STAN - Aerospace
• Drafting Committee: ASD-STAN/D 4/S 3 - Steels & Heat Resisting Alloys
• Current Stage: 6060 - Definitive text made available (DAV) - Publishing
• Start Date: 25-Oct-2017
• Completion Date: 25-Oct-2017
• Ref Project: SIST EN 2306:2018 - Aerospace series - Heat resisting - Nickel base alloy Ni-Cr20Co3Fe3 - Annealed - Bars

Overview

EN 2306:2017 is a CEN (ASD‑STAN) aerospace material standard that defines the requirements for heat‑resisting, nickel‑base alloy bars designated Ni‑Cr20Co3Fe3, supplied in the annealed condition for aerospace applications. It specifies composition control, permitted production and melting routes, delivery condition, heat treatment guidance and links to dimensional and inspection requirements used when supplying bars for machining or forging into high‑temperature aerospace parts.

Key topics and technical requirements

• Material designation: Nickel‑base alloy Ni‑Cr20Co3Fe3 (nominally ~20% Cr, ~3% Co, ~3% Fe with nickel balance).
• Chemical composition: The standard sets composition limits and control for alloying elements and impurities (carbon, silicon, manganese, sulfur, copper, lead, titanium, etc.). Exact ranges and analysis methods are defined in the document and agreed between manufacturer and purchaser where needed.
• Melting and refining methods: Permitted melting routes include air‑melting, vacuum melting or air melting with vacuum refining, and consumable electrode remelting; the method is to be agreed between supplier and purchaser.
• Form and production: Covers bars intended for machining and for forging; dimensional ranges refer to EN 2344 (e.g., typical round bar diameters).
• Delivery condition and heat treatment: Bars are supplied annealed (machined or descaled). The standard provides heat‑treatment conditions (reference anneal around 1 000 °C with air cooling) and guidance on soaking time relative to section thickness.
• Technical specification & inspection: Technical delivery requirements follow EN 4700‑002 and EN 2344. Test, inspection, marking, dimensional checks and product‑qualification provisions are included; specific qualification programs are agreed between manufacturer and purchaser.

Applications and who uses it

• Primary uses: Specification for bar stock used as feedstock for machining or forging into heat‑resistant aerospace components (e.g., hot‑section parts, structural elements exposed to elevated temperatures).
• Users who rely on EN 2306:2017:
  • Aerospace materials engineers and designers selecting high‑temperature alloys
  • Procurement and supply chain professionals specifying raw material for aerospace manufacture
  • Manufacturers of bars, forgings and machined components
  • Quality, inspection and certification teams ensuring compliance with CEN aerospace material standards

Related standards

• EN 2344 - Round bars, machined in heat resisting alloys (diameters)
• EN 4700‑002 - Technical specification for bars and sections (steel and heat‑resisting alloys)
• EN 4258 - Organization of aerospace metallic material standards
• EN 4500‑003 - Rules for drafting heat‑resisting alloy material standards

Keywords: EN 2306:2017, Ni‑Cr20Co3Fe3, nickel base alloy, heat resisting, annealed bars, aerospace material standard, CEN, material specification.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Aeronavtika - Toplotno odporna - Zlitina na nikljevi osnovi Ni-Cr20Co3Fe3 - Žarjena - PaliceLuft- und Raumfahrt - Hochwarmfeste Nickelbasislegierung Ni-Cr20Co3Fe3 - Geglüht - StangenSérie aérospatiale - Alliage résistant à chaud à base de Ni-Cr20Co3Fe3 - Recuit - BarresAerospace series - Heat resisting - Nickel base alloy Ni-Cr20Co3Fe3 - Annealed - Bars49.025.15Neželezove zlitine na splošnoNon-ferrous alloys in generalICS:Ta slovenski standard je istoveten z:EN 2306:2017SIST EN 2306:2018en,fr,de01-februar-2018SIST EN 2306:2018SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 2306
October
t r s y ICS
v {ä r t wä s w English Version
Aerospace series æ Heat resisting æ Nickel base alloy NiæCr t rCo uFe u æ Annealed æ Bars Série aérospatiale æ Alliage résistant à chaud à base de nickel NiæCr t rCo uFe u æ Recuit æ Barres
Luftæ und Raumfahrt æ Hochwarmfeste Nickelbasislegierung NiæCr t rCo uFe u æ Geglüht æ Stangen This European Standard was approved by CEN on
s v May
t r s yä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Serbiaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Avenue Marnix 17,
B-1000 Brussels
t r s y CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
t u r xã t r s y ESIST EN 2306:2018
...
