CEN/TS 1993-1-101:2022

(Main)

Eurocode 3: Design of steel structures - Part 1-101: Alternative interaction method for members in bending and compression

Eurocode 3: Design of steel structures - Part 1-101: Alternative interaction method for members in bending and compression

(1) This document provides an alternative method for the stability verification of steel members under compression axial force and bending moment, with reference to EN 1993 1 1.
NOTE   For the applicability of this document, see Clause 4.
(2) The method given in this document applies to uniform steel members with double symmetric cross-section under axial compression force and bi-axial bending.

Eurocode 3: Bemessung und Konstruktion von Stahlbauten - Teil 1-101: Alternative Interaktionsmethode für Bauteile unter Druck und Biegung

(1) Dieses Dokument enthält ein alternatives Nachweisverfahren für die Stabilität von Stahlbauteilen unter Drucknormalkraft und Biegemoment mit Bezug auf EN 1993 1 1.
ANMERKUNG   Bezüglich der Anwendbarkeit dieses Dokuments siehe Abschnitt 4.
(2) Das Verfahren in diesem Dokument ist für gleichförmige Stahlbauteile mit doppelt-symmetrischen Querschnitten unter Drucknormalkraft und zweiachsiger Biegung anwendbar.

Eurocode 3: Calcul des structures en acier - Partie 1 101: Méthode de calcul pour la stabilité des barres en acier sollicitées en compression et flexion bi-axiale

(1) Ce document fournit une méthode pour la vérification de la stabilité des barres en acier sous effort axial de compression et moment fléchissant, en se référant à l’EN 1993 1 1.
NOTE   Pour l’applicabilité de ce document, voir le Paragraphe 4.
(2) La méthode donnée dans ce document s’applique à des barres uniformes avec section transversale doublement symétrique, soumis à un effort axial de compression et à de la flexion bi-axiale.

Evrokod 3: Projektiranje jeklenih konstrukcij - 1-101. del: Alternativna interakcijska metoda za upogibno in tlačno obremenjene elemente

(1) Ta dokument zagotavlja alternativno metodo za preverjanje stabilnosti jeklenih elementov pod kompresijsko osno silo in upogibnim momentom, s sklicevanjem na standard EN 1993-1-1.
OPOMBA:   Za uporabo tega dokumenta glej točko 4.
(2) Metoda, podana v tem dokumentu, se uporablja za enakomerne jeklene elemente z dvojnim simetričnim prečnim prerezom pod aksialno kompresijsko silo in dvoosnim upogibom.

General Information

Status
Published
Publication Date
08-Nov-2022
ICS
91.010.30 - Technical aspects
91.080.13 - Steel structures
Technical Committee
CEN/TC 250 - Structural Eurocodes
Drafting Committee
CEN/TC 250/SC 3/WG 1 - Evolution of EN 1993-1-1 - General rules for buildings
Current Stage
6060 - Definitive text made available (DAV) - Publishing
Start Date
09-Nov-2022
Due Date
13-Mar-2023
Completion Date
09-Nov-2022
Directive
305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
Mandate
M/515 - Mandate for amending existing Eurocodes and extending the scope of structural Eurocodes
Ref Project
SIST-TS CEN/TS 1993-1-101:2023 - Eurocode 3: Design of steel structures - Part 1-101: Alternative interaction method for members in bending and compression

Buy Standard

TS CEN/TS 1993-1-101:2023TS CEN/TS 1993-1-101:2023
PreviousNext
Technical specification
TS CEN/TS 1993-1-101:2023
English language
9 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day
TS CEN/TS 1993-1-101:2023TS CEN/TS 1993-1-101:2023
PreviousNext
Technical specification
TS CEN/TS 1993-1-101:2023
English language
9 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day
