EN 16713-2:2016

Domestic swimming pools - Water systems - Part 2: Circulation systems - Requirements and test methods

This European Standard specifies requirements and test methods for circulation systems and is applicable to equipment used in domestic swimming pools and designed for the circulation of water (introduction and/or extraction).
This standard applies for swimming pools as defined in EN 16582-1 and will be read in conjunction with it.
This standard does not apply to:
-   pools for public use covered by EN 15288-1;
-   spas for domestic or public use;
-   paddling pools according to EN 71-8;
-   pre filtration;
-   natural and nature like pools.
NOTE   For filtration systems see prEN 16713-1 and for treatment systems prEN 16713-3.

Schwimmbäder für private Nutzung - Wassersysteme - Teil 2: Umwälzsysteme - Anforderungen und Prüfverfahren

Diese Europäische Norm legt die Anforderungen und Prüfverfahren für Umwälzsysteme fest und gilt für Anlagen, die in privaten Schwimmbädern verwendet werden und der Zirkulation von Wasser dienen (Einlauf und/oder Ablauf).
Diese Norm gilt für Schwimmbäder nach EN 16582-1 und wird in Zusammenhang mit dieser Norm gelesen.
Diese Norm gilt nicht für:
 Schwimmbäder für die öffentliche Nutzung nach EN 15288-1;
 Warmsprudelbecken für die private oder öffentliche Nutzung;
 Planschbecken nach EN 71-8;
 Vorfiltration;
 Teiche und Naturschwimmbäder.
ANMERKUNG Zu Filtrationssystemen siehe EN 16713-1 und zu Aufbereitungssystemen siehe EN 16713-3.

Piscines privées à usage familial - Systèmes de distribution d'eau - Partie 2 : Systèmes de circulation - Exigences et méthodes d'essai

La présente Norme européenne spécifie les exigences et les méthodes d'essai relatives aux systèmes de circulation et est applicable aux équipements utilisés dans les piscines privées à usage familial et conçus pour la circulation de l'eau (introduction et/ou extraction).
La présente norme s'applique aux piscines définies dans l'EN 16582-1 et doit être lue conjointement avec cette dernière.
La présente norme ne s’applique pas :
—   aux piscines à usage collectif couvertes par l'EN 15288-1 ;
—   aux spas à usage privé familial ou à usage collectif ;
—   aux pataugeoires selon l'EN 71-8 ;
—   à la pré-filtration ;
—   aux bassins naturels et analogues.
NOTE   Pour les systèmes de filtration, voir l'EN 16713-1 et pour le traitement de l’eau, voir l'EN 16713-3.

Plavalni bazeni za domačo uporabo - Vodni sistemi - 2. del: Sistemi vodnega kroženja - Zahteve in preskusne metode

Ta dokument določa zahteve in preskusne metode za sisteme vodnega kroženja in se uporablja za opremo v domačih plavalnih bazenih in opremo, izdelano za kroženje vode (dovajanje in/ali odvajanje).
Ta standard velja za plavalne bazene, kot je opredeljeno v standardu EN 16582-1, in se navezuje na navedeni standard.
Ta standard se ne uporablja za:
– klasificirane bazene, kot je opredeljeno v standardu EN 15288;
– domače prostore za dobro počutje;
– naravne in naravnim podobne bazene.
OPOMBA: Za filtrirne sisteme glej standarda prEN 16713-1 in prEN 16713-3.

General Information

• Status: Published
• Publication Date: 09-Feb-2016
• Withdrawal Date: 30-Aug-2016
• ICS: 97.220.10 - Sports facilities
• Technical Committee: CEN/TC 402 - Private family Swimming Pools and related materials/equipment and accessories
• Drafting Committee: CEN/TC 402/WG 2 - Pool water circulation, filtration and treatment
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 21-Oct-2021
• Completion Date: 14-Apr-2025
• Ref Project: SIST EN 16713-2:2016 - Domestic swimming pools - Water systems - Part 2: Circulation systems - Requirements and test methods

Relations

• Amended By: EN 16713-2:2016/prA1:2018 - Domestic swimming pools - Water systems - Part 2: Circulation systems - Requirements and test methods
• Effective Date: 07-Feb-2018

Overview

EN 16713-2:2016 (CEN) - "Domestic swimming pools - Water systems - Part 2: Circulation systems - Requirements and test methods" specifies safety, performance and test requirements for circulation equipment used in domestic (private) swimming pools. It covers devices and systems designed to introduce and/or extract pool water (pumps, skimmers, overflow channels, main drains, pipework, suction chambers and associated components). The standard is intended to be read in conjunction with EN 16582-1 (general requirements for domestic pools).

Key topics and technical requirements

• Filtration system design and nominal flow rate
  • Systems must be sized to meet pump/filter performance and ensure full pool turnover within a maximum of 8 hours. Basic calculation: Q = V / T (Q = flow rate, V = pool volume, T = turnover time).
• Extraction methods
  • Requirements for overflow channels, skimmers, channel drains and main drains including dimensions, capacity, access and cleanability.
• Suction entrapment and safety
  • Risk-reduction measures for suction outlets, suction chambers, grille design and prevention of fingernail/hair entrapment.
• Introduction of water
  • Design rules for return inlets, reduced-flow conditions and water/air-operated leisure features (jets, hydromassage).
• Pipework and pumps
  • Material resistance, hydrostatic pressure testing, self-priming performance, endurance and cyclical endurance tests, plus installation guidance and pump performance characterization.
• Test methods and verification
  • Prescribed tests: dye tracing, entrapment tests, hair-entrapment, outlet obstruction tests and pump evaluation (including ISO-based hydraulic acceptance testing).
• Information to users/installers
  • Required instructions and safety information for correct installation, operation and maintenance.

Applications and who uses this standard

• Pool manufacturers and component suppliers - to design and certify circulation equipment (pumps, grilles, skimmers, overflow systems).
• Pool designers and installers - to size systems, specify turnover rates, layout overflow/balance tanks and reduce entrapment risks.
• Testing laboratories and conformity assessors - to perform the specified tests (dye, entrapment, pump endurance).
• Regulators and certifiers - to reference consistent safety/performance criteria for private pools.
• Informed homeowners and facility managers - to understand safety and performance expectations when buying or maintaining domestic pool equipment.

Related standards

• EN 16713-1 - Filtration systems: requirements and test methods
• EN 16713-3 - Water treatment: requirements
• EN 16582-1 - Domestic swimming pools - General requirements (safety & test methods)
• EN ISO 9906 - Rotodynamic pump hydraulic performance tests
• HD 60364-7-702 - Electrical installations - Swimming pools

Keywords: EN 16713-2:2016, domestic swimming pools, circulation systems, pool circulation standard, pump testing, turnover rate, overflow channel, suction entrapment, pool safety, CEN.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Schwimmbäder für private Nutzung - Wassersysteme - Teil 2: Umwälzsysteme - Anforderungen und PrüfverfahrenPiscines privées à usage familial - Systèmes de distribution d'eau - Partie 2: Systèmes de circulation - Exigences et méthodes d'essaiDomestic swimming pools - Water systems - Part 2: Circulation systems - Requirements and test methods97.220.10Športni objektiSports facilitiesICS:Ta slovenski standard je istoveten z:EN 16713-2:2016SIST EN 16713-2:2016en,fr,de01-april-2016SIST EN 16713-2:2016SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 16713-2
February
t r s x ICS
{ yä t t rä s r English Version
Domestic swimming pools æ Water systems æ Part
tã Circulation systems æ Requirements and test methods Piscines privées à usage familial æ Systèmes de distribution d 5eau æ Partie
tã Systèmes de circulation æ Exigences et méthodes d 5essai
Schwimmbäder für private Nutzung æ Wassersysteme æTeil
tã Umwälzsysteme æ Anforderungen und Prüfverfahren This European Standard was approved by CEN on
w December
t r s wä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Avenue Marnix 17,
B-1000 Brussels
t r s x CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s x y s uæ tã t r s x ESIST EN 16713-2:2016

Pressure test procedure . 26 Annex B (informative)
Pump selection principle . 27 Annex C (informative)
Environmental aspects . 28 Bibliography . 31
¶ 0,5 m/s. Hair entrapment tests shall be performed on suction devices according to 5.3. Safety requirements a) to c) are not applicable to: — skimmers, because they are vented (see 4.4.3) and partly above the water level; — integrated swim jet systems, because the users are pushed away from the outlet, as defined in 3.3 by the action of the inlet. Additionally at least one of the following requirements shall be met: a) multiple suction outlet system designed in such a way that: 1) a minimum of two balanced and functioning suction outlets; 2) the distance between the nearest points of the perimeters of the devices shall be as large as possible with respect to the size of the pool and the design of suction outlets, but with a minimum of 1 m to ensure the appropriate level of safety from entrapment; 3) if any one of the suction outlets becomes blocked, the flow through the remaining suction outlet/s shall accommodate 100 % of the flow rate. b) in case of suction outlet systems with only one grille, the grille shall be designed in such a way that, either, 1) one user cannot cover more than 50 % of the opening; or 2) raised grilles domed opposite to the flow direction, with prevalent peripheral suction. The height of the dome shall be at least 10 % of the main dimension; or 3) single grilles with a surface of the area circumscribed to the suction openings
· 1 m2 (see Figure 1); or
Figure 1 — Identification of the area circumscribed to the suction openings c) any suitable designed outlet suction grille(s) that complies with the obstruction tests according to 5.4. In addition to the requirements in a) to c), a vacuum release system may be provided. When retrofitting existing installations that have a single suction outlet which does not comply with the requirements of this clause, then the following actions are required: SIST EN 16713-2:2016

Key a indicates suggested suction chamber configuration D inside diameter of the pipe Dmin dimension
· D Figure 2 — Minimum suction chamber dimensions 4.4.3 Skimmers Skimmers shall be effectively vented to atmosphere through openings in the lid (see Figure 3), or through a separate vent pipe. SIST EN 16713-2:2016

Key 1 vent trough lid Figure 3 — Skimmer, vent through lid 4.5 Introduction of pool water 4.5.1 General Water returning to the pool tank under pressure will assist the general movement of water in the pool. The number of inlets should be sufficient to take 100 % of the nominal flow rate of filtration system. The water speed at pool inlets shall be
¶ 15 m/s, except for vertical injection from the swimming pool floor in water depth < 700 mm, where it shall be
¶ 2 m/s. The number and location of the inlets shall ensure an equal and efficient water distribution in order to avoid water stagnation taking into account the following: a) effective water volume of the pool and pool size; b) pool shape; c) outlet location; d) nominal flow rate of filtration system. To verify the water distribution the dye test according to 5.1 may be applied if necessary. 4.5.2 Introduction of pool water at reduced filtration flow rate In case of reduced filtration flow rate e.g. during night time when the pool is not used, the introduction of pool water into the pool shall still be sufficient to ensure the maximum turnover time in 4.2. The validation at reduced flow rate may be verified according to 5.1 if necessary. 4.5.3 Air and water operated leisure feature 4.5.3.1 Introduction of water and/or air from the floor Features incorporating the introduction of water and/or air under pressure from the swimming pool floor shall not be installed in depths of less than 700 mm unless: a) the vertical water speed is
¶ 2 m/s (see 4.5.1); b) the total dynamic head in the system before the inlet is
¶ 30 kPa
m H2O). SIST EN 16713-2:2016
Key 1 walkable floor Figure 4 — Fountains — Horizontal and vertical clearances Generally, protruding jets should be avoided on the swimming pool wall, however in the case of overhanging counter-current or filtration units, protruding jets are allowed as long as they are part of a visible obstacle in the pool. 4.5.4 Other dangers The manufacturer shall provide recommendations for maintenance and cleaning of the air and water operated leisure features. 4.6 Pipe work The pipework and fittings used in any circulation system should be sized to take the nominal flow rate of filtration system and to minimize frictional head losses. The material should be non-corroding and in general terms suitable for the head pressure in the system and the water speed should not exceed 3 m/s with in the circulation pipe work at the pressure side. This is a maximum water speed at the pressure side, lower speeds are encouraged and will result in added energy savings. To avoid a potential cavitation risk it is recommended that water speed at the suction side of the pump shall be lower than the water speed at the pressure side taking into account pump suction behaviour and manufacturer's recommendations. SIST EN 16713-2:2016
...
