INTERNATIONAL STANDARD ISO 6848:2004(E)
Arc welding and cutting — Nonconsumable tungsten
electrodes — Classification
1 Scope
This International Standard specifies requirements for classification of nonconsumable tungsten electrodes for
inert gas shielded arc welding, and for plasma welding, cutting and thermal spraying.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 31-0:1992, Quantities and units — Part 0: General principles
3 Classification
Classification of a tungsten electrode is based upon its chemical composition.
4 Symbols and requirements
4.1 Symbol for the product/process
The symbol for gas shielded tungsten arc processes is the letter W.
4.2 Symbol for the chemical composition
The symbol for the chemical composition of the tungsten electrode is the chemical symbol for the principal
oxide additive followed by digits indicating the nominal mass percent of the oxide additive multiplied by 10. If
there is no additive, the symbol is the letter P. Table 1 lists the composition requirements for the various
classifications. Compositions not listed in Table 1 shall be symbolized by the letters WG, followed by the
chemical symbol and digits for the major oxide additive, according to the principle used for the other
compositions given in Table 1.
5 Chemical analysis
Chemical analysis shall be performed on specimens of the electrode being classified. Any analytical technique
may be used but, in cases of dispute, reference shall be made to established published methods.
6 Retests
If any test fails to meet the requirement, that test shall be repeated twice. The results of both retests shall
meet the requirements. Specimens for retesting may be taken from the original test assembly or from a new
test assembly. For chemical analysis, retests need only be for those specific elements that failed to meet their
ISO 6848:2004(E)
test requirement. If the results of one or both retests fail to meet the requirement, the material under test shall
be considered as not meeting the requirements of this specification for that classification.
In the event that, during preparation or after completion of any test, it is clearly determined that prescribed or
proper procedures were not followed in preparing the weld test assembly or test specimen(s), or in conducting
the tests, the test shall be considered invalid, without regard to whether the test was actually completed, or
whether the test results met, or failed to meet, the requirement. That test shall be repeated, following proper
prescribed procedures. In this case, the requirement for doubling the number of test specimens does not
apply.
7 Marking
In accordance with Table 1, tungsten electrodes shall be marked on the basis of their chemical composition,
with one colour ring near one end of the electrode. The width of the colour ring shall be at least 3 mm.
Alternatively, tungsten electrodes may have their classification symbols marked on the surface of the
electrode near at least one end of the electrode.
Table 1 — Chemical composition requirements for tungsten electrodes
Chemical composition requirements
Colour code,
Classification
Oxide addition Impurities, Tungsten,
RGB colour value and
symbol
a
mass mass
colour sample
Principal oxide Mass percent
percent percent
Green
b
#008000
WP None N.A. 0,5 max. 99,5 min.
Grey
#808080
CeO
WCe 20 1,8 to 2,2 0,5 max. Balance
Black
#000000
La O
WLa 10 0,8 to 1,2 0,5 max. Balance
2 3
Gold
#FFD700
La O
WLa 15 1,3 to 1,7 0,5 max. Balance
2 3
Blue
#0000FF
WLa 20 La O 1,8 to 2,2 0,5 max. Balance
2 3
Yellow
#FFFF00
ThO
WTh 10 0,8 to 1,2 0,5 max. Balance
Red
#FF0000
ThO
WTh 20 1,7 to 2,2 0,5 max. Balance
2 © ISO 2004 – All rights reserved
ISO 6848:2004(E)
Table 1 (continued)
Chemical composition requirements
Colour code,
Classification
Oxide addition Impurities, Tungsten,
RGB colour value and
symbol
a
mass mass
colour sample
Principal oxide Mass percent
percent percent
Violet
#EE82EE
WTh 30 ThO 2,8 to 3,2 0,5 max. Balance
Brown
#A52A2A
ZrO
WZr 3 0,15 to 0,50 0,5 max. Balance
White
#FFFFFF
ZrO
WZr 8 0,7 to 0,9 0,5 max. Balance
a
RGB colour values and colour samples can be found at the following website:
http://msdn.microsoft.com/library/default.asp?url=/workshop/author/dhtml/reference/colors/colors.asp
b
N.A. = Not applicable.
8 Standard sizes and tolerances
8.1 Electrode diameters
Standard electrode diameters and tolerances are given in Table 2. Other diameters and tolerances may be as
agreed between supplier and purchaser.
ISO 6848:2004(E)
Table 2 — Standard electrode diameters and tolerances
Diameter Tolerance
mm mm
0,25
± 0,02
0,30 ± 0,02
0,50 ± 0,05
1,0 ± 0,05
1,5
± 0,05
1,6 ± 0,05
2,0
± 0,05
2,4 ± 0,1
2,5
± 0,1
3,0 ± 0,1
3,2
± 0,1
4,0 ± 0,1
4,8 ± 0,1
5,0 ± 0,1
6,3 ± 0,1
6,4 ± 0,1
8,0 ± 0,1
10,0 ± 0,1
8.2 Electrode lengths
Standard electrode lengths and tolerances are given in Table 3. Other lengths and tolerances may be as
agreed between supplier and purchaser.
Table 3 — Standard electrode lengths and tolerances
Length Tolerance
mm mm
50 ± 1,5
+ 2,5
− 1,0
+ 4
− 1
+ 6
− 1
+ 8
− 1
+ 8
− 1
+ 13
− 1
4 © ISO 2004 – All rights reserved
ISO 6848:2004(E)
8.3 Electrode straightness
Electrodes shall not deviate from straight by more than 0,5 mm over any 100 mm of length or less.
9 Rounding-off procedure
For purposes of determining compliance with the requirements of this International Standard, the actual test
values obtained shall be subjected to the rounding-off rules of ISO 31-0:1992, Annex B, Rule A. If the
measured values are obtained by equipment calibrated in units other than those of this International Standard,
the measured values shall be converted to the units of this International Standard before rounding off. If an
average value is to be comp
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
