EN ISO 4080:2024
(Main)Rubber and plastics hoses and tubing, and their assemblies - Determination of permeability to gas (ISO 4080:2024)
Rubber and plastics hoses and tubing, and their assemblies - Determination of permeability to gas (ISO 4080:2024)
This document specifies three methods to determine the permeability to gas by measuring the volume of gas diffusing through a rubber or plastics hose or length of tubing used for gas applications in a specified time.
— Method 1 is for determining the permeability of the complete hose wall or length of tubing wall, excluding end fittings, to the test gas.
— Method 2 is for determining the permeability at the hose and fitting interface to the test gas.
— Method 3 is for precisely determining the permeability of the complete hose or length of tubing, including end fittings.
Gummi- und Kunststoffschläuche mit und ohne Einlage und Schlauchleitungen - Bestimmung der Gasdurchlässigkeit (ISO 4080:2024)
In diesem Dokument werden drei Verfahren zur Bestimmung der Gasdurchlässigkeit durch Messung des Gasvolumens festgelegt, das in einer festgelegten Zeit durch einen Gummi- oder Kunststoffschlauch oder eine Schlauchleitung für Gasanwendungen diffundiert.
- Verfahren 1 dient der Bestimmung der Prüfgasdurchlässigkeit der gesamten Schlauchwand oder Schlauchwandlänge mit oder ohne Einlage, mit Ausnahme der Endarmaturen.
- Verfahren 2 dient der Bestimmung der Prüfgasdurchlässigkeit im Übergangsbereich von Schlauch und Armatur.
- Verfahren 3 dient der präzisen Bestimmung der Durchlässigkeit des gesamten Schlauchs oder der Schlauchlänge mit oder ohne Einlage, einschließlich der Endarmaturen.
Tuyaux et tubes en caoutchouc et en plastique, et leurs assemblages - Détermination de la perméabilité au gaz (ISO 4080:2024)
Le présent document spécifie trois méthodes pour déterminer la perméabilité au gaz en mesurant le volume de gaz diffusant à travers un tuyau ou une longueur de tube en caoutchouc ou en plastique utilisé pour les applications gazières pendant une durée déterminée.
— La méthode 1 est destinée à déterminer la perméabilité au gaz d'essai de la paroi du tuyau entier ou de la paroi d'une longueur de tube, à l'exclusion des embouts.
— La méthode 2 est destinée à déterminer la perméabilité au gaz d'essai de l'interface du tuyau et du raccord.
— La méthode 3 est destinée à déterminer précisément la perméabilité du tuyau entier ou d'une longueur de tube, comprenant des embouts.
Gumene in polimerne cevi in cevovodi ter njihovi priključki - Ugotavljanje prepustnosti za pline (ISO/FDIS 4080:2024)
General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
oSIST prEN ISO 4080:2023
01-oktober-2023
Nadomešča:
SIST EN ISO 4080:2010
Gumene in polimerne cevi in cevovodi ter njihovi priključki - Ugotavljanje
prepustnosti za pline (ISO/DIS 4080:2023)
Rubber and plastics hoses and tubing, and their assemblies - Determination of
permeability to gas (ISO/DIS 4080:2023)
Gummi- und Kunststoffschläuche und Schlauchleitungen - Bestimmung der
Gasdurchlässigkeit (ISO/DIS 4080:2023)
Tuyaux et flexibles en caoutchouc et en plastique - Détermination de la perméabilité au
gaz (ISO/DIS 4080:2023)
Ta slovenski standard je istoveten z: prEN ISO 4080
ICS:
83.140.40 Gumene cevi Hoses
oSIST prEN ISO 4080:2023 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
oSIST prEN ISO 4080:2023
oSIST prEN ISO 4080:2023
DRAFT INTERNATIONAL STANDARD
ISO/DIS 4080
ISO/TC 45/SC 1 Secretariat: DIN
Voting begins on: Voting terminates on:
2023-08-02 2023-10-25
Rubber and plastics hoses and tubing, and their
assemblies — Determination of permeability to gas
ICS: 23.040.70
This document is circulated as received from the committee secretariat.
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
ISO/CEN PARALLEL PROCESSING
THEREFORE SUBJECT TO CHANGE AND MAY
NOT BE REFERRED TO AS AN INTERNATIONAL
STANDARD UNTIL PUBLISHED AS SUCH.
IN ADDITION TO THEIR EVALUATION AS
BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
USER PURPOSES, DRAFT INTERNATIONAL
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
POTENTIAL TO BECOME STANDARDS TO
WHICH REFERENCE MAY BE MADE IN
Reference number
NATIONAL REGULATIONS.
ISO/DIS 4080:2023(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2023
oSIST prEN ISO 4080:2023
ISO/DIS 4080:2023(E)
DRAFT INTERNATIONAL STANDARD
ISO/DIS 4080
ISO/TC 45/SC 1 Secretariat: DIN
Voting begins on: Voting terminates on:
Rubber and plastics hoses and tubing, and their
assemblies — Determination of permeability to gas
ICS: 23.040.70
This document is circulated as received from the committee secretariat.
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
© ISO 2023
ISO/CEN PARALLEL PROCESSING
THEREFORE SUBJECT TO CHANGE AND MAY
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
NOT BE REFERRED TO AS AN INTERNATIONAL
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on STANDARD UNTIL PUBLISHED AS SUCH.
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
IN ADDITION TO THEIR EVALUATION AS
or ISO’s member body in the country of the requester. BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
ISO copyright office
USER PURPOSES, DRAFT INTERNATIONAL
CP 401 • Ch. de Blandonnet 8
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
CH-1214 Vernier, Geneva
POTENTIAL TO BECOME STANDARDS TO
Phone: +41 22 749 01 11
WHICH REFERENCE MAY BE MADE IN
Reference number
Email: copyright@iso.org
NATIONAL REGULATIONS.
Website: www.iso.org ISO/DIS 4080:2023(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
Published in Switzerland
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
ii
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2023
oSIST prEN ISO 4080:2023
ISO/DIS 4080:2023(E)
Contents Page
Foreword .iv
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 1
4 Test pieces .2
4.1 Method 1 . 2
4.2 Method 2 . 2
4.3 Method 3 . 2
5 Apparatus . 2
6 Conditions for the test . 3
6.1 Test pieces . . 3
6.2 Test temperature . 3
6.3 Test gas . 3
6.4 Test pressure . 3
7 Procedure .3
7.1 General . 3
7.2 Method 1 . 4
7.3 Method 2 . 5
7.4 Method 3 . 5
8 Expression of results . 6
9 Test report . 7
Annex A (informative) Guidance on permeation . 8
Annex B (normative) Saturated vapour pressure .10
Annex C (informative) Guidance on test methods and their application .11
Bibliography .13
iii
oSIST prEN ISO 4080:2023
ISO/DIS 4080:2023(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www.iso.org/directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www.iso.org/patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to
the World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT), see
www.iso.org/iso/foreword.html.
This document was prepared by Technical Committee ISO/TC 45, Rubber and rubber products,
Subcommittee SC 1, Rubber and plastics hoses and hose assemblies.
This fifth edition cancels and replaces the fourth edition, which has been technically revised.
The main changes compared to the previous edition are as follows:
— revised gas permeation test as a whole;
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www.iso.org/members.html.
iv
oSIST prEN ISO 4080:2023
DRAFT INTERNATIONAL STANDARD ISO/DIS 4080:2023(E)
Rubber and plastics hoses and tubing, and their
assemblies — Determination of permeability to gas
WARNING — Persons using this document should be familiar with normal laboratory practice.
This document does not purport to address all of the safety problems, if any, associated with its
use. It is the responsibility of the user to establish appropriate safety and health practices.
1 Scope
This document specifies three methods for the determination of the volume of gas diffusing through a
rubber or plastics hose or length of tubing used for gas applications in a specified time.
Method 1:
For determining the volume of gas diffusing through the complete hose or length of tubing,
excluding end fittings in a specified time. This method is suitable for textile reinforced hose
with either pricked cover or textile cover or both, although this method is not suitable for
textile reinforced hose with unpricked cover. The permeability is calculated with respect to
the length of the hose or tubing and to the surface area of the hose lining or the tubing.
Method 2:
For determining the volume of gas diffusing at the hose and fitting interface. This method is
used when determining the permeability characteristics of textile reinforced hoses with an
unpricked cover, when the gas usually issues from the textile reinforcement at the cut ends.
The permeability is calculated with respect to the length of the hose and to the surface area of
the hose lining.
Method 3:
For precisely determining the volume of gas diffusing through the complete hose or length
of tubing including end fittings in a specified time. This method is not suitable for textile
reinforced hose with unpricked cover. The permeability is calculated with respect to the length
of the hose or tubing and to the surface area of the hose lining or the tubing.
NOTE 1 Guidance on test methods are provided in Annex C, Table C.1.
NOTE 2 Explanation of permeability is provided in Annex A, where the concept of trapped air and permeation
is explained in Figure A.1.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 8330, Rubber and plastics hoses and hose assemblies — Vocabulary
ISO 23529, Rubber — General procedures for preparing and conditioning test pieces for physical test
methods
3 Terms and definitions
For the purpose of this document, the terms and definitions given in ISO 8330 and the following apply.
oSIST prEN ISO 4080:2023
ISO/DIS 4080:2023(E)
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available
...
