EN 12573-3:2000

(Main)

Welded static non-pressurized thermoplastic tanks - Part 3: Design and calculation for single skin rectangular tanks

Welded static non-pressurized thermoplastic tanks - Part 3: Design and calculation for single skin rectangular tanks

This standard specifies the design and calculation for single sking rectangular tanks, fabricated from the following thermoplastics: Polyethylene (PE), Polypropylene (PP), Poly (vinyl chloride) (PVC), Poly (vinylidene fluoride) (PVDF). The tanks may be strengthened on the outside by means of ribs or frames made of the same or other materials. This standard is only applicable to tanks which are not intended to withstand internal pressure or vaccuum, other than that which may occur during the transfer of fluids (including gases) in their normal operation.

Geschweißte ortsfeste drucklose Behälter (Tanks) aus Thermoplasten - Teil 3: Konstruktion und Berechnung von einwandigen Rechteckbehältern (-tanks)

Diese Norm legt die Konstruktion und Berechnung von einwandigen Rechtecktanks fest, die aus den folgenden Thermoplasten gefertigt werden: Polyethylen (PE), Polypropylen (PP), Polyvinylchlorid (PVC), Polyvinylidenfluorid (PVDF). Die Tanks können von außen mit Rippen oder Rahmen aus demselben oder anderen Werkstoffen verstärkt sein. Diese Norm ist nur anwendbar für Tanks, die ohne inneren Überdruck oder Vakuum betrieben werden, ausgenommen die während des Befüllens/Entleerens mit Fluiden (einschließlich Gasen) bei Normalbetrieb vorkommenden Drücke.

Cuves statiques soudées en matières thermoplastiques sans pression - Partie 3: Conception et calcul des cuves parallélépipédiques rectangles à simple paroi

La présente norme prescrit la conception et les calculs concernant les cuves parallélépipédiques rectangles à simple paroi, fabriquées à partir des matériaux thermoplastiques suivants: polyéthylène (PE), polypropy- lène (PP), polychlorure de vinyle (PVC), polyfluorure de vinylidène (PVDF). Les cuves peuvent être renforcées extérieurement par des nervures ou des cadres fabriqués soit dans la même matière, soit dans une autre matière.

Welded static non-pressurized thermoplastic tanks - Part 3: Design and calculation for single skin rectangular tanks

General Information

Status
Published
Publication Date
21-Mar-2000
ICS
23.020.10 - Stationary containers and tanks
Technical Committee
CEN/TC 249 - Plastics
Drafting Committee
CEN/TC 249/WG 25 - Static thermoplastic tanks for above ground storage of fuel
Current Stage
9093 - Decision to confirm - Review Enquiry
Completion Date
31-Jul-2017
Directive
305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
89/106/EEC - Construction products
Mandate
M/131 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on pipes, tanks and ancillaries, not in contact with water intended for human consumption
Ref Project
SIST EN 12573-3:2000 - Welded static non-pressurized thermoplastic tanks - Part 3: Design and calculation for single skin rectangular tanks

Buy Standard

EN 12573-3:2000EN 12573-3:2000
PreviousNext
Standard
EN 12573-3:2000
English language
32 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)
