IEC 63404:2024 defines radiocommunication related requirements for equipment intended to integrate a radiocommunication device. It includes the initial integration and update of a the radiocommunication device, having a carrier frequency greater than 380 MHz, into new or updated host equipment with: - The classification of integration categories; - The EMC immunity verification using a capability profile approach; - The verification of the unwanted emission level of the radio transceiver.
Niederspannungsschaltgeräte und deren Niederspannungs-Schaltgerätekombinationen - Integration einer Funkkommunikationseinrichtung oberhalb 380 MHz in ein Gerät
Appareillages et ensembles d'appareillages à basse tension - Intégration d'un dispositif de radiocommunication de plus de 380 MHz à un équipement
L'IEC 63404:2024 définit les exigences relatives à la radiocommunication pour les équipements destinés à intégrer un dispositif de radiocommunication. Il couvre l'intégration initiale et la mise à jour d'un dispositif de radiocommunication, dont la fréquence porteuse est supérieure à 380 MHz, dans un équipement hôte neuf ou mis à jour, avec: - la classification des catégories d'intégration; - la vérification de l'immunité CEM selon l'approche par profil de capacité; - la vérification du niveau de rayonnements non désirés de l'émetteur-récepteur radioélectrique.
