IEC TR 61340-1:2012

Electrostatics - Part 1: Electrostatic phenomena - Principles and measurements

IEC/TR 61340-1:2012 describes the fundamental principles of electrostatic phenomena including charge generation, retention and dissipation and electrostatic discharges. Methods for measuring electrostatic phenomena and related properties of materials are described in a general way. Hazards and problems associated with electrostatic phenomena and principles of their control are outlined. Useful applications of electrostatic effects are summarized. The purpose of this technical report is to serve as a reference for the development of electrostatics related standards, and to provide guidance for their end-users. The contents of the corrigendum of March 2013 and the corrigendum 2 of December 2017 have been included in this copy.

Electrostatique - Partie 1: Phénomènes électrostatiques - Principes et mesures

La CEI/TR 61340-1:2012 qui est un rapport technique, décrit les principes fondamentaux relatifs aux phénomènes électrostatiques, comprenant la génération, le maintien et la dissipation de la charge, et les décharges électrostatiques. Les méthodes de mesure des phénomènes électrostatiques et des propriétés associées des matériaux sont décrites de manière générale. Les dangers et les problèmes liés aux phénomènes électrostatiques ainsi que les principes de leur contrôle sont présentés dans les grandes lignes. Des applications utiles des effets électrostatiques sont résumées. Le présent rapport technique est destinée à servir de référence pour l'élaboration de normes relatives aux phénomènes électrostatiques et de guide pour l'utilisateur final. Le contenu du corrigendum de mars 2013 et de décembre 2017 a été pris en considération dans cet exemplaire.

General Information

• Status: Published
• Publication Date: 09-Jun-2020
• ICS: 17.220.99 - Other standards related to electricity and magnetism
• ICS: 29.020 - Electrical engineering in general
• Technical Committee: TC 101 - Electrostatics
• Current Stage: PPUB - Publication issued
• Start Date: 26-Jun-2012
• Completion Date: 31-Aug-2012

Relations

• Amended By: IEC TR 61340-1:2012/AMD1:2020 - Amendment 1 - Electrostatics - Part 1: Electrostatic phenomena - Principles and measurements
• Effective Date: 05-Sep-2023
• Corrected By: IEC TR 61340-1:2012/COR2:2017 - Corrigendum 1 - Electrostatics - Part 1: Electrostatic phenomena - Principles and measurements
• Effective Date: 05-Sep-2023
• Corrected By: IEC TR 61340-1:2012/COR1:2013 - Corrigendum 1 - Electrostatics - Part 1: Electrostatic phenomena - Principles and measurements
• Effective Date: 05-Sep-2023

Overview

IEC TR 61340-1:2012 - "Electrostatics – Part 1: Electrostatic phenomena – Principles and measurements" is a Technical Report from the IEC that describes the fundamental principles of electrostatic phenomena and gives general guidance on measurement methods. The consolidated Edition 1.1 (2012 + corrigenda and Amendment 1, 2020) serves as a reference for standards development and for end‑users seeking a practical understanding of charge generation, retention, dissipation and electrostatic discharges (ESD).

Key topics

The report covers core electrostatics concepts and measurement-related topics, including:

• Charge generation and contact electrification (triboelectric effects and charge transfer mechanisms)
• Charging by induction and conduction, and retention of charge on materials
• Influence of environmental humidity on charge and charge decay
• Electrostatic discharges: spark, corona, brush, propagating brush and cone discharges; associated energy and ignition potential
• Mechanical forces in electrostatic fields
• ESD failure modes and hazards for electronic components, ignition risks, and human perception
• Common ESD simulation models referenced (human body model, machine model, charged device model) and circuits for discharge simulation
• Measurement concepts: electric field, surface and space potential, surface charge density, charge decay, resistance/resistivity, capacitance and charge transferred in discharges
• General measurement arrangements and practical guidance rather than prescriptive test procedures

Note: IEC TR 61340-1 is a technical report (guidance), not a prescriptive test standard; it provides principles and measurement options rather than mandatory limits.

Applications

IEC TR 61340-1 is useful for organizations and professionals involved in:

• ESD control and prevention programs in electronics manufacturing and assembly
• Product designers and material suppliers selecting packaging, coatings and components with favorable electrostatic properties
• Test laboratories developing measurement methods for surface voltage, charge decay and discharge energy
• Safety and process engineers assessing ignition hazards in flammable atmospheres
• Standards developers and researchers using the document as a reference for developing or harmonizing ESD-related standards

Practical uses include guiding risk assessments, specifying measurement setups, training engineers on ESD phenomena, and informing mitigation strategies (grounding, ionization, humidity control, conductive materials).

Related standards

• Other parts of the IEC 61340 series (Electrostatics) expand on ESD control methods and product‑specific guidance.
• The report references common ESD simulation models (Human Body Model, Machine Model, Charged Device Model) used across industry ESD standards.

Keywords: IEC TR 61340-1:2012, electrostatics, electrostatic discharge, ESD, charge decay, surface voltage, measurement methods, triboelectric, ESD control.

Standards Content (Sample)

IEC TR 61340-1 ®
Edition 1.1 2020-06
CONSOLIDATED VERSION
TECHNICAL
REPORT
colour
inside
Electrostatics –
Part 1: Electrostatic phenomena – Principles and measurements

All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form
or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from
either IEC or IEC's member National Committee in the country of the requester. If you have any questions about IEC
copyright or have an enquiry about obtaining additional rights to this publication, please contact the address below or
your local IEC member National Committee for further information.

IEC Central Office Tel.: [phone]
3, rue de Varembé [e-mail]
CH-1211 Geneva 20 www.iec.ch
Switzerland
About the IEC
The International Electrotechnical Commission (IEC) is the leading global organization that prepares and publishes
International Standards for all electrical, electronic and related technologies.

About IEC publications
The technical content of IEC publications is kept under constant review by the IEC. Please make sure that you have the
latest edition, a corrigendum or an amendment might have been published.

IEC publications search - webstore.iec.ch/advsearchform Electropedia - www.electropedia.org
The advanced search enables to find IEC publications by a The world's leading online dictionary on electrotechnology,
variety of criteria (reference number, text, technical containing more than 22 000 terminological entries in English
committee,…). It also gives information on projects, replaced and French, with equivalent terms in 16 additional languages.
and withdrawn publications. Also known as the International Electrotechnical Vocabulary

(IEV) online.
IEC Just Published - webstore.iec.ch/justpublished
Stay up to date on all new IEC publications. Just Published IEC Glossary - std.iec.ch/glossary
details all new publications released. Available online and 67 000 electrotechnical terminology entries in English and
once a month by email. French extracted from the Terms and definitions clause of
IEC publications issued between 2002 and 2015. Some
IEC Customer Service Centre - webstore.iec.ch/csc entries have been collected from earlier publications of IEC
If you wish to give us your feedback on this publication or TC 37, 77, 86 and CISPR.

need further assistance, please contact the Customer Service

Centre: [e-mail].
IEC TR 61340-1 ®
Edition 1.1 2020-06
CONSOLIDATED VERSION
TECHNICAL
REPORT
colour
inside
Electrostatics –
Part 1: Electrostatic phenomena – Principles and measurements

INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
ICS 17.220.99; 29.020 ISBN 978-2-8322-8521-3

IEC TR 61340-1 ®
Edition 1.1 2020-06
REDLINE VERSION
colour
inside
Electrostatics –
Part 1: Electrostatic phenomena – Principles and measurements

– 2 – IEC TR 61340-1:2012+AMD1:2020 CSV
© IEC 2020
CONTENTS
1 Scope . 7
2 Normative references . 7
3 Terms and definitions . 8
4 Fundamentals of static electricity . 10
4.1 General . 10
4.2 Contact electrification . 11
4.3 Charging by induction . 12
4.4 Charge transfer by conduction . 13
4.5 Retention of charge . 13
4.6 Influence of environmental humidity . 15
4.6.1 General . 15
4.6.2 In situ measurements . 15
4.7 Electrostatic discharges . 15
4.7.1 General . 15
4.7.2 Spark discharges . 15
4.7.3 Corona discharges . 16
4.7.4 Brush discharges . 16
4.7.5 Propagating brush discharges . 16
4.7.6 Cone discharges . 17
4.8 Mechanical forces in an electrostatic field . 17
5 Electrostatic problems and hazards . 18
5.1 General . 18
5.2 Electronic components and systems . 18
5.2.1 General . 18
5.2.2 Types of failure . 18
5.2.3 Problems and threats at different life cycle periods . 19
5.3 Electrostatic ignition – Hazards . 20
5.3.1 General . 20
5.3.2 Spark discharges from conducting objects . 20
5.3.3 Corona discharges from conducting objects . 20
5.3.4 Brush discharges from insulating surfaces . 20
5.3.5 Propagating brush discharges from insulating surfaces . 21
5.3.6 Discharges from people . 21
5.3.7 Ignition potential of electrostatic discharges . 21
5.4 Physiological sensation . 23
5.5 Simulation of electrostatic discharges. 24
5.5.1 General . 24
5.5.2 Capacitive discharges for ignition energy measurements . 25
5.5.3 Human body model . 25
5.5.4 Machine model . 25
5.5.5 Charged device model . 25
6 General solutions to problems and hazards . 26
6.1 General . 26
6.2 Common approaches. 26
7 Useful applications of electrostatic effects . 27
8 General aspects of measurements . 28
