IEC 63455:2025

Multimedia systems and equipment - Multimedia signal transmission - Dependable line code with error correction

IEC 63455:2025 specifies the 4b/10b line code with error correction for dependable multimedia data transmission, especially for real-time communications even in noisy environments, such as IoT devices, wearable devices, sensor networks, robotics, and spacecraft. This document corresponds to the functions specified in layer 1 to layer 2 of the OSI reference model (ISO/IEC 7498).
This document aims to facilitate the usage of the 4b/10b line code in complex systems by providing the 4b/10b line code protocol. This document defines the 4b/10b line code protocol for interconnections in complex systems, mainly distributed real-time systems such as embedded systems, control systems, IoT devices, wearable devices, sensor networks, amusement systems, robot systems, and spacecraft. Specifically, the 4b/10b line code is the line code that realizes embedded clock, DC balance, error detection, and error correction at the same time, whose functions are not satisfied by a conventional single line code so that the 4b/10b line code can achieve highly reliable digital communications. The most significant feature of the 4b/10b line code is that it is a line code with error correction capability. Therefore, there is no need for error correction in the upper layers, and communication can be performed using only the 4b/10b line code in noisy environments.

Systèmes et équipements multimédias - Transmission de signaux multimédias - Code en ligne fiable avec capacité de correction d'erreurs

IEC 63455:2025 spécifie le code en ligne 4b/10b avec correction d’erreurs pour la transmission fiable de données multimédias, en particulier pour les communications en temps réel, même dans des environnements bruyants, tels que les dispositifs IdO, les dispositifs portatifs, les réseaux de capteurs, la robotique et les engins spatiaux. Il correspond aux fonctions spécifiées dans les couches 1 à 2 du modèle de référence OSI (ISO/IEC 7498).
Le présent document vise à faciliter l’utilisation du code en ligne 4b/10b dans les systèmes complexes en fournissant le protocole de code en ligne 4b/10b. Il définit le protocole de code en ligne 4b/10b pour les interconnexions dans les systèmes complexes, principalement les systèmes distribués en temps réel tels que les systèmes embarqués, les systèmes de commande, les dispositifs IdO, les dispositifs portatifs, les réseaux de capteurs, les systèmes de divertissement, les systèmes robotiques, et les engins spatiaux. Plus précisément, le code en ligne 4b/10b est celui qui réalise simultanément l’horloge intégrée, l’équilibrage du courant continu, la détection d’erreurs et la correction d’erreurs, dont les fonctions ne sont pas assumées par un seul code en ligne conventionnel, de sorte que le code en ligne 4b/10b puisse réaliser des communications numériques hautement fiables. La caractéristique la plus importante du code en ligne 4b/10b est qu’il s’agit d’un code en ligne avec une capacité de correction d’erreurs. La correction d’erreurs n’est donc pas nécessaire dans les couches supérieures et la communication peut être effectuée en utilisant uniquement le code en ligne 4b/10b dans les environnements bruyants.

General Information

• Status: Published
• Publication Date: 01-May-2025
• ICS: 33.160.60 - Multimedia systems and teleconferencing equipment
• ICS: 35.110 - Networking
• Technical Committee: TA 18 - Multimedia home systems and applications for end-user networks
• Drafting Committee: PT 63455 - TC 100/TA 18/PT 63455
• Current Stage: PPUB - Publication issued
• Start Date: 02-May-2025
• Completion Date: 23-May-2025

Standards Content (Sample)

IEC 63455 ®
Edition 1.0 2025-05
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Multimedia systems and equipment – Multimedia signal transmission –
