TEST METHODS FOR ELECTRICAL MATERIALS, PRINTED BOARDS AND
OTHER INTERCONNECTION STRUCTURES AND ASSEMBLIES –
Part 2-803: Test methods for Z-axis expansion of base materials and
printed boards
1 Scope
This part of IEC 61189 specifies a test method to determine the Z-axis expansion of base
materials and printed boards using a thermomechanical analyser (TMA).
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies.
For undated references, the latest edition of the referenced document (including any
amendments) applies.
IEC 60194-1, Printed boards design, manufacture and assembly – Vocabulary – Part 1:
Common usage in printed board and electronic assembly technologies
3 Terms and definitions
For the purposes of this document, the terms and definitions given in IEC 60194-1 apply.
ISO and IEC maintain terminological databases for use in standardization at the following
addresses:
• IEC Electropedia: available at https://www.electropedia.org/
• ISO Online browsing platform: available at https://www.iso.org/obp
4 Preparation of test specimens
Unless otherwise specified, a minimum of two specimens shall be tested. These specimens
shall be taken from random locations of the material to be evaluated.
The test specimens shall be verified to be free of particles.
5 Test specimens
Test specimens shall be unclad laminate material or a printed circuit board. Multilayer printed
boards may be tested but no internal conductors are to be present in the specimen.
All copper shall be etched from the te
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
