SIST EN 15004-8:2018

Fixed firefighting systems - Gas extinguishing systems - Part 8: Physical properties and system design of gas extinguishing systems for IG-100 extinguishant (ISO 14520-13:2015, modified)

1.1   This part of EN 15004 contains specific requirements for gaseous fire-extinguishing systems, with respect to the IG-100 extinguishant. It includes details of physical properties, specification, usage and safety aspects.
1.2   This part of EN 15004 covers systems operating at nominal pressures of 200 bar at 15 °C and 300 bar at 15 °C. This does not preclude the use of other systems, although design data for other pressures are not available at this time.

Ortsfeste Brandbekämpfungsanlagen - Löschanlagen mit gasförmigen Löschmitteln - Teil 8: Physikalische Eigenschaften und Anlagenauslegung für Löschmittel IG-100 (ISO 14520-13:2015, modifiziert)

1.1   Dieses Dokument legt Anforderungen für Löschanlagen mit gasförmigen Löschmitteln fest, bei denen IG 100 als Löschmittel angewendet wird. Es enthält Einzelheiten zu den physikalischen Eigenschaften, zur Spezifikation, zum Einsatz und zu den Sicherheitsaspekten.
1.2   Dieses Dokument ist anwendbar für Anlagen, die bei Nenndrücken von 200 bar bei 15 °C und 300 bar bei 15 °C betrieben werden. Die Anwendung anderer Anlagen ist nicht ausgeschlossen, wenngleich derzeit noch keine Auslegungsdaten für andere Drücke zur Verfügung stehen.

Installations fixes de lutte contre l’incendie - Installations d’extinction à gaz - Partie 8 : Propriétés physiques et conception des systèmes pour agent extincteur IG-100 (ISO 14520-13:2015, modifiée)

1.1   La présente partie de l'EN 15004 contient des exigences spécifiques relatives aux installations d’extinction à gaz, contenant de l’agent extincteur IG-100. Elle inclut des détails relatifs à ses propriétés physiques, sa spécification, son usage ainsi que ses aspects de sécurité.
1.2   La présente partie de l'EN 15004 traite des systèmes fonctionnant à des pressions nominales de 200 bar à 15 °C et 300 bar à 15 °C. Cela n’exclut pas l’utilisation d’autres systèmes, les données nominales pour d’autres pressions étant toutefois indisponibles au moment de la publication.

Vgrajeni gasilni sistemi - Sistemi za gašenje s plinom - 8. del: Fizikalne lastnosti in načrtovanje sistema za gašenje s plinom za gasilo IG-100 (ISO 14520-13:2015, spremenjen)

ICS:   13.220.10
1.1   Ta del standarda EN 15004 vsebuje specifične zahteve za gašenje s plinom v povezavi s sredstvom za gašenje IG-100. Vsebuje podrobnosti o fizičnih lastnostih, specifikacijah, uporabi in varnostnih vidikih.
1.2   Ta del standarda EN 15004 zajema sisteme, ki delujejo pri nazivnem tlaku 200 barov pri 15 °C in 300 barov pri 15 °C. To ne izključuje uporabe drugih sistemov, čeprav projektni podatki za druge tlake trenutno niso na voljo.

General Information

• Status: Published
• Public Enquiry End Date: 14-Oct-2016
• Publication Date: 18-Jan-2018
• ICS: 13.220.10 - Fire-fighting
• Technical Committee: POZ - Požarna varnost
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 05-Jan-2018
• Due Date: 12-Mar-2018
• Completion Date: 19-Jan-2018
• Directive: 305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
• Mandate: M/109 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on fire alarm/detection, fixed firefighting, fire and smoke control and explosion suppression products
• Ref Project: EN 15004-8:2017 - Fixed firefighting systems - Gas extinguishing systems - Part 8: Physical properties and system design of gas extinguishing systems for IG-100 extinguishant (ISO 14520-13:2015, modified)

Relations

• Replaces: SIST EN 15004-8:2008 - Fixed firefighting system - Gas extinguishing systems - Part 8: Physical properties and system design of gas extinguishing systems for IG-100 extinguishant (ISO 14520-13:2005, modified)
• Effective Date: 01-Feb-2018

Overview

EN 15004-8:2017 - Fixed firefighting systems - Gas extinguishing systems - Part 8 - specifies the physical properties and system design requirements for IG-100 extinguishant. Adopted by CEN from ISO 14520-13:2015 (modified), this European standard covers specification, usage and safety aspects for IG-100 (nitrogen) used in fixed gas extinguishing systems. It applies to systems with nominal storage pressures of 200 bar and 300 bar at 15 °C and defines agent characteristics, storage/fill pressures, extinguishing concentrations and personnel safety guidance.

Key topics

• Extinguishant identity and specification
  • IG-100 = nitrogen (chemical formula N2), molecular mass 28.02.
  • Purity ≥ 99.6% by volume; moisture ≤ 50 ppm; oxygen ≤ 0.1% by volume.
• Physical properties and quantities
  • Tables provide specific vapour volumes and the amount of IG-100 (m3/m3) required to reach target volumetric concentrations at different temperatures.
  • Extinguishing and design concentrations are specified (e.g., heptane cup-burner extinguishment ~32.3% vol; minimum design for heptane ~47.6% vol after safety factors).
• System storage and pressures
  • Applicable to containers filled to 200 bar or 300 bar at 15 °C; corresponding maximum working pressures (e.g., 240 bar for 200 bar fill at 50 °C; 360 bar for 300 bar).
  • Containers are not superpressurized.
• Safety of personnel
  • Addresses hazards from oxygen depletion and combustion products.
  • Physiological guidance: NOAEL 43% (no observed adverse effect level), LOAEL 52% (lowest observed adverse effect level) - corresponding to minimum oxygen equivalents noted in the standard.
• Environmental properties
  • IG-100 is inert with zero GWP and zero ODP.

Applications

• For designers and engineers of fixed firefighting systems specifying total‑flooding gas extinguishing systems using IG-100.
• Useful to system manufacturers, installation contractors, commissioning engineers, safety managers and regulatory authorities assessing compliance for data centers, archives, machinery enclosures and other enclosed hazards where inert gas flooding is appropriate.
• Helps calculate agent quantity, select storage pressure options (200/300 bar), determine design concentrations for Class A/B hazards, and evaluate personnel safety measures and ventilation/evacuation strategies.

Related standards

• EN 15004-1:2017 - Design, installation and maintenance (normative reference).
• ISO 14520-13:2015 - International source standard (modified for EN 15004-8).
• Other parts in the EN 15004 series cover FK‑5‑1‑12, HFCs, IG‑01, IG‑55, IG‑541, etc., under the general title “Fixed firefighting systems - Gas extinguishing systems.”

Keywords: EN 15004-8:2017, IG-100, gas extinguishing systems, fixed firefighting systems, design concentration, nitrogen extinguishant, 200 bar, 300 bar, inert gas, zero GWP.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.VSUHPHQMHQOrtsfeste Brandbekämpfungsanlagen - Löschanlagen mit gasförmigen Löschmitteln - Teil 8: Physikalische Eigenschaften und Anlagenauslegung für Löschmittel IG-100 (ISO 14520-13:2015, modifiziert)Installations fixes de lutte contre l’incendie - Installations d’extinction à gaz - Partie 8 : Propriétés physiques et conception des systèmes pour agent extincteur IG-100 (ISO 14520-13:2015, modifiée)Fixed firefighting systems - Gas extinguishing systems - Part 8: Physical properties and system design of gas extinguishing systems for IG-100 extinguishant (ISO 14520-13:2015, modified)13.220.10Gašenje požaraFire-fightingICS:Ta slovenski standard je istoveten z:EN 15004-8:2017SIST EN 15004-8:2018en,fr,de01-februar-2018SIST EN 15004-8:2018SLOVENSKI
STANDARDSIST EN 15004-8:20081DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 15004-8
December
t r s y ICS
s uä t t rä t r Supersedes EN
s w r r væ zã t r r zEnglish Version
Fixed firefighting systems æ Gas extinguishing systems æ Part
zã Physical properties and system design of gas extinguishing systems for Installations fixes de lutte contre l 5incendie æ Installations d 5extinction à gaz æ Partie
z ã Propriétés physiques et conception des systèmes pour agent
Ortsfeste Brandbekämpfungsanlagen æ Löschanlagen mit gasförmigen Löschmitteln æ Teil
zã Physikalische Eigenschaften und Anlagenauslegung für Löschmittel This European Standard was approved by CEN on
t w September
t r s yä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Serbiaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Avenue Marnix 17,
B-1000 Brussels
t r s y CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s w r r væ zã t r s y ESIST EN 15004-8:2018
...
