SIST EN 60793-1-41:2010

Optical fibres - Part 1-41: Measurement methods and test procedures - Bandwidth (IEC 60793-1-41:2010)

This part of IEC 60793 describes three methods for determining and measuring the modal bandwidth of multimode optical fibres (see IEC 60793-2-10, IEC 60793-30 series and IEC 60793-40 series). The baseband frequency response is directly measured in the frequency domain by determining the fibre response to a sinusoidaly modulated light source. The baseband response can also be measured by observing the broadening of a narrow pulse of light. The calculated response is determined using differential mode delay (DMD) data. The three methods are: • Method A - Time domain (pulse distortion) measurement • Method B - Frequency-domain measurement • Method C - Overfilled launch modal bandwidth calculated from differential mode delay (OMBc) Methods A and B can be performed using one of two launches: an overfilled launch (OFL) condition or a restricted mode launch (RML) condition. Method C is only defined for A1a.2 (and A1a.3 in preparation) multimode fibre and uses a weighted summation of DMD launch responses with the weights corresponding to an overfilled launch condition. The relevant test method and launch condition should be chosen according to the type of fibre.

Lichtwellenleiter - Teil 1-41: Messmethoden und Prüfverfahren - Bandbreite (IEC 60793-1-41:2010)

Fibres optiques - Partie 1-41: Méthodes de mesure et procédures d'essai - Largeur de bande (CEI 60793-1-41:2010)

La CEI 60793-1-41:2010 décrit trois méthodes pour déterminer et mesurer la largeur de bande modale des fibres optiques multimodales (voir CEI 60793-2-10, série CEI 60793-30 et série CEI 60793-40). La réponse en fréquence de bande de base est directement mesurée dans le domaine fréquentiel en déterminant la réponse de la fibre à une source lumineuse modulée de manière sinusoïdale. La réponse en bande de base peut aussi être mesurée en observant l'élargissement d'une impulsion étroite de lumière. La réponse calculée est déterminée en utilisant les données de retard de mode différentiel (differential mode delay - DMD). Les trois méthodes sont les suivantes:  - Methode A - Mesure dans le domaine temporel (distorsion d'impulsion)  - Methode B - Mesure dans le domaine fréquentiel   - Methode C - Largeur de bande modale d'injection saturée calculée à partir du retard de mode différentiel (OMBc).  La modification principale par rapport à la précédente édition est l'addition d'une troisième méthode pour la détermination de la largeur de bande modale fondée sur les données de DMD et afin d'améliorer les procédures de mesure pour les fibres A4. Il convient d'utiliser cette norme conjointement à la CEI 60793-1-1 et à la CEI 60793-1-2, qui couvrent les spécifications génériques.

Optična vlakna - 1-41. del: Metode merjenja in preskusni postopki Pasovna širina (IEC 60793-1-41:2010)

Ta del IEC 60793 opisuje tri metode za določanje in merjenje modalne pasovne širine večrodovnih optičnih vlaken (glej IEC 60793-2-10, serijo IEC 60793-30 in serijo IEC 60793-40). Frekvenčni odziv osnovnega frekvenčnega pasu se meri neposredno v frekvenčni domeni z ugotavljanjem odziva vlaken na sinusoidno modulirani svetlobni vir. Odziv osnovnega frekvenčnega pasu se lahko meri tudi z opazovanjem širjenja ozkega svetlobnega impulza. Izračunani odziv se določi s podatki o diferenčni zakasnitvi rodov (DMD). Tri metode so: • Metoda A – meritev časovne domene (popačenje impulza) • Metoda B – merjenje frekvenčne domene • Metoda C – prenapolnjena zagonska modalna pasovna širina, izračunana iz diferenčne zakasnitve rodov (OMBc) Metodi A in B se lahko izvajata z uporabo enega od dveh zagonov: s prenapolnjenim stanjem pred začetkom proizvodnje (OFL) ali s stanjem pred začetkom proizvodnje v omejenem načinu (RML). Metoda C je definirana le za večrodovna optična vlakna A1a.2 (in A1a.3 v pripravi) in uporablja uteženo seštevanje zagonskih odzivov DMD z utežmi, ki ustrezajo prenapolnjenemu zagonu. Glede na vrsto vlakna se izbereta ustrezna preskusna metoda in stanje pred začetkom proizvodnje.
