SIST EN 50483-5:2026

Test requirements for low voltage aerial bundled cable accessories - Part 5: Electrical ageing test

The EN 50483 series applies to overhead line fittings for tensioning, supporting and connecting aerial bundled cables (ABC) of rated voltage U0/U (Um): 0,6/1 (1,2) kV.
This document applies to the connections described in EN 50483-4, including branch connectors, Insulation Piercing Connectors (IPC), pre-insulated lugs (terminals) and through pre-insulated connectors (sleeves).
Two classes of connectors are covered by this document:
-   Class A: These are connectors intended for electricity distribution or industrial networks in which they can be subjected to short-circuits of relatively high intensity and duration. As a consequence, Class A connectors will be suitable for the majority of applications.
-   Class B: These are connectors for networks in which overloads or short-circuits are rapidly cleared by the operation of protection devices.
Depending on their application, the connectors are subjected to heat cycles and short-circuit current tests.
Class A: the connectors are subjected to heat cycles and short-circuit current tests.
Class B: the connectors are subjected to heat cycles only.
The object of this document is to define the heating cycles test methods and requirements which apply to compression through connectors, insulation piercing connectors and all other type of connections for low voltage aerial bundled cables.

Prüfanforderungen für Bauteile für isolierte Niederspannungsfreileitungen - Teil 5: Elektrische Alterungsprüfungen

Prescriptions relatives aux essais des accessoires pour réseaux aériens basse tension torsadés - Partie 5: Essai de vieillissement électrique

Zahteve za preskušanje pribora za nizkonapetostne izolirane nadzemne kable - 5. del: Preskus električnega staranja

Serija EN 50483 se nanaša na opremo za nadzemne vodnike za napenjanje, podporo in povezovanje zračnih snopov kablov (ABC) z nazivno napetostjo U0/U (Um): 0,6/1 (1,2) kV.
Ta dokument se uporablja za povezave, opisane v EN 50483-4, vključno z odcepnimi konektorji, izolacijskimi prebojnimi konektorji (IPC), predizoliranimi čepi (terminali) in skozi predizolirane konektorje (rokavi).
Ta dokument zajema dva razreda konektorjev:
- Razred A: To so konektorji namenjeni distribucijskim ali industrijskim omrežjem, v katerih so lahko izpostavljeni kratkostičnim tokovom z relativno visoko intenzivnostjo in trajanjem. Posledično bodo konektorji razreda A primerni za večino aplikacij.
- Razred B: To so konektorji za omrežja, v katerih se preobremenitve ali kratki stiki hitro odpravijo z delovanjem zaščitnih naprav.
Glede na njihovo uporabo so konektorji podvrženi toplotnim ciklom in preskusom kratkostičnega toka.
Razred A: konektorji so podvrženi toplotnim ciklom in preskusom kratkostičnega toka.
Razred B: konektorji so podvrženi samo toplotnim ciklom.
Namen tega dokumenta je opredeliti metode preskušanja toplotnih ciklov in zahteve, ki se uporabljajo za kompresijske skozi konektorje, izolacijske prebojne konektorje in vse druge vrste povezav za nizkonapetostne zračne snopove kablov.
