SIST EN ISO 887:2002

Plain washers for metric bolts, screws and nuts for general purposes - General plan (ISO 887:2000)

Flache Scheiben für metrische Schrauben und Muttern für allgemeine Anwendungen - Allgemeine Übersicht (ISO 887:2000)

Diese Internationale Norm enthält Festlegungen für den gesamten Bereich der Nennmaße von flachen Scheiben der Produktklassen A und C für Schrauben und Muttern mit Gewinde-Nenndurchmessern von 1 mm bis 150 mm für allgemeine Anwendungen. Diese Internationale Norm gilt bezüglich der Lochdurchmesser und Dicken nicht für flache Scheiben für Kombi-Schrauben. Hinweise für die Anwendung flacherScheiben gibt der informative Anhang A.

Rondelles plates pour vis et écrous métriques pour usages généraux - Plan général (ISO 887:2000)

La présente Norme internationale spécifie la gamme complète de dimensions nominales des rondelles plates de grades A et C pour vis et écrous de diamètre nominal de filetage de 1 mm à 150 mm inclus pour usages généraux.La présente Norme internationale n'est pas applicable aux rondelles pour les vis avec rondelle incorporée pour ce qui est des diamètres et des épaisseurs de trous de passage.L'information sur l'emploi des rondelles plates est donnée dans l'annexe A.

Okrogle ravne podložke za metrske vijake in matice za splošno rabo - Splošni pregled (ISO 887:2000)

General Information

• Status: Published
• Publication Date: 30-Jun-2002
• ICS: 21.060.30 - Washers, locking elements
• Technical Committee: ISEL - Mechanical elements
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Jul-2002
• Due Date: 01-Jul-2002
• Completion Date: 01-Jul-2002
• Ref Project: EN ISO 887:2000 - Plain washers for metric bolts, screws and nuts for general purposes - General plan (ISO 887:2000)

Relations

• Corrected By: SIST EN ISO 887:2002/AC:2006 - Plain washers for metric bolts, screws and nuts for general purposes - General plan (ISO 887:2000)
• Effective Date: 22-Dec-2008

Standards Content (Sample)

SLOVENSKI STANDARD
SIST EN ISO 887:2002
01-julij-2002
Okrogle ravne podložke za metrske vijake in matice za splošno rabo - Splošni
pregled (ISO 887:2000)

Plain washers for metric bolts, screws and nuts for general purposes - General plan (ISO

887:2000)
Flache Scheiben für metrische Schrauben und Muttern für allgemeine Anwendungen -
Allgemeine Übersicht (ISO 887:2000)

Rondelles plates pour vis et écrous métriques pour usages généraux - Plan général (ISO

887:2000)
Ta slovenski standard je istoveten z: EN ISO 887:2000
ICS:
21.060.30 Podložke, varovalni elementi Washers, locking elements
SIST EN ISO 887:2002 en

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------
SIST EN ISO 887:2002
---------------------- Page: 2 ----------------------
SIST EN ISO 887:2002
---------------------- Page: 3 ----------------------
SIST EN ISO 887:2002
---------------------- Page: 4 ----------------------
SIST EN ISO 887:2002
---------------------- Page: 5 ----------------------
SIST EN ISO 887:2002
---------------------- Page: 6 ----------------------
SIST EN ISO 887:2002
INTERNATIONAL ISO
STANDARD 887
Second edition
2000-06-15
Plain washers for metric bolts, screws and
nuts for general purposes — General plan
Rondelles plates pour vis et écrous métriques pour usages généraux —
Plan géneral
Reference number
ISO 887:2000(E)
ISO 2000
---------------------- Page: 7 ----------------------
SIST EN ISO 887:2002
ISO 887:2000(E)
PDF disclaimer

This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but shall not

be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In downloading this

file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat accepts no liability in this

area.
Adobe is a trademark of Adobe Systems Incorporated.

Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation parameters

were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In the unlikely event

that a problem relating to it is found, please inform the Central Secretariat at the address given below.

© ISO 2000

All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronic

or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or ISO's member body

in the country of the requester.
ISO copyright office
Case postale 56 � CH-1211 Geneva 20
Tel. + 41 22 749 01 11
Fax + 41 22 734 10 79
E-mail [e-mail]
Web www.iso.ch
Printed in Switzerland
ii © ISO 2000 – All rights reserved
---------------------- Page: 8 ----------------------
SIST EN ISO 887:2002
ISO 887:2000(E)
Foreword

ISO (the International Organization for Standardization) is a worldwide federation of national standards bodies (ISO

member bodies). The work of preparing International Standards is normally carried out through ISO technical

committees. Each member body interested in a subject for which a technical committee has been established has

the right to be represented on that committee. International organizations, governmental and non-governmental, in

liaison with ISO, also take part in the work. ISO collaborates closely with the International Electrotechnical

Commission (IEC) on all matters of electrotechnical standardization.

International Standards are drafted in accordance with the rules given in the ISO/IEC Directives, Part 3.

Draft International Standards adopted by the technical committees are circulated to the member bodies for voting.

Publication as an International Standard requires approval by at least 75 % of the member bodies casting a vote.

Attention is drawn to the possibility that some of the elements of this International Standard may be the subject of

patent rights. ISO shall not be held responsible for identifying any or all such patent rights.

International Standard ISO 887 was prepared by Technical Committee ISO/TC 2, Fasteners.

This second edition cancels and replaces the first edition (ISO 887:1983), which has been technically revised.

Annex A of this International Standard is for information only.
© ISO 2000 – All rights reserved iii
---------------------- Page: 9 ----------------------
SIST EN ISO 887:2002
---------------------- Page: 10 ----------------------
SIST EN ISO 887:2002
INTERNATIONAL STANDARD ISO 887:2000(E)
Plain washers for metric bolts, screws and nuts for general
purposes — General plan
1 Scope

This International Standard specifies the full range of the nominal dimensions of product-grade-A and -C plain

washers for general-purpose bolts, screws and nuts of nominal thread diameters ranging from 1 mm to 150 mm

inclusive.

This International Standard is not applicable to washers for screw and washer assemblies in relation to hole

diameters and thicknesses.
Information on the use of plain washers is given in annex A.
2 Normative reference

The following normative document contains provisions which, through reference in this text, constitute provisions of

this International Standard. For dated references, subsequent amendments to, or revisions of, any of these

publications do not apply. However, parties to agreements based on this International Standard are encouraged to

investigate the possibility of applying the most recent edition of the normative document indicated below. For

undated references, the latest edition of the normative document referred to applies. Members of ISO and IEC

maintain registers of currently valid International Standards.
ISO 273:1979, Fasteners — Clearance holes for bolts and screws.
3 Clearance holes

The clearance hole diameters d for washers (see Figure 1) shall be chosen in accordance with those specified in

ISO 273, as follows:

� fine series for washers of product grade A and with a nominal thickness of less than 6 mm, i.e. for nominal

sizes < 39 mm;

� medium series for washers of product grade A with a nominal thickness equal to or greater than 6 mm, i.e. for

nominal sizesW 39 mm and fo
...
