SIST EN 60819-3-4:2014

Non-cellulosic papers for electrical purposes - Part 3: Specifications for individual materials - Sheet 4: Aramid fibre paper containing not more than 50 % of mica particles

EN IEC 60819-3-4 specifies requirements for two types of aramid fibre paper containing mica particles and designated as PAaM. - type 1: calendered aramid paper containing mica particles; - type 2: uncalendered aramid paper containing mica particles. Materials which conform to this specification meet established levels of performance. However, the selection of material by a user for a specific application should be based on the actual requirements necessary for adequate performance in that application and not based on this specification alone. SAFETY WARNING: It is the responsibility of the user of the methods contained or referred to in this document to ensure that they are used in a safe manner.

Zellulosefreie Papiere für elektrotechnische Zwecke - Teil 3: Bestimmungen für einzelne Materialien - Blatt 4: Papier aus Aramidfaser mit einem Glimmeranteil von nicht mehr als 50 %

Papiers non cellulosiques pour usages électriques - Partie 3: Spécifications pour matériaux particuliers - Feuille 4: Papiers en fibres aramide ne contenant pas plus de 50 % de particules de mica

L'IEC 60819-3-4:2013 spécifie des exigences pour deux types de papier en fibre aramide contenant des particules de mica et désignés PAaM:  - type 1: papier aramide calendré contenant des particules de mica;  - type 2: papier aramide non calendré contenant des particules de mica. Les matériaux conformes à cette spécification satisfont à des niveaux établis de performance. Cependant, il convient que le choix du matériau par un utilisateur et pour une application particulière soit fondé sur les exigences réelles nécessaires pour obtenir les performances satisfaisantes pour cette application, et non pas fondé uniquement sur la présente spécification. AVERTISSEMENT DE SÉCURITÉ: Il est de la responsabilité de l'utilisateur de s'assurer que les méthodes présentées ou référencées dans le présent document sont utilisées de manière sûre. Cette deuxième édition annule et remplace la première édition parue en 2001. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente: le document a été mis à jour en incluant de nouvelles épaisseurs et les valeurs correspondantes du Tableau 1. Mots clés: papier en fibre aramide contenant des particules de mica, PAaM, calendré, non calendré

Necelulozni papirji za elektrotehniko - 3. del: Specifikacije za posamezne materiale - 4. list: Papir z aramidnimi vlakni z največ 50 % sljudnih delcev (IEC 60819-3-4:2013)

Standard EN IEC 60819-3-4 določa zahteve za dve vrsti papirja z aramidnimi vlakni, ki vsebujejo sljudne delce in so označeni kot PAaM. – vrsta 1: stisnjeni aramidni papir, ki vsebuje sljudne delce, – vrsta 2: nestisnjeni aramidni papir, ki vsebuje sljudne delce. Materiali, ki so skladni s to specifikacijo, ustrezajo določenim ravnem delovanja. Vendar mora uporabnik material za določeno uporabo izbrati glede na dejanske zahteve za zadostno učinkovitost pri tej uporabi, ne samo na podlagi te specifikacije. VARNOSTNO OPOZORILO: Končni uporabnik je odgovoren za varno uporabo metod, ki so zajete ali omenjene v tem dokumentu.

General Information

• Status: Published
• Publication Date: 29-May-2014
• ICS: 29.035.10 - Paper and board insulating materials
• Technical Committee: IIZS - Insulating materials and systems
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 13-May-2014
• Due Date: 18-Jul-2014
• Completion Date: 30-May-2014
• Ref Project: EN 60819-3-4:2014 - Non-cellulosic papers for electrical purposes - Part 3: Specifications for individual materials - Sheet 4: Aramid fibre paper containing not more than 50 % of mica particles

Relations

• Replaces: SIST EN 60819-3-4:2002 - Non-cellulosic papers for electrical purposes -- Part 3: Specifications for individual materials -- Sheet 4: Aramid fibre paper containing not more than 50 % of mica particles
• Effective Date: 25-Sep-2012
• Replaces: SIST EN 60819-3-4:2002 - Non-cellulosic papers for electrical purposes -- Part 3: Specifications for individual materials -- Sheet 4: Aramid fibre paper containing not more than 50 % of mica particles
• Effective Date: 29-Jan-2023
• Revised: SIST EN 60819-3-4:2002 - Non-cellulosic papers for electrical purposes -- Part 3: Specifications for individual materials -- Sheet 4: Aramid fibre paper containing not more than 50 % of mica particles
• Effective Date: 06-May-2014

Standards Content (Sample)

SLOVENSKI STANDARD
SIST EN 60819-3-4:2014
01-julij-2014
1DGRPHãþD
SIST EN 60819-3-4:2002
1HFHOXOR]QLSDSLUML]DHOHNWURWHKQLNRGHO6SHFLILNDFLMH]DSRVDPH]QHPDWHULDOH
OLVW3DSLU]DUDPLGQLPLYODNQL]QDMYHþVOMXGQLKGHOFHY,(&

Non-cellulosic papers for electrical purposes - Part 3: Specifications for individual
materials - Sheet 4: Aramid fibre paper containing not more than 50 % of mica particles
Papiers non cellulosiques pour usages électriques - Partie 3: Spécifications pour
matériaux particuliers - Feuille 4: Papiers en fibres aramide ne contenant pas plus de 50
% de particules de mica
Ta slovenski standard je istoveten z: EN 60819-3-4:2014
ICS:
29.035.10 Papirni in kartonski izolacijski Paper and board insulating
materiali materials
SIST EN 60819-3-4:2014 en
