SIST EN 13179-1:2013

Tests for filler aggregate used in bituminous mixtures - Part 1: Delta ring and ball test

This European Standard specifies the procedure used to determine the stiffening effect of filler aggregate when mixed with bitumen.

Prüfverfahren für mineralische Füller in bitumenhaltigen Mischungen - Teil 1: Delta-Ring- und Kugel-Verfahren

Diese Europäische Norm legt das Verfahren für die Bestimmung der versteifenden Wirkung mineralischer Füller fest, wenn sie mit Bitumen gemischt werden.

Essais sur les fillers utilisés dans les mélanges bitumineux - Partie 1: Essai bille-anneau

La présente norme européenne spécifie le mode opératoire permettant de déterminer le pouvoir rigidifiant des fillers mélangés au bitume.

Preskus kamene moke za bitumenske zmesi - 1. del: Delta preskus prstan-kroglica

Ta evropski standard določa postopek, ki se uporablja za določevanje utrditvenega učinka kamene moke, ko je zmešana z bitumnom.

General Information

• Status: Published
• Public Enquiry End Date: 19-Mar-2013
• Publication Date: 15-Sep-2013
• ICS: 75.140 - Waxes, bituminous materials and other petroleum products
• Technical Committee: AGR - Aggregates
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 05-Sep-2013
• Due Date: 10-Nov-2013
• Completion Date: 16-Sep-2013
• Ref Project: EN 13179-1:2013 - Tests for filler aggregate used in bituminous mixtures - Part 1: Delta ring and ball test

Relations

• Replaces: SIST EN 13179-1:2002 - Tests for filler aggregate used in bituminous mixtures - Part 1: Delta ring and ball test
• Effective Date: 01-Oct-2013

Overview: EN 13179-1:2013 - Delta ring and ball test for filler aggregate

EN 13179-1:2013 (CEN) specifies the laboratory procedure to assess the stiffening effect of filler aggregate when mixed with bitumen. Known as the Delta ring and ball (∆ R & B) test, it measures the increase in bitumen softening point caused by mineral filler in a 37.5 vol% filler / 62.5 vol% bitumen mixture. The result is reported as ∆R & B and is used in quality control and materials characterization for bituminous mixtures and asphalt production.

Key topics and technical requirements

• Scope: Determines stiffening effect of fillers in bituminous mixtures; part of a series of tests for bituminous bound filler aggregates.
• Principle: Duplicate brass rings are cast with pure bitumen and with bitumen+filler; disks are heated and the softening point is determined by the Ring & Ball procedure (steel ball drops 25.0 ± 0.4 mm).
• Sample preparation
  • Use filler aggregate < 0.125 mm; test portion mass ≥ 60 g.
  • Dry to constant mass (110 ± 5 °C) and determine particle density (EN 1097-7).
• Mix composition and dosing
  • Volume ratio: 37.5% filler : 62.5% bitumen.
  • Filler mass calculated as mf = 0.6 × mb × f / b (mb = bitumen mass; f = filler particle density; b = bitumen density; use 1.025 Mg/m3 if unknown).
• Apparatus and conditions
  • Oven at (150 ± 5) °C for heating; stirring at controlled temperatures; brass rings per EN 1427.
  • Balance accuracy 0.1 g; 0.125 mm test sieve.
• Results and reporting
  • Calculate mean softening points for bitumen and mixture; report difference rounded to nearest 0.5 °C as ∆R & B.
  • If mixture cannot be homogenized due to extreme stiffening, record result as “greater than 25 °C”.
  • Repeat test if duplicate differences exceed 3 °C.
• Quality rules: Follow EN 932-5 requirements for equipment; include specified test report data.

Applications and users

• Asphalt and bituminous mix designers evaluating filler effects on binder stiffness.
• Aggregate laboratories, materials testing labs, and paving contractors performing production and acceptance testing.
• Quality control in hot mix asphalt (HMA) manufacturing, specification compliance, and research into filler–bitumen interactions.
• National standards bodies and certification laboratories adopting CEN methods.

Related standards

• EN 13179-2 (Bitumen number)
• EN 1427 (Ring and Ball softening point)
• EN 1097-7 (particle density of filler)
• EN 932, EN 933, EN 1097, EN 1367, EN 1744 (aggregate test series)

Keywords: EN 13179-1:2013, Delta ring and ball test, filler aggregate, bituminous mixtures, stiffening effect, ∆R & B, bitumen softening point, CEN.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Preskus kamene moke za bitumenske zmesi - 1. del: Delta preskus prstan-kroglicaPrüfverfahren für mineralische Füller in bitumenhaltigen Mischungen - Teil 1: Delta-Ring- und Kugel-VerfahrenEssais sur les fillers utilisés dans les mélanges bitumineux - Partie 1: Essai bille-anneauTests for filler aggregate used in bituminous mixtures - Part 1: Delta ring and ball test75.140Voski, bitumni in drugi naftni proizvodiWaxes, bituminous materials and other petroleum productsICS:Ta slovenski standard je istoveten z:EN 13179-1:2013SIST EN 13179-1:2013en,fr,de01-oktober-2013SIST EN 13179-1:2013SLOVENSKI
STANDARDSIST EN 13179-1:20021DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 13179-1
July 2013 ICS 75.140 Supersedes EN 13179-1:2000English Version
Tests for filler aggregate used in bituminous mixtures - Part 1: Delta ring and ball test
Essais sur les fillers utilisés dans les mélanges bitumineux - Partie 1: Essai bille-anneau
Prüfverfahren für mineralische Füller in bitumenhaltigen Mischungen - Teil 1: Delta-Ring- und Kugel-Verfahren This European Standard was approved by CEN on 30 May 2013.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2013 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 13179-1:2013: ESIST EN 13179-1:2013

EN 13179-1:2000: Clause 7 has been completed by the following sentence: "For some types of filler, the stiffening effect may make the mixture of filler and bitumen so stiff that a homogeneous mixture cannot be obtained by stirring for the specified time. If a homogenous mixture cannot be obtained, the test shall be stopped. The result shall be recorded (9.1 (b)) as “greater than 25 °C”. The other part of EN 13179 are: Part 2: Bitumen number. This standard forms part of series of tests for bituminous bound filler aggregates. Test methods for other properties of aggregates will be covered by parts of the following European Standards: EN 932, Tests for general properties of aggregates EN 933, Tests for geometrical properties of aggregates EN 1097, Tests for mechanical and physical properties of aggregates EN 1367, Tests for thermal and weathering properties of aggregates EN 1744, Tests for chemical properties of aggregates According to the CEN-CENELEC Internal Regulations, the national standards organisations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom.
1 Scope This European Standard specifies the procedure used to determine the stiffening effect of filler aggregate when mixed with bitumen. 2 Normative references The following documents, in whole or in part, are normatively referenced in this document and are indispensable for its application. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 932-2, Tests for general properties of aggregates — Part 2: Methods for reducing laboratory samples EN 932-5, Tests for general properties of aggregates — Part 5: Common equipment and calibration EN 1097-7, Tests for mechanical and physical properties of aggregates — Part 7: Determination of the particle density of fi
...
