SIST EN ISO 5620-1:2000

Shipbuilding and marine structures - Filling connection for drinking water tanks - Part 1: General requirements (ISO 5620-1:1992)

Specifies the general requirements, the composition and the designation of the complete drinking water filling connection aboard ships for attachment of piping from another ship or from a land distribution system and gives a recommendation for the installation aboard ships.

Schiffbau und Meerestechnik - Übernahme-Flanschanschluß für Trinkwassertanks - Teil 1: Allgemeine Anforderungen (ISO 5620-1:1992)

ISO 5620 legt den Trinkwasseranschluß an Bord von Schiffen für den Anschluß von Leitungen fest, die von einem anderen Schiff oder von einem Verteilungssystem an Land kommen. Dieser Teil von ISO 5620 legt die allgemeinen Anforderungen, die Zusammenstellung und die Bezeichnung des vollständigen Übernahme-Flanschanschlusses fest und gibt Empfehlungen für den Einbau an Bord. Anmerkung 1: Die Einzelheiten der Einzelteile des Übernahme-Flanschanschlusses, sowohl für die abgegebende Seite wie für das Schiff, sind in ISO 5620-2 festgelegt.

Construction navale et structures maritimes - Raccordement de remplissage des réservoirs a eau potable - Partie 1: Exigences générales (ISO 5620-1:1992)

L'ISO 5620 prescrit le raccordement en eau potable à bord des navires, assurant la liaison avec le tuyautage d'un autre navire ou un réseau de distribution terrestre. La présente partie de l'ISO 5620 prescrit les exigences générales, la composition et la désignation du raccordement de remplissage complet et donne des recommandations pour son installation à bord du navire.
NOTES 1 Le détail des éléments composant le raccordement de remplissage, tant pour le réseau de distribution que pour le navire, est donné dans l'ISO 5620-2. 2 Les règles générales pour les systèmes de distribution d'eau potable sont du ressort des autorités portuaires nationales et sortent du cadre de l'ISO 5620. Le raccordement prescrit dans l'ISO 5620 est destiné à empêcher le remplissage des réservoirs à eau potable du navire avec un autre liquide. En outre, il empêche la pollution du tuyautage d'eau potable par d'autres liquides.
NOTES 3 L'ISO 5620 est également applicable aux bateaux de navigation intérieure, après accord entre utilisateurs. 4 L'attention des utilisateurs est attirée sur le fait que, tout en satisfaisant aux exigences de l'lSO 5620, il convient qu'ils respectent aussi les prescriptions légales, règles et règlements applicables au type de navire concerné.

Shipbuilding and marine structures - Filling connection for drinking water tanks - Part 1: General requirements (ISO 5620-1:1992)

General Information

• Status: Published
• Publication Date: 30-Nov-2000
• ICS: 47.020.30 - Piping systems
• Technical Committee: SS SPL - Technical Board for the general field
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Dec-2000
• Due Date: 01-Dec-2000
• Completion Date: 01-Dec-2000
• Ref Project: EN ISO 5620-1:1996 - Shipbuilding and marine structures - Filling connection for drinking water tanks - Part 1: General requirements (ISO 5620-1:1992)

Overview

EN ISO 5620-1:1996 (ISO 5620-1:1992) - "Shipbuilding and marine structures - Filling connection for drinking water tanks - Part 1: General requirements" specifies the general requirements, composition and designation of a complete filling connection for drinking water tanks aboard ships. The standard defines the connection used for attachment of piping or hoses from another ship or a land distribution system, and gives recommendations for shipboard installation to safeguard drinking water from contamination.

Key topics and technical requirements

• Connection principle: Uses special ship watering flanges with a five-point connection for mating.
• Nominal sizes/ratings: Flange and piping nominal diameter DN 65 and nominal pressure PN 16 are specified.
• Materials and strength: Flange connections must be made of weldable steel with minimum tensile strength of 360 MPa.
• Corrosion protection: Requires hot-dip galvanizing in accordance with ISO 1461 or alternative coatings that do not constitute a health hazard.
• Sealing: A gasket of material suitable for drinking water systems must be fitted to the ship watering flange.
• Security: The blind flange on the ship’s side is to be secured with a corrosion‑resistant padlock fitted to a securing bolt; components such as securing chain and stud-bolts are detailed.
• Composition and designation: The complete connection is designated by elements including the part number (ISO 5620-1) and a code letter for composition (example: Code Z). Detailed component specifications are in ISO 5620-2.
• Installation recommendation: The flange connection should be installed in a suspended position, with a bent pipe recommended to facilitate safe filling and drainage.

Applications and practical value

• Standardizes the interface for shipboard drinking water filling, enabling safe and interchangeable connections between ships and shore supply systems.
• Prevents cross‑contamination of drinking water tanks and supply piping by ensuring secure blind flanges, proper gasket materials and corrosion‑resistant finishes.
• Useful for design, procurement and inspection of ship piping systems, shipyards, ship operators, marine engineers, and component manufacturers supplying watering flanges, gaskets, padlocks and related fittings.

Who would use this standard

• Shipbuilders and naval architects specifying potable water systems.
• Marine engineers and ship operators implementing safe filling points.
• Manufacturers and suppliers of maritime piping components and flanges.
• Port and regulatory authorities assessing compliance for shipboard water connections.

Related standards

• ISO 5620-2 (Components) - details individual parts referenced by Part 1.
• ISO 1461 - hot-dip galvanized coatings.
• ISO 2553 - symbolic representation of welded joints (referenced for weld depiction).

Keywords: EN ISO 5620-1:1996, filling connection, drinking water tanks, shipbuilding, marine structures, watering flange, DN 65, PN 16, hot-dip galvanizing, ISO 5620-2.

Standards Content (Sample)

SLOVENSKI STANDARD
01-december-2000
Shipbuilding and marine structures - Filling connection for drinking water tanks -
Part 1: General requirements (ISO 5620-1:1992)
Shipbuilding and marine structures - Filling connection for drinking water tanks - Part 1:
General requirements (ISO 5620-1:1992)
Schiffbau und Meerestechnik - Übernahme-Flanschanschluß für Trinkwassertanks - Teil
1: Allgemeine Anforderungen (ISO 5620-1:1992)
Construction navale et structures maritimes - Raccordement de remplissage des
réservoirs a eau potable - Partie 1: Exigences générales (ISO 5620-1:1992)
Ta slovenski standard je istoveten z: EN ISO 5620-1:1996
ICS:
47.020.30 Sistemi cevi Piping systems
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

INTERNATIONAL
ISO
STANDARD
First edi tion
19924 2-01
Shipbuilding and marine structures - Fiiling
connection for drinking water tanks -
Bart 1:
General requirements
Construction navale et structures maritimes
Raccordement de
rempiissage des rhervoirs a eau potable -
Partie 1: Exigences ghkales
Reference number
ISO 56204 : 1992( E)
ISO 5620=1:1992(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide
federation of national Standards bodies (ISO member bodies). The work
of preparing International Standards is normally carried out through ISO
technical committees. Esch member body interested in a subject for
which a technical committee has been established has the right to be
represented on that committee. International organizations, govern-
mental and non-governmental, in liaison with ISO, also take part in the
work. ISO collaborates closely with the International Electrotechnical
Commission (IEC) on all matters of electrotechnical standardization.
Draft International Standards adopted by the technical committees are
circulated to the member bodies for voting. Publication as an Inter-
national Standard requires approval by at least 75 % of the member
bodies casting a vote.
International Standard ISO 56204 was prepared by Technical Committee
ISO/TC 8, Shipbuiiding and marine structures.
This first edition of ISO 56204 together with ISO 5620-2 cancel and re-
place the first edition of ISO 5620, of which they constitute a technical
revision.
ISO 5620 consists of the following park, under the general title
Shipbuilding and marine structures - Filling connection for drinking
water tanks:
- Part 1: General requirements
- Part 2: Components
0 ISO 1992
All rights reserved. No part of this publication may be reproduced or utilized in any form
or by any means, electronie or mechanical, including photocopying and microfilm, without
Permission in writing from the publisher.
International Organkation for Standardization
Case Postale 56 0 CH-1211 Genkve 20 l Switzerland
Printed in Switzerland
ii
ISO 5620=1:1992(E)
INTERNATIONAL STANDARD
Shipbuilding and marine structures - Fiiling connection for
drinking water tanks -
Part 1:
General requirements
4 Users of ISO 5620 should note that, while observing
1 Scope
the requirements of the Standard, they should at the same
time ensure compliance with such statutary requirements,
ISO 5620 specifies the drinking water connection
rules and regulations as may apply to the individual ship
aboard ships for attachment of piping from another
concerned.
ship or from a land distribution System.
This patt of ISO 5620 specifies the general require-
ments, the composition and the designation of the
2 Normative references
complete filling connection and gives a recommen-
dation for the installation aboard ships.
The following Standards contain provisions which,
NOTES
through reference in this text, constitute provisions
of this part of ISO 5620. At the time of publication,
1 Details for the components of the filling connection are
the editions indicated were valid. All Standards are
given in ISO 5620-2, both for the distribution System and
subject to revision, and
...
