1 Scope
This document specifies the requirements for uncoated high strength steel strands or zinc or zinc alloy
1)
coated high strength steel strands, encapsulated with a protection product and a sheath .
The intended use of these products is mainly the prestressing of concrete.
NOTE These products can also be used in other stress applications in the construction field (e.g. stay cables
for bridges) where the protection of the products is not removed in use.
The standard applies only to products as supplied by the producer.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
EN 728, Plastics piping and ducting systems — Polyolefin pipes and fittings — Determination of oxidation
induction time
EN 10020, Definition and classification of grades of steel
prEN 10138-1, Prestressing steels — Part 1: General requirements
prEN 10138-3, Prestressing steels — Part 3: Strand
EN 10204, Metallic products — Types of inspection documents
prEN 10337, Zinc and zinc alloy coated prestressing steel wires and strands
prEN 10369-2, Prestressing steels — Protected and sheathed strands for prestressing — Part 2: Sliding
strands
prEN 10369-3, Prestressing steels — Protected and sheathed strands for prestressing — Protected and
sheathed high strength steel strands — Part 3: Adherent strands
EN ISO 175, Plastics — Methods of test for the determination of the effects of immersion in liquid
chemicals (ISO 175:2010)
EN ISO 527-1, Plastics — Determination of tensile properties — Part 1: General principles (ISO 527-1)
EN ISO 527-2, Plastics — Determination of tensile properties — Part 2: Test conditions for moulding and
extrusion plastics (ISO 527-2)
EN ISO 4892-2, Plastics — Methods of exposure to laboratory light sources — Part 2: Xenon-arc lamps
(ISO 4892-2)
EN ISO 9227, Corrosion tests in artificial atmospheres — Salt spray tests (ISO 9227)
1)
The word "sheath" used in the present document does not cover the sheaths as stated in mandate M/115 and
specified in EN 523.
5
---------------------- Page: 7 ----------------------
oSIST prEN 10369-1:2019
prEN 10369-1:2019 (E)
EN ISO 10304-1, Water quality — Determination of dissolved anions by liquid chromatography of ions —
Part 1: Determination of bromide, chloride, fluoride, nitrate, nitrite, phosphate and sulfate (ISO 10304-1)
EN ISO 10304-4, Water quality — Determination of dissolved anions by liquid chromatography of ions —
Part 4: Determination of chlorate, chloride and chlorite in water with low contamination (ISO 10304-4)
EN ISO 15630-3, Steel for the reinforcement and prestressing of concrete — Test methods — Part 3:
Prestressing steel (ISO 15630-3)
ISO 1183-1, Plastics — Methods for determining the density of non-cellular plastics — Part 1: Immersion
method, liquid pyknometer method and titration method
ISO 2137, Petroleum products and lubricants — Determination of cone penetration of lubricating greases
and petrolatum
ISO 2176, Petroleum products — Lubricating grease — Determination of dropping point
ISO 2207, Petroleum waxes — Determination of congealing point
ISO 6964, Polyolefin pipes and fittings — Determination of carbon black content by calcination and
pyrolysis — Test method
ISO 18553, Method for the assessment of the degree of pigment or carbon black dispersion in polyolefin
pipes, fittings and compounds
BS 2000-121, Methods of test for petroleum and its products — Determination of oil separation from
lubricating grease — Pressure filtration method
DIN 51451, Testing of petroleum products and related products — Analysis by infrared spectrometry —
General working principles
NF M 07-023, Liquid fuels — Determination of chlorides in crude petroleum and petroleum products
NF T 60-191, Petroleum products and lubricating greases — Oil separation on storage of grease — Static
conditions under pressure
ASTM D95, Standard Test Method for Water in Petroleum Products and Bituminous Materials by
Distillation
ASTM D942, Standard Test Method for Oxidation Stability of Lubricating Greases by the Oxygen Pressure
Vessel Method
3 Terms and definitions
For the purposes of this document, the terms and definitions given in prEN 10138-1 and prEN 10337
and the following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at http://www.electropedia.org/
— ISO Online browsing platform: available at http://www.iso.org/obp
6
---------------------- Page: 8 ----------------------
oSIST prEN 10369-1:2019
prEN 10369-1:2019 (E)
3.1
uncoated strand
strand consisting of uncoated high strength steel wires in accordance with prEN 10138-1 and
prEN 10138-3
3.2
zinc or zinc alloy coated prestressing strand
strand consisting of zinc or zinc alloy hot-dip coated high strength steel wires in accordance with prEN
10337
3.3
protected and sheathed strand
uncoated or zinc or zinc alloy coated strand encapsulated with a protection product and a sheath
A distinction is made between:
3.3.1
sliding protected and sheathed strand (type S)
protected and sheathed strand for which the protection product allows a movement between the sheath
and strand by application of a specified force
3.3.2
adherent protected and sheathed strand (type A)
protected and sheathed strand for which an adherence between the sheath and strand restricts their
relative movement until a specified minimum force is reached
3.3.3
protected and double sheathed strand
protected and sheathed strand using double sheathing for both types (S and A)
3.4
protection product
product applied before sheathing to ensure full encapsulation
3.5
sheath
continuous envelope surrounding the strand
3.6
batch of protection material
quantity of grease or wax produced in one manufacturing operation
4 Symbols
The symbols used in this European Standard and the corresponding designations are given in Table 1.
7
---------------------- Page: 9 ----------------------
oSIST prEN 10369-1:2019
prEN 10369-1:2019 (E)
Table 1 — Symbols and corresponding designations
Symbol Unit Designation
L mm Length of the test piece
M g Total mass of the test piece
t
M g Mass of the sheath
s
M g Total mass of wires
w
M g/m Mass per unit length of the protection product
pl
E MPa Modulus of elasticity of the strand
α ° Angle of bend of the test piece in the test for resistance to rotating
bending
D mm Diameter of the core wire
a
5 Classification and designation
5.1 Classification
The steels of the constituent strands of protected and sheathed strands covered by this document are
classified as special steels according to EN 10020.
5.2 Designation
The designation of the products covered by this standard comprises in the order:
— the description of the product (i.e. protected and sheathed strand);
— the designation of the strand from which the protected and sheathed strand is produced according
to the relevant standard in square brackets;
— the symbol of the protection product (+ G for grease; + W for wax);
— the symbol of the type of protected and sheathed strand (S or A, respectively see prEN 10369-2 and
prEN 10369-3);
— the colour of the sheath when other than black.
6 Information to be obtained by the manufacturer
The following information shall be obtained by the manufacturer at the time of enquiry and order:
a) designation of the product in accordance with 5.2;
b) the packaging and protection requirements;
c) the requirements concerning information to accompany the delivery (e.g. date of manufacture,
delivery note, type of inspection document, see EN 10204, copies of force/extension diagrams);
d) special requirements for labelling.
8
---------------------- Page: 10 ----------------------
oSIST prEN 10369-1:2019
prEN 10369-1:2019 (E)
7 Requirements
7.1 General
7.1.1 Manufacturing process
The strands to be protected and sheathed shall be manufactured in accordance with prEN 10138-1 and
prEN 10138-3 or prEN 10337.
The manufacturing method of the protected and sheathed strands shall be at the discretion of the
manufacturer provided that the sheath is applied to the protected strand by direct extrusion and all the
requirements of this standard are fulfilled.
7.1.2 Requirements for the constituent materials of the protected and sheathed strands
7.1.2.1 Strand
The uncoated strands shall be in accordance with prEN 10138-1 and prEN 10138-3 and be free from
rust at the time of application of the protection and sheath.
The zinc or zinc alloy coated prestressing strands shall be in accordance with prEN 10337.
7.1.2.2 Protection product
7.1.2.2.1 General
The protection product is a mineral oil-based grease or a microcrystalline wax.
7.1.2.2.2 Grease
The grease shall meet the requirements given in Table A.1.
7.1.2.2.3 Wax
The wax shall meet the requirements given in Table A.2.
7.1.2.3 Base material of the sheath
The base material of the sheath shall meet the requirements given in Annex B.
7.2 Requirements for the protected and sheathed strands
7.2.1 Standard and special properties
The requirements for the standard and special properties as defined in prEN 10138-1 and
prEN 10138-3 or prEN 10337 respectively shall apply.
7.2.2 Overall diameter
The overall diameter of the protected and sheathed strands shall be within a specified range in
accordance with the requirements of:
— prEN 10369-2 for sliding protected and sheathed strands (type S), and
— prEN 10369-3 for adherent protected and sheathed strands (type A).
7.2.3 Straightness
The maximum bow height of the protected and sheathed strands from a reference line of 1 m long,
measured within the curvature, in its plane, according to EN ISO 15630-3, shall be less than or equal to
25 mm.
9
---------------------- Page: 11 ----------------------
oSIST prEN 10369-1:2019
prEN 10369-1:2019 (E)
7.2.4 Mass of the protection product
The minimum specified value for the mass of grease or wax per metre of strand shall be as given in the
relevant requirements of prEN 10369-2 or prEN 10369-3.
The mass per unit length of grease or wax shall be determined according to the procedure described in
C.1.
7.2.5 Properties of the sheath
7.2.5.1 Thickness
The minimum thickness of the sheath shall meet the requirements specified in prEN 10369-2 or
prEN 10369-3 at any section.
The thickness of the sheath shall be determined according to the procedure described in C.2.
7.2.5.2 Surface conditions
There shall be no trace of protection product at the surface of the sheath.
The sheath shall not show continuous scratches, injuries or craters visible with a normal or corrected
vision. Local discontinuities shall not be of a length greater than the maximum overall diameter of the
protected and sheathed strand. The thickness of the sheath at a local discontinuity shall not fall below
the specified minimum.
7.2.5.3 Mechanical properties
The specified values of mechanical properties of the sheath shall be the minimum specified value of
tensile stress at yield, tensile strain at break at 23 °C, determined according to EN ISO 527-1 and
EN ISO 527-2 on a specimen 1B with a testing speed of 100 mm/min ± 10 %, and shall meet the
requirements specified in prEN 10369-2 or prEN 10369-3.
7.2.5.4 Stress cracking resistance
There shall be neither rupture nor cracking of the sheath, visible under a visual inspection by a person
with a normal or corrected vision when tested according to ASTM D1693 in an aqueous solution with
1 % of nonylphenol poly(ethylene-oxy)ethanol.
7.2.5.5 Resistance to aggressive media
The values of the tensile stress at yield and tensile strain at break of the sheath at 23 °C, determined
according to EN ISO 527-1 and EN ISO 527-2 on a specimen 1B with a testing speed of
100 mm/min ± 10 %, shall be greater than or equal to 75 % of those specified in prEN 10369-2 or
prEN 10369-3, after an exposure of 16 weeks to each of the aggressive media as listed in Table 2.
Table 2 — List of typical aggressive media and test agents
Exposure to Test agent
Mineral oil Oil No 3 according to ISO 1817
Acid 10 % sulphuric acid
Base Saturated calcium hydroxide 40 % sodium hydroxide
Solvents Blend of acetone: ethanol: n-heptane: toluol, 1:1:1:1 by mass
Salt water Saturated solution of demineralised tab water and NaCl
The change of the test piece volume after each test shall be lower than or equal to 5 %.
10
---------------------- Page: 12 ----------------------
oSIST prEN 10369-1:2019
prEN 10369-1:2019 (E)
The tests shall be carried out according to EN ISO 175.
7.2.5.6 Resistance to ionising radiation
Where required or applicable, there shall not appear cracks visible under a visual inspection without
assistance by a person with a normal or corrected vision and the yield strength of the sheath shall
remain at a value greater than or equal to 75 % of that specified in prEN 10369-2 or prEN 10369-3,
after a 3 000 h-test.
The test shall be carried out according to EN ISO 4892-2.
7.2.5.7 Properties after exposure to temperature
The values of tensile stress at yield and tensile strain at break of the sheath shall be greater than or
equal to 75 % of those specified in prEN 10369-2 or prEN 10369-3, after exposure of the sheath for 72
h ± 1 h to temperatures of 100 °C ± 5 °C and - 20 °C ± 2 °C.
The tensile test shall be carried out at 23 °C ± 5 °C according to EN ISO 527-1 and 2 on a specimen 1B
with a testing speed of 100 mm/min ± 10 %.
7.2.5.8 Colour stability
Where required and for specific applications, the colour stability as well as the method of verification of
this property may be specified for colours other than black.
7.2.6 Water tightness
Water tightness of the product shall be specified as the maximum mass variation of the test piece and
the mass of water passing through the test piece during the test as specified in prEN 10369-2 or
prEN 10369-3.
The tests to characterize the water tightness shall be carried out according to the procedure described
in C.5.
NOTE These tests are intended to give the proof of a proper filling of the spaces between the wires of the
strand and between the sheath and the wires by the protection product.
7.2.7 Initial resistance to friction
Initial resistance to friction shall be a maximum or minimum specified force as given in prEN 10369-2
or prEN 10369-3.
It shall be determined according to the procedure described in C.3.
7.2.8 Retention of the adherence under thermal variations
The retention of the adherence under thermal variations is only specified for adherent protected and
sheathed strands (type A), see prEN 10369-3.
It shall be determined according to the procedure described in C.4.
7.2.9 Impact resistance
Impact resistance shall be as specified in prEN 10369-2 or prEN 10369-3.
The test shall be carried out according to the procedure described in C.6.
11
---------------------- Page: 13 ----------------------
oSIST prEN 10369-1:2019
prEN 10369-1:2019 (E)
8 Assessment and verification of the constancy of performance (AVCP)
8.1 General
The compliance of the protected and sheathed strands for prestressing with the requirements of this
standard and with the performances declared by the manufacturer in the declaration of performance
(DoP) shall be demonstrated by:
— determination of the product type;
— factory production control by the manufacturer, including product assessment.
The manufacturer shall always retain the overall control and shall have the necessary means to take
responsibility for the conformity of the product with its declared performance(s).
8.2 Type testing
8.2.1 General
All performances related to characteristics included in this standard shall be determined when the
manufacturer intends to declare the respective performances.
Assessment previously performed in accordance with the provisions of this standard, may be taken into
account provided that they were made to the same or a more rigorous test method, under the same
AVCP system on the same product or products of similar design, construction and functionality, such
that the results are applicable to the product in question.
NOTE 1 Same AVCP system means testing by an independent third party, under the responsibility of a notified
product certification body.
For the purposes of assessment, the manufacturer's products may be grouped into families, where it is
considered that the results for one or more characteristics from any one product within the family are
representative for those same characteristics for all products within that same family.
NOTE 2 Products can be grouped in different families for different characteristics.
NOTE 3 Reference to the assessment method standards can be made to allow the selection of a suitable
representative sample.
In addition, the determination of the product type shall be performed for all characteristics included in
the standard for which the manufacturer declares the performance:
— at the beginning of the production of a new or modified protected and sheathed strands for
prestressing (unless a member of the same product range), or
— at the beginning of a new or modified method of production (where this may affect the stated
properties); or
they shall be repeated for the appropriate characteristic(s), whenever a change occurs in the protected
and sheathed strands for prestressing design, in the raw material or in the supplier of the components,
or in the method of production (subject to the definition of a family), which would affect significantly
one or more of the characteristics.
Where components are used whose characteristics have already been determined, by the component
manufacturer, on the basis of assessment methods of other product standards, these characteristics
need not be re-assessed. The specifications of these components shall be documented.
Products bearing
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
