SIST EN IEC 61169-74:2026

Radio-frequency connectors - Part 74: Sectional specification for HN series RF coaxial connectors with screw coupling - Characteristic impedance 50 Ω (IEC 61169-74:2025)

IEC 61169-74:2025, which is a Sectional Specification (SS), provides information and rules for the preparation of Detail Specifications (DS) for series HN RF coaxial connectors with screw coupling with a characteristic impedance of 50 Ω.
This document prescribes mating face dimensions for high performance connectors (grade 2), dimensional details of standard test connectors (grade 0), gauging information and tests selected from IEC 61169-1, applicable to all Detail Specifications relating to series HN RF connectors.
This document indicates recommended performance characteristics which are considered when writing a Detail Specification and it covers test schedules and inspection requirements for assessment levels M and H.
The series HN connectors are intended to be used in microwave transmission systems and can be connected with all kinds of RF cables and microstrips. The operating frequency is up to 6 GHz.

Hochfrequenz-Steckverbinder – Teil 74: Rahmenspezifikation für koaxiale HF-Steckverbinder der Serie HN mit Schraubkupplung – Wellenwiderstand 50 Ohm (IEC 61169-74:2025)

Connecteurs pour fréquences radioélectriques - Partie 74: Spécification intermédiaire pour connecteurs RF coaxiaux de la série hn avec couplage à vis - Impédance caractéristique 50 ohms (IEC 61169-74:2025)

L'IEC 61169-74:2025, qui est une spécification intermédiaire (SS, Sectional Specification), fournit des informations et des règles pour l'élaboration des spécifications particulières (DS, Detail Specification) relatives aux connecteurs RF coaxiaux de la série HN, à couplage à vis et ayant une impédance caractéristique de 50 Ω.
Le présent document décrit les dimensions des faces d'accouplement pour les connecteurs à usage général (grade 2), les détails dimensionnels des connecteurs d'essai normalisés (grade 0), les informations relatives aux calibres et les essais choisis à partir de l'IEC 61169-1, applicables à toutes les spécifications particulières relatives aux connecteurs RF de série HN.
Le présent document indique les caractéristiques de performance recommandées prises en considération pour la rédaction d'une spécification particulière et elle couvre les programmes d'essai et les exigences de contrôle pour les niveaux d'assurance M et H.
Les connecteurs de série HN sont destinés à être utilisés dans les systèmes de transmission à hyperfréquences et peuvent être connectés à tous types de câbles RF et de microrubans. La fréquence de fonctionnement s'étend jusqu'à 6 GHz.

Radiofrekvenčni konektorji - 74. del: Področna specifikacija za koaksialne konektorje RF serije HN z navojnim spajanjem - Karakteristična impedanca 50 ohm (IEC 61169-74:2025)

General Information

• Status: Not Published
• Public Enquiry End Date: 31-Jul-2025
• ICS: 33.120.30 - RF connectors
• Technical Committee: MOC - Mobile Communications
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 16-Dec-2025
• Due Date: 20-Feb-2026
• Ref Project: EN IEC 61169-74:2025 - Radio-frequency connectors - Part 74: Sectional specification for HN series RF coaxial connectors with screw coupling - Characteristic impedance 50 Ω

Standards Content (Sample)

SLOVENSKI STANDARD
oSIST prEN IEC 61169-74:2025
01-julij-2025
Radiofrekvenčni konektorji - 74. del: Področna specifikacija za koaksialne
konektorje RF serije HN z navojnim spajanjem - Karakteristična impedanca 50 ohm
Radio-frequency connectors - Part 74: Sectional specification for HN series RF coaxial
connectors with screw coupling - Characteristic impedance 50 ohms
Connecteurs pour fréquences radioélectriques - Partie 74: Spécification intermédiaire
pour connecteurs RF coaxiaux de la série hn avec couplage à vis - Impédance
caractéristique 50 ohms
Ta slovenski standard je istoveten z: prEN IEC 61169-74:2025
ICS:
33.120.30 Radiofrekvenčni konektorji RF connectors
(RF)
oSIST prEN IEC 61169-74:2025 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

oSIST prEN IEC 61169-74:2025
oSIST prEN IEC 61169-74:2025
46F/703/CDV
COMMITTEE DRAFT FOR VOTE (CDV)
PROJECT NUMBER:
IEC 61169-74 ED1
DATE OF CIRCULATION: CLOSING DATE FOR VOTING:
2025-05-09 2025-08-01
SUPERSEDES DOCUMENTS:
46F/690/CD, 46F/698/CC
IEC SC 46F : RF AND MICROWAVE PASSIVE COMPONENTS
SECRETARIAT: SECRETARY:
United States of America Mr John Morelli
OF INTEREST TO THE FOLLOWING COMMITTEES: HORIZONTAL FUNCTION(S):

ASPECTS CONCERNED:
SUBMITTED FOR CENELEC PARALLEL VOTING NOT SUBMITTED FOR CENELEC PARALLEL VOTING
Attention IEC-CENELEC parallel voting
The attention of IEC National Committees, members of CENELEC,
is drawn to the fact that this Committee Draft for Vote (CDV) is
submitted for parallel voting.
The CENELEC members are invited to vote through the CENELEC
online voting system.
This document is still under study and subject to change. It should not be used for reference purposes.
Recipients of this document are invited to submit, with their comments, notification of any relevant patent rights of which they are aware
and to provide supporting documentation.
Recipients of this document are invited to submit, with their comments, notification of any relevant “In Some Countries” clau ses to be
included should this proposal proceed. Recipients are reminded that the CDV stage is the final stage for submitting ISC claus es. (SEE
AC/22/2007 OR NEW GUIDANCE DOC).

TITLE:
Radio-frequency connectors – Part 74: Sectional specification for HN series RF coaxial connectors with screw
coupling – Characteristic impedance 50 ohms

PROPOSED STABILITY DATE: 2028
NOTE FROM TC/SC OFFICERS:
electronic file, to make a copy and to print out the content for the sole purpose of preparing National Committee positions.
You may not copy or "mirror" the file or printed version of the document, or any part of it, for any other purpose without
permission in writing from IEC.

oSIST prEN IEC 61169-74:2025
– 2 – IEC 61169-74 © IEC 2025
CONTENTS
1 Scope . 3
2 Normative references . 3
3 Mating face and gauge information . 3
3.1 General connectors – Grade 2 . 3
3.1.1 Connector with pin centre contact . 3
3.1.2 Connector with socket centre contact . 5
3.2 Gauges . 6
3.2.1 Gauge pin for socket centre contact .6
3.2.2 Gauge for outer contact of connector with pin centre contact .7
3.3 Dimensions – Standard test connectors – Grade 0 . 8
3.3.1 Connectors with pin centre contact .8
3.3.2 Connector with socket centre contact .9
4 Quality assessment procedures . 10
4.1 General . 10
4.2 Ratings and characteristics . 10
4.3 Test schedule and inspection requirements . 13
4.3.1 Acceptance tests . 13
4.3.2 Periodic tests . 13
4.3.3 Procedures for the quality conformance . 15
5 Instructions for preparation of detail specifications . 15
5.1 General . 15
5.2 Identification of the component . 15
5.3 Performance . 15
5.4 Marking, ordering information and related matters . 16
5.5 Selection of tests, test conditions and severities . 16
5.6 Blank detail specification pro-forma for HN connectors . 16
Bibliography . 21

oSIST prEN IEC 61169-74:2025
IEC 61169-74 © IEC 2025 – 3 –
1 RADIO-FREQUENCY CONNECTORS –
2 Part 74: Sectional specification for HN series RF coaxial connectors
3 with screw coupling – Characteristic impedance 50 ohms
6 1 Scope
7 This part of IEC 61169, which is a sectional specification (SS), provides information and rules
8 for the preparation of detail specifications (DS) for series HN RF coaxial connectors with
9 screw coupling with a characteristic impedance of 50 Ω.
10 This document prescribes mating face dimensions for high performance connectors – grade 2,
11 dimensional details of standard test connectors-grade 0, gauging information and tests
12 selected from IEC 61169-1, applicable to all detail specifications relating to series HN RF
13 connectors.
14 This document indicates recommended performance characteristics to be considered when
15 writing a detail specification and it covers test schedules and inspection requirements for
16 assessment levels M and H.
17 The series HN connectors which are used with all kinds of RF cables and microstrips in
18 microwave transmission systems. The operating frequency is up to 6 GHz.
19 NOTE Metric dimension are original dimensions. All undimensioned pictorial configurations are for reference
20 purpose only.
21 2 Normative references
22 The following documents, in whole or in part, are normatively referenced in this document and
23 are indispensable for its application. For dated references, only the edition cited applies. For
24 undated references, the latest edition of the referenced document (including any amendments)
25 applies.
26 IEC 61169-1:2013, Radio frequency connectors – Part 1: Generic specification – General
27 requirements and measuring methods
28 IEC 62153-4-7, Metallic communication cable test methods – Part 4-7: Electromagnetic
29 compatibility (EMC) – Test method for measuring of transfer impedance Z and screening
T
30 attenuation a or coupling attenuation a of connectors and assemblies up to and above
s c
31 3 GHz – Triaxial tube in tube method
32 IEC 62037-3, Passive RF and microwave devices, intermodulation level measurement - Part
33 3: Measurement of passive intermodulation in coaxial connectors
34 3 Mating face and gauge information
35 3.1 General connectors – Grade 2
36 3.1.1 Connector with pin centre contact
37 The mating face of connector with pin centre contact is shown in Figure 1 and its dimensions
38 are shown in Table 1.
oSIST prEN IEC 61169-74:2025
– 4 – IEC 61169-74 © IEC 2025
40 a) Connector with slotted outer conductor 41 b) Connector with unslotted outer conductor
43 NOTE 1 Mechanical and electrical reference plane.
44 NOTE 2 Sealing ring.
45 NOTE 3 Slot is optional. Slotted and flared to meet gauge requirements of 3.2.2.
46 Figure 1 – Connector with pin centre contact (for dimensions, see Table 1)
47 Table 1 – Dimensions of connector with pin centre contact
mm in
Ref. Remarks
min max min max
a
a — 3,35 — 0,132
a
b 10,8 nom 0,425 nom
c 13,80 13,90 0,543 0,547
d 7,34 — 0,289 —
e 6,68 — 0,263 —
f 1,57 1,68 0,062 0,066
g 19,30 — 0,760 —
b
h 13,34 — 0,525 —
i 9,35 — 0,368 —
j 9,04 9,86 0,356 0,388
k 0,13 — 0,005 —
c
l 10,24 — 0,403 —
d
m — 1,47 — 0,058
n 2,54 — 0,100 —
p 3,51 — 0,138 —
q 3,05 — 0,120 —
s — 0,38 — 0,015
t — 23,50 — 0,925
a
Dimension b depends on the dimension a and dielectric constant, and it must meet the requirement of
50Ω±1,5Ω characteristics.
b
Dimension h shall meet the requirement of electrical and sealing performance requirements.
c
Full thread.
d
Coupling nut in forward position.
oSIST prEN IEC 61169-74:2025
IEC 61169-74 © IEC 2025 – 5 –
49 3.1.2 Connector with socket centre contact
50 The mating face of connector with socket centre contact is shown in Figure 2 and its
51 dimensions are shown in
52 Table 2.
54 NOTE 1 Mechanical and electrical reference plane.
55 Figure 2 – Connector with socket centre contact (for dimensions, see
56 Table 2)
57 Table 2 – Dimensions of connector with socket centre contact
mm in
Ref. Remarks
min max min max
oSIST prEN IEC 61169-74:2025
– 6 – IEC 61169-74 © IEC 2025
mm in
Ref. Remarks
min max min max
a
a — 3,35 — 0,132
a
b 10,8 nom 0,425 nom
c 13,92 14,05 0,548 0,553
d — 7,47 — 0,294
e — 6,81 — 0,268
b
f — — — —
g — 19,18 — 0,755
h 13,11 13,26 0,516 0,522
i — 9,35 — 0,368
j 8,33 9,09 0,328 0,358
k — 0,13 — 0,005
c
l 9,12 — 0,359 —
m 14,50 — 0,571 —
d
n 14,99 — 0,590 —
p 9,02 — 0,355 —
q 1,96 2,21 0,077 0,087
s 14,50 14,68 0,571 0,578
t 16,81 17,35 0,662 0,683
a
Dimension b depends on the dimension a and dielectric constant, and shall meet the requirement of
50Ω±1,5Ω characteristics.
b
Design of slotting is optional. It is chosen to meet return loss (RL), mating characteristics, and connector
durability requirements, when mated with a 1,60 mm to 1,68 mm (0,063 in to 0,066 in) gauge pin.
c
Full thread.
d
Clearance for mating connector coupling nut.
59 3.2 Gauges
60 3.2.1 Gauge pin for socket centre contact
61 The gauge pin for socket centre contact is shown in Figure 3 and its dimensions are shown in
62 Table .
64 Figure 3 – Gauge pin for socket centre contact (for dimensions, see Table )
65 Table 3 – Dimensions of gauge pin for socket centre contact
Gauge A Gauge B Gauge C
(For sizing purpose) (For insertion purpose) (For retention purpose)
mm in mm in mm in
Ref.
min max min max min max min max min max min max
b 1,685 1,690 0,0663 0,0665 1,600 1,605 0,0630 0,0632 1,565 1,570 0,0616 0,0618
c — 0,25 — 0,01 — 0,25 — 0,01 — 0,25 — 0,01
d 3,18 — 0,125 — 3,18 — 0,125 — 3,18 — 0,125 —

oSIST prEN IEC 61169-74:2025
IEC 61169-74 © IEC 2025 – 7 –
e — 9,86 — 0,388 — 9,86 — 0,388 — 9,86 — 0,388
α
38°±2° 38°±2° 38°±10°
Material: steel, polished.
67 The test procedure is as follows:
68 a) Sizing test
69 The gauge A shall be inserted into the socket-centre contact three times. This is a sizing
70 operation and should only be carried out when the socket-centre contact is removed from
71 the connector.
72 b) Insertion test
73 After sizing test, the standard Gauge B should be inserted into the socket-centre contact.
74 The insertion depth should not be less than 6,35 mm and the insertion force should not be
75 more than 4.4 N.
76 c) Retention test
77 After sizing test, the gauge C shall be inserted into socket-centre contact. The contact
78 shall retain the mass of the gauge C in a vertical downward position. The insertion depth
79 should not be less than 6,35 mm and the separation force shall not be less than 0,56 N.
80 3.2.2 Gauge for outer contact of connector with pin centre contact
81 The gauge for outer contact of connector with pin centre contact is shown in Figure 4 and its
82 dimensions are shown in Table 4.
84 Figure 4 – Gauge for outer contact of connector with pin centre contact (for dimensions,
85 see Table 4)
86 Table 4– Dimensions of gauge for outer contact of connector with pin centre contact
Gauge D Gauge E Gauge F
(For sizing purpose) (For insertion purpose) (For retention purpose)
mm in mm in mm in
Ref.
min max min max min max min max min max min max
a 13,90 13,92 0,547 0,548 14,15 14,17 0,557 0,558 14,05 14,07 0,553 0,554
b — 7,62 — 0,300 — 7,62 — 0,300 — 7,62 — 0,300
c 14,45 14,50 0,569 0,571 14,15 14,17 0,557 0,558 14,05 14,07 0,553 0,554
d — 17,52 — 0,69 — 17,52 — 0,69 — 17,52 — 0,69
e 9,20 9,35 0,362 0,368 6,00 6,35 0,236 0,250 6,00 6,35 0,236 0,250
f 0,50 0,80 0,020 0,031 0,50 0,80 0,020 0,031 0,50 0,80 0,020 0,031
a
r 0,50 0,80 0,020 0,031 0,50 0,80 0,020 0,031 0,50 0,80 0,020 0,031
Material: steel, polished.
oSIST prEN IEC 61169-74:2025
– 8 – IEC 61169-74 © IEC 2025
88 The test procedure is as follows:
89 a) Sizing test
90 The resilient outer contact shall be completely inserted three times into the gauge D This
91 is a sizing operation.
92 b) Insertion test
93 After sizing test, the resilient outer contact shall be inserted into the gauge E The insertion
94 depth should not be less than 6,00 mm and the insertion force should not be more than
95 4.4 N.
96 c) Retention test
97 After insertion test, the resilient outer contact shall be inserted into the gauge E The
98 resilient outer contact shall retain the gauge F in a vertical downward direction. The
99 insertion depth should not be less than 6,00 mm and the separation force shall not be less
100 than 4 N.
101 This test may also be carried out on the connector with the insulator unremoved.
102 3.3 Dimensions – Standard test connectors – Grade 0
103 3.3.1 Connectors with pin centre contact
104 The interface of connector with pin centre contact is shown in Figure 5, dimensions are shown
105 in Table 5.
107 NOTE 1 Mechanical and electrical reference plane.
108 Figure 5 – Connector with pin centre contact (for dimensions, see Table 5)
109 Table 5 – Dimensions of connector with pin centre contact
mm in
Ref. Remarks
min max min max
oSIST prEN IEC 61169-74:2025
IEC 61169-74 © IEC 2025 – 9 –
mm in
Ref. Remarks
min max min max
a
a 3,3 nom 0,130 nom
b
b 10,78 10,81 0,4245 0,4255
c 13,84 13,89 0,545 0,547
d 7,35 7,46 0,289 0,294
e 6,70 6,80 0,264 0,268
f 1,638 1,664 0,0645 0,0655
i 9,40 9,45 0,370 0,372
j 9,15 9,20 0,360 0,362
k 0,13 0,25 0,005 0,010
u 0,64 0,89 0,025 0,035
c
v 0,20 0,40 0,008 0,016
a
The size of PTFE medium with dielectric constant of 2,02, and the PTFE medium shall be used.
b
The selected diameter should meet the requirements of 50 Ω ±0,5 Ω characteristic impedance.
c
Radius.
111 3.3.2 Connector with socket centre contact
112 The mating face of standard test connector with socket centre contact is shown in Figure 6
113 and its dimensions are shown in Table 6.
115 NOTE 1 Mechanical and electrical reference plane.
116 Figure 6 – Connector with socket in centre contact (for dimensions, see Table 6)
117 Table 6 – Dimensions of connector with socket centre contact
mm in
Ref. Remarks
min max min max
oSIST prEN IEC 61169-74:2025
– 10 – IEC 61169-74 © IEC 2025
mm in
Ref. Remarks
min max min max
a
a 3,3 nom 0,130 nom
b
b 10,78 10,81 0,4245 0,4255
c 13,93 14,00 0,548 0,552
d 7,35 7,46 0,289 0,294
e 6,66 6,75 0,262 0,266
f 1,651 nom 0,0650 nom
h 13,14 13,23 0,517 0,521
i 9,25 9,30 0,364 0,366
j 9,00 9,05 0,354 0,356
k 0,00 0,13 0,000 0,005
p 9,40 — 0,370 —
s 14,51 14,65 0,571 0,577
u 0,38 0,64 0,015 0,025
v 1,80 1,91 0,071 0,075
w 0,13 0,20 0,005 0,008
x 0,38 0,89 0,015 0,035
y 8,28 8,53 0,326 0,336
a
The size of PTFE medium with dielectric constant of 2,02, and the PTFE medium shall be used.
b
The selected diameter should meet the requirements of 50 Ω ±0,5 Ω characteristic impedance.
119 4 Quality assessment procedures
120 4.1 General
121 Subclauses 4.2 to 4.3 provide recommended ratings, performance and test conditions to be
122 considered when writing a detail specification (DS). They also provide an appropriate
123 schedule of tests with minimum levels of conformance inspection sampling, together with the
124 pro forma blank detail specification (BDS) and instructions for the preparation of a detail
125 specification.
126 4.2 Ratings and characteristics
127 Preferred climatic categories are given in Table 7
128 The values indicated below are recommended for HN series RF connectors and are given for
129 the writer of the detail specification. They are applicable for the condition when the
130 connectors are fully mated. Rating and characteristics are given in Table 8.
131 Certain tests are listed without any recommended values being given. These tests will usually
132 not be required. When these tests are required, appropriate values shall be entered in the
133 detail specification at the discretion of the specification writer.
134 Table 7 – Preferred climatic categories
Climate series Grade * Temperature range Steady damp heat
40/85/21 A − 40 °C ~ + 85 °C 21 days
55/125/21 B − 55 °C ~ + 125 °C 21 days
55/155/56 C − 55 °C ~ + 155 °C 56 days

* To be included in the IEC series designation.

oSIST prEN IE
...
