Electronic fee collection - Compliance check communication for autonomous systems (ISO/TS 12813:2009)
ISO/TS 12813:2009 defines requirements for short-range communication for the purposes of compliance checking in autonomous electronic fee-collecting (EFC) systems. Compliance checking communication (CCC) takes place between a road vehicle's on-board equipment (OBE) and an outside interrogator (road-side mounted equipment, mobile device or hand‑held unit), and serves to establish whether the data that are delivered by the OBE correctly reflect the road usage of the corresponding vehicle according to the rules of the pertinent toll regime.
The operator of the compliance checking interrogator is assumed to be part of the toll charging role as defined in ISO 17573. The CCC permits identification of the OBE, vehicle and contract, and verification of whether the driver has fulfilled his obligations and the checking status and performance of the OBE. The CCC reads, but does not write, OBE data.
ISO/TS 12813:2009 is applicable to OBE in an autonomous mode of operation; it is not applicable to compliance checking in dedicated short-range communication (DSRC)-based charging systems. It defines data syntax and semantics, but does not define a communication sequence. All the attributes defined herein are required in any OBE claimed to be compliant with ISO/TS 12813:2009, even if some values are set to “not defined” in cases where a certain functionality is not present in an OBE. The interrogator is free to choose which attributes are read, as well as the sequence in which they are read. In order to achieve compatibility with existing systems, the communication makes use of the attributes defined in ISO 14906 wherever possible.
The CCC is suitable for a range of short‑range communication media. Specific definitions are given for the CEN DSRC specified in EN 15509, as well as for the use of ISO CALM IR, UNI DSRC and ARIB DSRC as alternatives to the CEN DSRC. The attributes and functions defined are for compliance checking by means of the DSRC communication services provided by DSRC layer 7, with the CCC attributes and functions made available to the CCC applications at the road-side equipment (RSE) and OBE. The attributes and functions are defined on the level of ADU (application data units).
Test specifications are not within the scope of ISO/TS 12813:2009.
Elektronische Gebührenerhebung - Kommunikation zur Übereinstimmungsprüfung für autonome Systeme
Perception dutélépéage - Communication de contrôle de conformité pour systèmes autonomes (ISO/TS 12813:2009)
Elektronsko pobiranje pristojbin - Komunikacija za potrditev skladnosti avtonomnih sistemov (ISO/TS 12813:2009)
Ta tehnična specifikacija določa zahteve komunikacije kratkega dosega za namene preverjanja skladnosti avtonomnih elektronskih sistemov za pobiranje plačil (EFC). Preverjanje skladnosti komunikacije (CCC) se izvaja med vgrajeno opremo v cestnem vozilu (OBE) in zunanjim spraševalcem (oprema nameščena na robu cestišča, mobilna naprava ali ročna naprava) in služi temu, da ugotovi, ali podatki, ki so oddani iz OBE, pravilno odsevajo uporabo cestišča ustreznega vozila, skladno z navodili pristojnega režima cestnin. Operaterja spraševalca, ki preverja skladnost, je potrebno obravnavati kot del vloge zaračunavanja cestnin, kot je to določeno v ISO 17573. CCC dovoljuje identifikacijo OBE, vozila in pogodbe, ter verifikacijo, ali je voznik izpolnil svoje obveznosti in status preverjanja in delovanja OBE. CCC bere, vendar ne piše podatkov OBE. Ta tehnična specifikacija velja za OBE v avtonomnem načinu delovanja; ne velja za preverjanje skladnosti v namenskih, na DSRC osnovanih sistemih za zaračunavanje, ki uporabljajo komunikacijo kratkega dosega. Določa sintakso in semantiko podatkov, vendar ne določa zaporedje komunikacije. Vsi atributi v nadaljevanju so potrebni v vsaki OBE, za katero velja, da je v skladu s temi tehničnimi specifikacijami, tudi če so nekatere vrednosti v primerih, kjer določena funkcionalnost ni prisotna v OBE, nastavljene na »neopredeljeno«. Spraševalec prosto izbira, kateri atributi se berejo, kot tudi zaporedje, v katerem se berejo. Z namenom doseganja kompatibilnosti z obstoječimi sistemi se pri komunikaciji uporabljajo, kadar koli je mogoče, atributi, opredeljeni v ISO 14906. CCC je primeren za razpon medijev, ki uporabljajo komunikacijo kratkega dosega. Posebne definicije so dane za CEN-DSRC in so navedene v IN 15509, kot tudi uporaba ISO CALM IR, UNI DSRC in ARIB DSRC kot druge možnosti za CEN-DSRC. Opredeljeni atributi in funkcije so za preverjanje skladnosti z uporabo DSRC komunikacijskih servisov, ki jih zagotavlja 7. plast DSRC, z CCC atributi in funkcijami, ki so na voljo CCC aplikacijam v opremi na robu cestišč (RSE) in OBE. Atributi in funkcije so določeni na nivoju ADU (aplikativne podatkovne enote).
