EN 15817:2011

Polymer modified bituminous thick coatings for waterproofing - Water resistance

This European Standard specifies a procedure for determining the water resistance of polymer modified bituminous thick coatings for waterproofing.

Kunststoffmodifizierte Bitumendickbeschichtungen zur Bauwerksabdichtung - Wasserbeständigkeit

Diese Europäische Norm legt ein Verfahren zur Bestimmung der Wasserbeständigkeit von kunststoff-modifizierten Bitumendickbeschichtungen zur Bauwerksabdichtung fest.

Revêtements bitumineux épais modifiés aux polymères pour imperméabilisation - Résistance à l'eau

La présente Norme européenne spécifie une méthode permettant de déterminer la résistance à l'eau des revêtements bitumineux épais modifiés aux polymères pour imperméabilisation.

Bitumenske debeloslojne prevleke za tesnjenje, modificirane s polimeri - Vodoodpornost

Ta evropski standard opredeljuje postopek za določanje vodoodpornosti bitumenskih debeloslojnih prevlek za tesnjenje, modificiranih s polimeri, da se zagotovi hidroizolacija.

General Information

• Status: Published
• Publication Date: 22-Mar-2011
• Withdrawal Date: 29-Sep-2011
• ICS: 91.100.50 - Binders. Sealing materials
• Technical Committee: CEN/TC 361 - Project Committee - Thick synthetic modified bitumous coating masses - Definitions and requirements/Test methods
• Drafting Committee: CEN/TC 361 - Project Committee - Thick synthetic modified bitumous coating masses - Definitions and requirements/Test methods
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 13-Mar-2022
• Completion Date: 14-Apr-2025
• Directive: 305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
• Directive: 89/106/EEC - Construction products
• Mandate: M/102 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on membranes
• Ref Project: SIST EN 15817:2011 - Polymer modified bituminous thick coatings - Water resistance

Overview

EN 15817:2011 specifies a standardized laboratory procedure to determine the water resistance of polymer modified bituminous thick coatings for waterproofing. Published by CEN and approved in March 2011, this test method evaluates the behaviour of a polymer-modified bitumen-emulsion sheet when partially immersed in water for a defined period. The procedure supports product quality control, durability assessment and compliance with European waterproofing requirements.

Key topics

• Scope: Applies to polymer modified bituminous thick coatings intended for waterproofing; defines a water-resistance test procedure.
• Conditioning: Specimens conditioned in a standard atmosphere of (23 ± 2) °C and (50 ± 5) % RH in accordance with ISO 554 for 28 days before testing.
• Specimen preparation:
  • Flexible sheet formed from the polymer bitumen-emulsion.
  • Target dry layer thickness: 4 ± 0.4 mm (achieved by levelling the wet coating with a frame/gauge).
  • If applicable, incorporate any inlay/reinforcement prior to testing.
  • Minimum sample dimensions depend on the container (example dimensions given in the standard: not less than 90 mm × 250 mm).
• Test setup:
  • Place specimen in a glass beaker with approx. 2.5 L tap water, suspended centrally so 2/3 is immersed and 1/3 is not, ensuring the specimen is surrounded by water on all sides.
  • Maintain slight, continuous water movement using a magnetic stirrer during the test.
• Duration and assessment:
  • Immersion period: 28 days at room temperature.
  • Final evaluation is visual: look for material changes, peeling of reinforcement, or water discoloration.
• Reporting requirements: Include product identification, reference to EN 15817, test period, dry thickness, visual assessment, and test date.

Applications

• Quality control and batch verification by manufacturers of polymer modified bituminous coatings.
• Independent testing laboratories performing durability and water-resistance assessments.
• Specifiers, architects and contractors verifying product suitability for waterproofing applications (roofs, basements, foundations).
• Certification bodies and regulators using standardized test evidence for compliance and performance claims.
• Product development teams comparing formulations for improved water resistance.

Related standards

• FprEN 15814:2011 - Definitions and requirements for polymer modified bituminous thick coatings (referenced for terms and product requirements).
• ISO 554 - Standard atmospheres for conditioning and/or testing (used for specimen conditioning).

Keywords: EN 15817:2011, polymer modified bituminous thick coatings, water resistance test, waterproofing, bituminous coatings, CEN test method, waterproofing durability.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Bitumenske debeloslojne prevleke za tesnjenje, modificirane s polimeri - VodoodpornostKunststoffmodifizierte Bitumendickbeschichtungen - WasserbeständigkeitPolymer modified bituminous thick coatings - Water resistance91.100.50Veziva. Tesnilni materialiBinders. Sealing materialsICS:Ta slovenski standard je istoveten z:EN 15817:2011SIST EN 15817:2011en,fr,de01-junij-2011SIST EN 15817:2011SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 15817
March 2011 ICS 91.100.50 English Version
Polymer modified bituminous thick coatings for waterproofing - Water resistance
Revêtements bitumineux épais modifiés aux polymères pour imperméabilisation - Résistance à l'eau
Kunststoffmodifizierte Bitumendickbeschichtungen zur Bauwerksabdichtung - Wasserbeständigkeit This European Standard was approved by CEN on 13 February 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2011 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 15817:2011: ESIST EN 15817:2011
...
