EN 12573-2:2000

(Main)

Welded static non-pressurised thermoplastic tanks - Part 2: Calculation of vertical cylindrical tanks

Welded static non-pressurised thermoplastic tanks - Part 2: Calculation of vertical cylindrical tanks

This standard establishes rules for the design and calculation of welded static,vertical, non-pressurised, cylindrical, flat-bottom thermoplastic tanks. This standard applies to tanks fabricated in the following thermoplastics: Polyethylene (PE), Polypropylene (PP), Poly (vinyl chloride) (PVC), Poly (vinylidene fluoride) (PVDF). This standard does not take into account wind and/or snow loading. If wind or/and snow loading has to be taken into account additional calculations are necessary.

Geschweißte orstfeste drucklose Behälter (Tanks) aus Thermoplasten - Teil 2: Berechnung von runden stehenden Behältern (Tanks)

Diese Norm legt Regeln für die Konstuktion und Berechnung von geschweißten ortsfesten drucklosen runden stehenden Flachbodentanks aus Thermoplasten fest. Diese Norm gilt für Tanks, die aus den folgenden Thermoplasten gefertigt werden: Polyethylen (PE), Polypropylen (PP), Polyvinylchlorid (PVC), Polyvinylidenfluorid (PVDF). Wind- und/oder Schneelasten werden in dieser Norm nicht berücksichtigt. Wenn Wind- und/oder Schneelasten zu berücksichtigen sind, sind zusätzliche Berechnungen notwendig.

Cuves statiques soudées en matières thermoplastiques sans pression - Partie 2: Calcul des cuves cylindriques verticales

La présente norme fixe les règles de conception et de calcul des cuves cylindriques verticales, statiques, soudées, à fond plat, en matières thermo- plastiques, sans pression. La présente norme s'applique aux cuves fabriquées à partir des matériaux thermoplastiques suivants: polyéthylène (PE), polypropylène(PP), polychlorure de vinyle (PVC), polyfluorure de vinylidène (PVDF). La présente norme ne tient pas compte de la charge due au vent et/ou à la neige. Si la charge due au vent et/ou la neige doit être prise en compte, des calculs supplémentaires sont nécessaires.
