Railway applications - Braking - Brake performance

This European Standard defines an harmonized way to assess the braking performance by test of locomotives, passenger coaches, freight wagons and self-propelled passenger trains (EMU/DMU).
The European Standard sets out the standardized method for undertaking brake performance tests and the correction factors to be applied to the data obtained for all types of rolling stock.
This European Standard also defines the methods to assess the brake performance in terms of stopping distance, and from this the process to determine vehicle(s) deceleration and brake weight.
It then deals with conversion of the brake weight to the brake weight percentage of a vehicle or train for operating purposes. It also sets out additional factors when determining the brake weight percentage of a train calculated from specified brake weight, depending on the formation of the train.
In Annex D there is a method for determining brake performance of freight wagons fitted with P10 cast iron using limited testing (force measurement).

Bahnanwendung - Bremse - Bremsleistung

Dieses Dokument legt eine harmonisierte Verfahrensweise zur Bewertung des Bremsvermögens durch Prüfung von Lokomotiven, Reisezugwagen, Güterwagen und Elektro- und Dieseltriebwagen und  triebzügen fest.
Dieses Dokument legt das Normverfahren für die Durchführung von Prüfungen des Bremsvermögens und die Korrektur¬faktoren dar, die auf die für alle Arten von Schienenfahrzeugen gewonnenen Daten anzuwenden sind.
Dieses Dokument legt auch die Verfahren zur Bewertung des Bremsvermögens in Bezug auf den Anhalteweg und, davon ausgehend, den Prozess zur Bestimmung der Fahrzeugverzögerung und des Bremsgewichts fest.
Es befasst sich mit der Umwandlung des Bremsgewichts eines Fahrzeugs oder Zuges in Bremsgewichtshundertstel für betriebliche Zwecke. Es legt auch die zusätzlichen Faktoren bei der Bestimmung des Bremsgewichtshundertstel eines Zuges fest, das in Abhängigkeit von der Zugbildung aus dem festgelegten Bremsgewicht berechnet wird.
Anhang D enthält ein Verfahren (Kraftmessung) zur Bestimmung des Bremsvermögens von Güterwagen, die mit Bremsklötzen aus Grauguss P10 oder LL-Bremsklötzen ausgestattet sind.

Applications ferroviaires - Freins - Performance de freinage

Le présent document définit une méthode harmonisée pour évaluer la performance de freinage par essai des locomotives, des voitures voyageurs, des wagons et des rames automotrices (électriques et diesel).
Le présent document décrit la méthode normalisée pour réaliser les essais de performance de freinage, ainsi que les facteurs de correction à appliquer aux données obtenues pour tous les types de matériels roulants.
Le présent document définit également les méthodes d'évaluation de la performance de freinage en termes de distance d'arrêt et, à partir de celle-ci, le processus pour déterminer la décélération et la masse freinée du ou des véhicules.
Il traite ensuite de la conversion de la masse freinée en pourcentage de masse freinée d'un véhicule ou d'un train pour l'utilisation en service. Il présente également des facteurs supplémentaires pour la détermination du pourcentage de masse freinée d'un train calculé à partir d'une masse freinée spécifiée, selon la composition du train.
L'Annexe D spécifie une méthode pour déterminer la performance de freinage des wagons équipés de semelles en fonte P10 ou de semelles LL en utilisant des essais limités (mesurage de l'effort).

Železniške naprave - Zavore - Značilnosti zavore

Ta evropski standard določa usklajen način ocenjevanja značilnosti zavor s preskusom lokomotiv, potniških vagonov, tovornih vagonov in potniških vlakov na lastni pogon (EMU/DMU).
Evropski standard določa standardizirano metodo za preskušanje značilnosti zavor in korekcijske faktorje, ki se uporabljajo za podatke, pridobljene za vse tipe tirnih vozil.
Ta evropski standard prav tako opredeljuje metode za ocenjevanje značilnosti zavor v smislu zavorne razdalje in pri tem postopek za določanje pojemanja vozila in zavorne teže.
Vsebuje tudi pretvorbo zavorne mase v odstotek zavorne mase vozila ali vlaka za namene obratovanja. Prav tako določa dodatne faktorje za določanje odstotka zavorne mase vlaka, izračunanega iz specifične zavorne mase v odvisnosti od formacije vlaka.
V dodatku D je na voljo metoda za določanje značilnosti zavor tovornih vagonov, opremljenih z železovo litino P10, z uporabo omejenega preskušanja (merjenje sile).
