SIST EN 15269-2:2024
(Main)Extended application of test results for fire resistance and/or smoke control for door, shutter and openable window assemblies, including their elements of building hardware - Part 2: Fire resistance of hinged and pivoted steel doorsets
Extended application of test results for fire resistance and/or smoke control for door, shutter and openable window assemblies, including their elements of building hardware - Part 2: Fire resistance of hinged and pivoted steel doorsets
This European Standard covers single and double leaf, hinged and pivoted, steel based doorsets. It prescribes the methodology for extending the application of test results obtained from fire resistance test(s) conducted in accordance with EN 1634-1.
Subject to the completion of the appropriate test or tests, the extended application may cover all or some of the following examples:
- integrity (E), integrity/radiation (EW) or integrity/insulation (EI1 or EI2) classification;
- door leaf;
- ventilation grilles and/or louvres
- wall/ceiling fixed elements (frame/suspension system);
- glazing for door leaf, side, transom and flush over panels;
- items of building hardware;
- decorative finishes;
- intumescent, smoke, draught or acoustic seals;
- alternative supporting construction(s).
Erweiterter Anwendungsbereich von Prüfergebnissen zur Feuerwiderstandsfähigkeit und/oder Rauchdichtigkeit von Türen, Toren und Fenstern einschließlich ihrer Baubeschläge - Teil 2: Feuerwiderstandsfähigkeit von Drehflügeltüren aus Stahl
Dieses Dokument deckt ein- und zweiflügelige Drehflügeltüren aus Stahl ab. In diesem Dokument wird der Begriff „Tür“ verwendet, um sowohl die Türelemente als auch die aus verschiedenen Elementen bestehende Türeinheit abzudecken. Es schreibt die Methodologie zur Erweiterung der Anwendung von Ergebnissen der Prüfung(en) der Feuerwiderstandsfähigkeit nach EN 1634-1 vor.
In Abhängigkeit von der Durchführung der entsprechenden Prüfung oder Prüfungen kann der erweiterte Anwendungsbereich einige oder alle der nachstehend aufgeführten Beispiele abdecken:
— Klassifizierung von nicht wärmegedämmten Abschlüssen (E) sowie solchen mit Anforderungen an die Strahlung (EW) oder wärmegedämmten Abschlüssen (EI1 oder EI2);
— Türflügel;
— Seitenteile, Oberblenden und/oder Oberteile mit Kämpfern;
— Lüftungsgitter (Belüftungs-/Lufttransfergitter);
— an der Wand/Decke befestigte Elemente (Zarge/Aufhängungssysteme);
— Verglasungen für Türflügel, Seitenteile, Oberteile und obere Türblenden;
— Baubeschläge;
— dekorative Beschichtungen und/oder Schutzbeschichtungen;
— dämmschichtbildende Dichtungen und nicht dämmschichtbildende Dichtungen zur Behinderung von Rauchdurchtritt (Rauchschutzdichtungen, Durchzug oder Schallübertragung Schallschutzdichtungen);
— alternative Tragkonstruktion(en).
Dieses Dokument behandelt keine horizontalen Türen.
Die Auswirkung auf eine „C“-Klassifizierung für Türen im Rahmen eines erweiterten Anwendungsprozesses wird nicht in diesem Dokument behandelt.
Application étendue des résultats d'essais en matière de résistance au feu et/ou d'étanchéité à la fumée des blocs-portes, blocs-fermetures et fenêtres, y compris leurs éléments de quincaillerie - Partie 2: Résistance au feu des blocs-portes battants et pivotants en acier
Le présent document couvre les blocs-portes battants et pivotants en acier, à simple et à double vantail, à l’exception des blocs-portes en acier avec vantaux à ossature métallique couverts par l’EN 15269 5. Il prescrit la méthodologie permettant d’étendre l’application des résultats obtenus à partir d’un ou plusieurs essais de résistance au feu effectués conformément à l’EN 1634-1.
Sous réserve de la réalisation de l’essai ou des essais appropriés, l’application étendue peut couvrir tout ou partie des exemples suivants :
- classement de l’étanchéité au feu (E), de l’étanchéité au feu et aux rayonnements (EW) ou de l’étanchéité au feu et l’isolation thermique (EI1 ou EI2) ;
- vantail ;
- panneaux latéraux, impostes, panneaux supérieurs affleurants ;
- grilles d’aération (par exemple, grilles de ventilation/jalousies) ;
- composants (par exemple, dormant/système de suspension) fixés à la construction support (par exemple, mur/plafond) ;
- vitrage encastré dans le vantail (par exemple, panneaux latéraux, impostes et panneaux supérieurs affleurants) ;
- éléments de quincaillerie ;
- finitions décoratives et de protection ;
- bandes intumescentes, joints intumescents et non-intumescents (joints d’étanchéité à la fumée, joints d’étanchéité à l’air ou joints acoustiques) ;
- autre(s) construction(s) support.
Le présent document ne couvre pas les blocs-portes posés à l’horizontale (par exemple, les trappes).
L’effet sur le classement « C » des blocs-portes qui suivent un processus d’application étendu n’est pas traité dans le présent document.
Razširjena uporaba rezultatov preskusov požarne odpornosti in/ali dimotesnosti za vrata, zaporne elemente in okna, ki se odpirajo, vključno z njihovim okovjem - 2. del: Požarna odpornost jeklenih vrat z vrtljivim krilom
General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
oSIST prEN 15269-2:2023
01-februar-2023
Razširjena uporaba rezultatov preskusov požarne odpornosti in/ali dimotesnosti
za vrata, zaporne elemente in okna, ki se odpirajo, vključno z njihovim okovjem - 2.
del: Požarna odpornost jeklenih vrat z vrtljivim krilom
Extended application of test results for fire resistance and/or smoke control for door,
shutter and openable window assemblies, including their elements of building hardware -
Part 2: Fire resistance of hinged and pivoted steel doorsets
Erweiterter Anwendungsbereich von Prüfergebnissen zur Feuerwiderstandsfähigkeit
und/oder Rauchdichtigkeit von Türen, Toren und Fenstern einschließlich ihrer
Baubeschläge - Teil 2: Feuerwiderstandsfähigkeit von Drehflügeltüren aus Stahl
Ta slovenski standard je istoveten z: prEN 15269-2
ICS:
13.220.50 Požarna odpornost Fire-resistance of building
gradbenih materialov in materials and elements
elementov
91.060.50 Vrata in okna Doors and windows
oSIST prEN 15269-2:2023 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
oSIST prEN 15269-2:2023
oSIST prEN 15269-2:2023
DRAFT
EUROPEAN STANDARD
prEN 15269-2
NORME EUROPÉENNE
EUROPÄISCHE NORM
December 2022
ICS
English Version
Extended application of test results for fire resistance
and/or smoke control for door, shutter and openable
window assemblies, including their elements of building
hardware - Part 2: Fire resistance of hinged and pivoted
steel doorsets
Erweiterter Anwendungsbereich von Prüfergebnissen
zur Feuerwiderstandsfähigkeit und/oder
Rauchdichtigkeit von Türen, Toren und Fenstern
einschließlich ihrer Baubeschläge - Teil 2:
Feuerwiderstandsfähigkeit von Drehflügeltüren aus
Stahl
This draft European Standard is submitted to CEN members for enquiry. It has been drawn up by the Technical Committee
CEN/TC 127.
If this draft becomes a European Standard, CEN members are bound to comply with the CEN/CENELEC Internal Regulations
which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
This draft European Standard was established by CEN in three official versions (English, French, German). A version in any other
language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC
Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway,
Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Türkiye and
United Kingdom.
Recipients of this draft are invited to submit, with their comments, notification of any relevant patent rights of which they are
aware and to provide supporting documentation.
Warning : This document is not a European Standard. It is distributed for review and comments. It is subject to change without
notice and shall not be referred to as a European Standard.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2022 CEN All rights of exploitation in any form and by any means reserved Ref. No. prEN 15269-2:2022 E
worldwide for CEN national Members.
oSIST prEN 15269-2:2023
prEN 15269-2:2022 (E)
Contents Page
European foreword . 3
1 Scope . 4
2 Normative references . 4
3 Terms and definitions . 5
4 Determination of the field of extended application . 6
4.1 General . 6
4.2 How to use extended application rules in Annex A . 7
4.3 Procedure for maximum field of extended application . 7
4.4 Analysis of test results . 8
5 Extended application report . 8
6 Classification report . 8
Annex A (normative) Construction parameter variations . 10
Annex B (normative) Arrangements for doorsets incorporating side and/or over panels . 132
oSIST prEN 15269-2:2023
prEN 15269-2:2022 (E)
European foreword
This document (prEN 15269-2:2022) has been prepared by Technical Committee CEN/TC 127 “Fire
safety in buildings”, the secretariat of which is held by BSI.
This document is currently submitted to the CEN Enquiry.
This document will supersede EN 15269-2:2012.
This document has been prepared under a mandate given to CEN by the European Commission and the
European Free Trade Association.
A list of all parts in the EN 15269 series can be found on the CEN website.
oSIST prEN 15269-2:2023
prEN 15269-2:2022 (E)
1 Scope
This document covers single and double leaf, hinged and pivoted, steel based doorsets. Throughout this
document the term “doorset” will be used to cover both doorsets and door assemblies. It prescribes the
methodology for extending the application of test results obtained from fire resistance test(s) conducted
in accordance with EN 1634-1.
Subject to the completion of the appropriate test or tests, the extended application may cover all or some
of the following examples:
— integrity (E), integrity/radiation (EW) or integrity/insulation (EI or EI ) classification;
1 2
— door leaf
— side, transom and/or overpanels;
— louvres (ventilation / air transfer grilles);
— wall/ceiling fixed elements (frame/suspension system);
— glazing for door leaf, side, transom and flush over panels;
— items of building hardware;
— decorative and protective finishes;
— intumescent seals and non-intumescent (smoke, draught or acoustic) seals;
— alternative supporting construction(s).
This document does not cover horizontal doorsets.
The effect on the Classification ‘C’ for the doorsets following an extended application process is not
addressed in this document.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
EN 179, Building hardware - Emergency exit devices operated by a lever handle or push pad, for use on
escape routes - Requirements and test methods
EN 1125, Building hardware - Panic exit devices operated by a horizontal bar, for use on escape routes -
Requirements and test methods
EN 1363-1, Fire resistance tests - Part 1: General requirements
EN 1363-2, Fire resistance tests - Part 2: Alternative and additional procedures
EN 1634-1, Fire resistance and smoke control tests for door and shutter assemblies, openable windows and
elements of building hardware - Part 1: Fire resistance test for door and shutter assemblies and openable
windows
oSIST prEN 15269-2:2023
prEN 15269-2:2022 (E)
EN 1634-2, Fire resistance and smoke control tests for door, shutter and openable window assemblies and
elements of building hardware — Part 2: Fire resistance characterisation test for elements of building
hardware
EN 12519, Windows and pedestrian doors - Terminology
EN 13501-2:2016, Fire classification of construction products and building elements - Part 2: Classification
using data from fire resistance tests, excluding ventilation services
EN 15254-4, Extended application of results from fire resistance tests — Non-loadbearing walls — Part 4.
Glazed constructions
EN 15269-1, Extended application of test results for fire resistance and/or smoke control for door, shutter
and openable window assemblies, including their elements of building hardware - Part 1: General
requirements
EN ISO 13943, Fire safety - Vocabulary (ISO 13943)
3 Terms and definitions
For the purposes of this document, the terms and definitions given in EN 1363-1, EN 1363-2, EN 1634-1,
EN 1634-2, EN 12519, EN 15269-1 and EN ISO 13943 and the following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at https://www.electropedia.org/
— ISO Online browsing platform: available at https://www.iso.org/obp
3.1
full scale test
test of a doorset in accordance with EN 1634-1.
3.2
small scale test
test on elements of building hardware in accordance with EN 1634-2 and where the decision process,
given in EN 1634-2, permits its use
3.3
effective rebate depth
dimension of the door leaf thickness of overlapping adjacent edges of door leaf relative to the door frame,
transom or side panel or other door leaf flush overpanel
Note 1 to entry: At the meeting edges and for rebated leaves this dimension will be the rebate where the
intumescent seal is fitted or, if no seal is fitted, the depth of the largest rebate (see Figure 1).
3.4
panel
component of a door leaf separated from other elements by joints which break through the total door
thickness
Note 1 to entry: A door leaf can consist of one or more panels.
oSIST prEN 15269-2:2023
prEN 15269-2:2022 (E)
3.5
decorative and/or protective finishes
outer layer of material on the leaf or panel only used for decorative and/or protective, not for structural
purposes
3.6
representative / similar / fundamentally the same
A door leaf design can be considered as representative by having ‘fundamentally the same’ or ‘similar’
construction as another door leaf design for the purpose of evaluating parameter variations providing
the relevant aspects of tested performance are considered
Note 1 to entry: see EN 15269-1 for further guidance on evaluation of similar/fundamentally the same.
4 Determination of the field of extended application
4.1 General
4.1.1 Before there can be any consideration for extended application the doorset / door assembly shall
have been tested in accordance with EN 1634-1 to achieve a test result which could generate a
classification in accordance with EN 13501-2 at least equal to the classification subsequently required
from extended application considerations. These tests are referred to in this standard as basic tests.
Note 1 to entry: If a doorset is classified from one side only (e.g. just opening face), the extended
application rules cannot lead to a classification of the opposite side or of both sides.
4.1.2 A review of the doorset construction parameters can indicate that one or more characteristics
may be improved by a particular parameter variation. All evaluations shall be made on the basis of
retaining the classifications obtainable from testing to EN 1634-1, including those lower than the test
duration. However, this shall never lead to an increased classification for any specific parameter beyond
that achieved during any one test unless specifically identified in the relevant Construction Parameter
Variation tables.
4.1.3 If, when following the extended application procedure, any part of the classified product cannot
be covered by the extended application rules, that part shall be omitted from the subsequent extended
application report and classification report.
4.2 How to use extended application rules in Annex A
4.2.1 Identify the variations from the original test specimen(s) which are required to be covered by an
extended application report.
4.2.2 Locate the variations in the appropriate parameter variation by reference to columns (1) and (2)
of Annex A.
4.2.3 Establish from the contents of column (3) of Annex A whether any extended application is
available beyond the direct application rules (DIAP) in EN 1634-1 without the need for further testing.
4.2.4 Where this is deemed to be possible, it can be recorded in the extended application report
together with any appropriate restrictions and the stated rules from column (3) of Annex A.
4.2.5 Where the variations required can only be achieved from additional testing, the additional test
should be made on a representative specimen type i.e. a doorset of the same or more onerous
configuration. Alternatively, column (4) of Annex A identifies an option for alternative testing and
relevant test parameters.
oSIST prEN 15269-2:2023
prEN 15269-2:2022 (E)
Most onerous configuration must be the one with the lowest relevant performance in terms of mode of
failure and/or highest distortion but must also be evaluated taking the intended construction parameter
variation(s) into account. For example, if the construction parameter variation involves a change to
glazing or side panel and over panel configurations then the previous result where these have been tested
would need to be used to make the evaluation of most onerous. The result for a single unglazed doorset
would not be suitable and can therefore be discounted when making the evaluation
4.3 Procedure for maximum field of extended application
4.3.1 It is possible to provide an extended field of application from a single test. However, where a
manufacturer intends to produce a range of doors incorporating single doors and also double
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
