SIST EN 12020-1:2022

Aluminium and aluminium alloys - Extruded precision profiles in alloys EN AW-6060 and EN AW-6063 - Part 1: Technical conditions for inspection and delivery

This document specifies technical conditions for inspection and delivery of alloys EN AW-6060 and EN AW 6063 extruded precision profiles manufactured with and without a thermal barrier (see Figures 1 and 2) and without further surface treatment.
Precision profiles covered in this document are distinguished from extruded profiles for general applications covered in EN 755 9 by the following characteristics:
- they are designed with mostly uniformly wall thicknesses;
- they are mainly used for mechanical engineering, architectural and automotive (except crash-elements) applications;
- the maximum weight by meter is 10 kg/m;
- the maximum wall thickness proportion (Smax/Smin) is 3,5.
In the case of profiles, which, due to the complexity of their design, are difficult to manufacture and specify, special agreements between supplier and purchaser may need to be reached.
NOTE   The effect of the thermal barrier material on the dimensional tolerances is covered by EN 12020 2 although the actual thermal barrier material itself is not (see EN 14024).

Aluminium und Aluminiumlegierungen - Stranggepresste Präzisionsprofile aus Legierungen EN AW-6060 und EN AW-6063 - Teil 1: Technische Lieferbedingungen

Dieses Dokument legt die Technischen Lieferbedingungen für stranggepresste Präzisionsprofile aus den Legierungen EN AW 6060 und EN AW 6063 fest, die mit oder ohne Wärmedämmung (siehe Bild 1 und Bild 2) hergestellt werden und ohne weitere Oberflächenbehandlung geliefert werden.
Die in diesem Dokument beschriebenen Präzisionsprofile unterscheiden sich von den stranggepressten Profilen für allgemeine Anwendungen nach EN 755 9 wie folgt:
- sie werden mit meist gleichmäßigen Wanddicken ausgeführt;
- sie werden hauptsächlich im Maschinenbau, in der Architektur und im Automobilbau (außer Crashelementen) eingesetzt;
- das maximale Metergewicht beträgt 10 kg/m;
- das maximale Wanddickenverhältnis (Smax/Smin) beträgt 3,5.
Bei Profilen, die aufgrund ihrer komplexen Konstruktion schwierig herzustellen und zu spezifizieren sind, können besondere Vereinbarungen zwischen Lieferer und Käufer notwendig sein.
ANMERKUNG   Der Einfluss des Materials für die Wärmedämmung auf die Grenzabmaße wird in EN 12020 2 berücksichtigt, wenngleich das eigentliche Material für die Wärmedämmung nicht enthalten ist (siehe EN 14024).

Aluminium et alliages d'aluminium - Profilés de précision filés en alliages EN AW-6060 et EN AW-6063 - Partie 1: Conditions techniques de contrôle et de livraison

Le présent document spécifie les conditions techniques de contrôle et de livraison des profilés de précision filés en alliages EN AW 6060 et EN AW 6063 fabriqués avec ou sans barrière thermique (voir Figures 1 et 2) et sans autre traitement de surface.
Les profilés de précision traités dans le présent document se distinguent des produits filés pour application générale traités dans l'EN 755 9 par les caractéristiques suivantes :
- ils sont conçus avec des épaisseurs de paroi le plus souvent uniformes ;
- ils sont principalement destinés à des applications du génie mécanique, de l’architecture et de l’automobile (à l’exception des éléments exposés aux collisions) ;
- la masse maximale par mètre est de 10 kg/m ;
- le rapport maximal d’épaisseur de paroi (Smax/Smin) est de 3,5.
Dans le cas de profilés qui, en raison de la complexité de leur conception, sont difficiles à spécifier et à fabriquer, il peut s’avérer nécessaire que le fournisseur et l’acheteur conviennent d’accords spéciaux.
NOTE   Les effets du matériau de la barrière thermique sur les tolérances dimensionnelles sont traités dans l'EN 12020 2, même si le matériau lui-même de la barrière thermique proprement dite ne l'est pas (voir l'EN 14024).

Aluminij in aluminijeve zlitine - Precizni iztiskani profili v zlitinah EN AW-6060 in EN AW-6063 - 1. del: Tehnični pogoji za pregled in dobavo

Ta dokument določa tehnične pogoje za pregled in dobavo preciznih iztiskanih profilov v zlitinah EN AW-6060 in EN AW 6063, izdelanih s termično prevleko ali brez nje (glej sliki 1 in 2) in brez nadaljnje površinske obdelave.
Precizni profili, ki jih zajema ta dokument, se razlikujejo od iztiskanih profilov za splošno uporabo, ki so zajeti v standardu EN 755-9, po naslednjih lastnostih:
– zasnovani so z večinoma enakomernimi debelinami sten;
– uporabljajo se predvsem v strojništvu, arhitekturi in avtomobilski industriji (razen elementov proti trčenju);
– največja teža na meter je 10 kg/m;
– največji delež debeline stene (Smax/Smin) je 3,5.
Pri profilih, ki jih je zaradi kompleksnosti zasnove težko izdelati in določiti, je morda treba doseči posebne dogovore med dobaviteljem in kupcem.
OPOMBA:   Učinek termične prevleke na tolerance mer je zajet v standardu EN 12020-2, čeprav sam material termične prevleke ni zajet (glej standard EN 14024).
