Electromagnetic compatibility and Radio spectrum Matters (ERM); Short Range Devices;
Road Transport and Traffic Telematics (RTTT); Radar equipment operating in the 76
GHz to 77 GHz range; Part 1: Technical characteristics and test methods for radar
equipment operating in the 76 GHz to 77 GHz range
Ta slovenski standard je istoveten z: EN 301 091-1 Version 1.2.1
ICS:
33.060.99 Druga oprema za radijske Other equipment for
komunikacije radiocommunications
33.100.01 Elektromagnetna združljivost Electromagnetic compatibility
na splošno in general
35.240.60 Uporabniške rešitve IT v IT applications in transport
transportu in trgovini and trade
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
European Standard (Telecommunications series)
Electromagnetic compatibility
and Radio spectrum Matters (ERM);
Short Range Devices;
Road Transport and Traffic Telematics (RTTT);
Radar equipment operating in the 76 GHz to 77 GHz range;
Part 1: Technical characteristics and test methods for
radar equipment operating in the 76 GHz to 77 GHz range
2 ETSI EN 301 091-1 V1.2.1 (2004-11)
Reference
REN/ERM-TG31B-047-1
Keywords
radar, radio, testing, SRD, RTTT, short range
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2004.
All rights reserved.
TM TM TM
DECT , PLUGTESTS and UMTS are Trade Marks of ETSI registered for the benefit of its Members.
TM
TIPHON and the TIPHON logo are Trade Marks currently being registered by ETSI for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
ETSI
3 ETSI EN 301 091-1 V1.2.1 (2004-11)
Contents
Intellectual Property Rights.6
Foreword.6
1 Scope.7
2 References.7
3 Definitions, symbols and abbreviations .8
3.1 Definitions.8
3.2 Symbols.10
3.3 Abbreviations.10
4 Technical requirements specifications.11
4.1 Presentation of equipment for testing purposes.11
4.1.1 Choice of model for testing .11
4.2 Mechanical and electrical design.11
4.3 Auxiliary test equipment .11
4.4 Interpretation of the measurement results .11
5 Test conditions, power sources and ambient temperatures .12
5.1 Normal and extreme test conditions .12
5.2 External test power source.12
5.3 Normal test conditions.12
5.3.1 Normal temperature and humidity.12
5.3.2 Normal test power source .12
5.3.2.1 Mains voltage.12
5.3.2.2 Other power sources.12
5.4 Extreme test conditions .13
5.4.1 Extreme temperatures.13
5.4.1.1 Procedure for tests at extreme temperatures.13
5.4.1.2 Extreme temperature ranges.13
5.4.2 Extreme test source voltages.13
5.4.2.1 Mains voltage.13
5.4.2.2 Other power sources.13
6 General conditions.13
6.1 Test fixture.13
6.1.1 Calibration.14
6.1.2 General requirements for RF cables and waveguides .15
6.1.3 Shielded anechoic chamber.15
7 Methods of measurement and limits for transmitter parameters .16
7.1 Permitted range of operating frequencies.17
7.1.1 Definition.17
7.1.2 Method of measurement.17
7.1.3 Limits.17
7.2 Radiated spatial power density.18
7.2.1 Definition.18
7.2.2 Method of measurement.18
7.2.2.1 Equipment with a fixed beam antenna (i.e. non-steerable by either mechanical or electronic
means) .18
7.2.2.2 Equipment with (electronically or mechanically) steerable antenna(s).18
7.2.3 Limits.19
7.2.3.1 Equipment with fixed beam antenna.19
7.2.3.2 Equipment with (electronically or mechanically) steerable antennas .19
7.3 Out-of-band emissions.19
7.3.1 Definitions.19
7.3.2 Measuring receiver.19
7.3.3 Method of measurement.20
ETSI
4 ETSI EN 301 091-1 V1.2.1 (2004-11)
7.3.4 Limits.20
7.4 Radiated spurious.21
7.4.1 Definition.21
7.4.2 Measuring receiver.21
7.4.3 Method of measurement for radiated spurious.21
7.4.4 Limits.22
8 Receiver.22
8.1 Receiver spurious and out-of-band emissions .22
8.1.1 Definition.22
8.1.2 Method of measurement - radiated spurious and out-of-band emissions.22
8.1.3 Limit.23
9 Measurement uncertainty.23
Annex A (normative): Radiated measurements .24
A.1 Test sites and general arrangements for measurements involving the use of radiated fields.24
A.1.1 Open Area Test Site (OATS) .24
A.1.2 Test antenna.25
A.1.3 Standard position.25
A.1.4 Indoor Test Site.25
A.2 Guidance on the use of radiation test sites .26
A.2.1 Measuring distance.26
A.2.2 Test antenna.26
A.2.3 Substitution antenna.27
A.2.4 Auxiliary cables.27
A.3 Alternative test site using a fully anechoic RF chamber .27
A.3.1 Example of the construction of a shielded anechoic chamber.27
A.3.2 Influence of parasitic reflections in anechoic chambers.28
A.3.3 Calibration of the shielded RF anechoic chamber.28
Annex B (normative): General description of measurement methods.30
B.1 Radiated measurements.30
Annex C (informative): Maximum safe level of radiated power density.32
C.1 Definition.32
C.2 Method of measurement.32
C.2.1 Equipment with a fixed beam antenna(s) (i.e. non-steerable by either mechanical or electronic means) .32
C.2.2 Equipment with (electronically or mechanically) steerable antenna .32
C.3 Limit.32
Annex D (informative): Examples of modulation schemes.33
D.1 Pulse modulation.33
D.1.1 Definition.33
D.1.2 Typical operating parameters .33
D.2 Frequency modulated continuous wave .34
D.2.1 Definition.34
D.2.2 Typical operating parameters .34
D.3 Frequency Shift Keying (FSK).35
D.3.1 Definition.35
D.3.2 Typical operating parameters .36
D.4 PN-ASK (Pseudo-Noise Amplitude Shift Keying) 77 GHz.36
D.4.1 Definition.36
D.4.2 Typical operating parameters .37
Annex E (informative): Conversion of power density to e.i.r.p.38
ETSI
5 ETSI EN 301 091-1 V1.2.1 (2004-11)
E.1 Assumptions.38
E.2 Example.38
Annex F (informative): Bibliography.39
History .40
ETSI
6 ETSI EN 301 091-1 V1.2.1 (2004-11)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This European Standard (Telecommunications series) has been produced by ETSI Technical Committee
Electromagnetic compatibility and Radio spectrum Matters (ERM).
For non EU countries the present document may be used for regulatory (Type Approval) purposes.
Where equipment compliant with the present document is intended for fitment into vehicles, then it is subject to
automotive EMC type approval and has to comply with directive 95/54/EC [6]. For use on vehicles outside the scope of
95/54/EC [6] compliance with an EMC directive/standard appropriate for that use is required.
The present document is part 1 of a multi-part deliverable covering Electromagnetic compatibility and Radio spectrum
Matters (ERM); Short Range Devices; Road Transport and Traffic Telematics (RTTT); Radar equipment operating in
the 76 GHz to 77 GHz range, as identified below:
Part 1: "Technical characteristics and test methods for radar equipment operating in the 76 GHz to
77 GHz range";
Part 2: "Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive".
National transposition dates
Date of adoption of this EN: 5 November 2004
Date of latest announcement of this EN (doa): 28 February 2005
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 31 August 2005
Date of withdrawal of any conflicting National Standard (dow): 31 August 2005
ETSI
7 ETSI EN 301 091-1 V1.2.1 (2004-11)
1 Scope
The present document specifies the requirements for Short Range Devices (SRD) operating in the frequency range from
76 GHz to 77 GHz intended for Road Transport and Traffic Telematics (RTTT) applications such as Automotive Cruise
Control (ACC), Collision Warning (CW), Anti-Collision (AC) systems, obstacle detection, Stop and Go, blind spot
detection, parking aid, backup aid and other automotive applications.
The document applies to:
a) transmitters operating in range from 76 GHz to 77 GHz;
b) receivers operating in the range from 76 GHz to 77 GHz.
The present document contains the technical characteristics and test methods for radar equipment fitted with integral
antennas operating in the frequency range from 76 GHz to 77 GHz and references CEPT/ERC/ECC Recommendation
for SRDs, CEPT/ERC/ECC Recommendation 70-03 [1] and CEPT/ECC Decision (02)01 [2].
The present document does not necessarily include all the characteristics which may be required by a user, nor does it
necessarily represent the optimum performance achievable.
The present document covers radars for mobile applications in the frequency range from 76 GHz to 77 GHz. It covers
integrated transceivers and separate transmit/receive modules.
The present document covers only equipment for road vehicles.
NOTE: It is necessary for the equipment to comply with the current regulations regarding safe levels for radiated
power. Information is given in the informative annex C.
2 References
The following documents contain provisions which, through reference in this text, constitute provisions of the present
document.
• References are either specific (identified by date of publication and/or edition number or version number) or
non-specific.
• For a specific reference, subsequent revisions do not apply.
• For a non-specific reference, the latest version applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
[1] CEPT/ERC Recommendation 70-03 (Latest edition): "Relating to the use of Short Range Devices
(SRD)".
[2] CEPT/ECC/DEC(02)01: "ECC Decision of 15 March 2002 on the frequency bands to be
designated for the coordinated introduction of Road Transport and Traffic Telematic Systems".
[3] CISPR 16-1: "Specifications for radio disturbance and immunity measuring apparatus and
methods; Part 1: Radio disturbance and immunity measuring apparatus".
[4] ETSI TR 100 028 (all parts): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Uncertainties in the measurement of mobile radio equipment characteristics".
[5] Council Recommendation 1999/519/EC of 12 July 1999 on the limitation of exposure of the
general public to electromagnetic fields (0 Hz to 300 GHz).
ETSI
8 ETSI EN 301 091-1 V1.2.1 (2004-11)
[6] Commission Directive 95/54/EC of 31 October 1995 adapting to technical progress Council
Directive 72/245/EEC on the approximation of the laws of the Member States relating to the
suppression of radio interference produced by spark-ignition engines fitted to motor vehicles and
amending Directive 70/156/EEC on the approximation of the laws of the Member States relating
to the type-approval of motor vehicles and their trailers.
[7] ETSI TR 102 273-2: "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Improvement on Radiated Methods of Measurement (using test site) and evaluation of the
corresponding measurement uncertainties; Part 2: Anechoic chamber".
[8] CEPT/ERC Recommendation 01-06: "Procedure for mutual recognition of type testing approval
for radio equipment".
3 Definitions, symbols and abbreviations
3.1 Definitions
For the purposes of the present document, the following terms and definitions apply:
antenna scan duty factor: ratio of the area of the beam (measured at its 3 dB point) to the total area scanned by the
antenna (as measured at its 3 dB point)
assigned frequency band: frequency band within which the device is authorized to operate
associated antenna: antenna and all its associated components which are designed as an indispensable part of the
equipment
average time: time interval on which a mean measurement is integrated
blanking period: time period where no intentional emission occurs
channel dwell duty: ratio of the time of uninterrupted continuous transmission within a given frequency channel to the
channel repetition interval (= channel dwell time/channel repetition interval)
channel dwell time: accumulated amount of transmission time of uninterrupted continuous transmission within a single
given frequency channel and within one channel repetition interval
duty cycle: the ratio of the total on time of the "message" to the total off-time in any one hour period
Equipment Under Test (EUT): radar sensor including the integrated antenna together with any external antenna
components which affect or influence its performance
equivalent isotropically radiated power (e.i.r.p.): total power or power density transmitted, assuming an isotropic
radiator
NOTE: e.i.r.p. is conventionally the product of "power or power density into the antenna" and "antenna gain".
e.i.r.p. is used for both peak or average power and peak or average power density.
equivalent pulse power duration: duration of an ideal rectangular pulse which has the same content of energy
compared with the pulse shape of the EUT with pulsed modulation or time gating
far field measurements: distance "X" should be a minimum of 2d /λ , where d = largest dimension of the antenna
aperture of the EUT
maximum safe level for radiated power density: level which can be transmitted in accordance with the current
recommended safety levels in EN 50166-2 should be done on the vehicle
ETSI
9 ETSI EN 301 091-1 V1.2.1 (2004-11)
mean power: supplied from the antenna during an interval of time sufficiently long compared with the lowest
frequency encountered in the modulation taken under normal operating conditions (see Radio Regulations [8])
NOTE: For pulsed systems the mean power is equal the peak envelope power multiplied by the time gating duty
factor. For CW systems without further time gating the mean power is equal the transmission power
without modulation.
on-off gating: methods of transmission with fixed or randomly quiescent period that is much larger than the PRF
operating frequency (operating centre frequency): nominal frequency at which equipment is operated
NOTE: Equipment may be able to operate at more than one operating frequency.
operating frequency range: range of operating frequencies over which the equipment can be adjusted through
switching or reprogramming or oscillator tuning
NOTE 1: For pulsed or phase shifting systems without further carrier tuning the operating frequency range is fixed
on a single carrier line.
NOTE 2: For analogue or discrete frequency modulated systems (FSK, FMCW) the operating frequency range
covers the difference between minimum and maximum of all carrier frequencies on which the equipment
can be adjusted.
peak envelope power: mean power (round mean square for sinusoidal carrier wave type) supplied from the antenna
during one radio frequency cycle at the crest of the modulation envelope taken under normal operating conditions (see
Radio Regulations)
Power Spectral Density (PSD): ratio of the amount of power to the used radio measurement bandwidth
NOTE: It is expressed in units of dBm/Hz or as a power in unit dBm with respect to the used bandwidth. In case
of measurement with a spectrum analyser the measurement bandwidth is equal the RBW.
Pulse Repetition Frequency (PRF): inverse of the Pulse Repetition Interval, averaged over a time sufficiently long as
to cover all PRI variations
Pulse Repetition Interval (PRI): time between the rising edges of the transmitted (pulsed) output power
quiescent period: time instant where no emission occurs
radiated spurious emissions: emissions at frequencies other than those of the carrier and sidebands associated with
normal modulation
radome: external protective cover which is independent of the associated antenna, and which may contribute to the
overall performance of the antenna (and hence, the EUT)
spatial radiated power density: power per unit area normal to the direction of the electromagnetic wave propagation
NOTE: It is expressed in units of W/m .
spread spectrum: modulation technique in which the energy of a transmitted signal is spread throughout a relatively
large portion of the frequency spectrum
ETSI
10 ETSI EN 301 091-1 V1.2.1 (2004-11)
3.2 Symbols
For the purposes of the present document, the following symbols apply:
λ Wavelength
1/P repetition rate of the modulation wave form
ac alternating current
B Bandwidth
d largest dimension of the antenna aperture
D antenna scan Duty factor
dB decibel
dBi gain in decibels relative to an isotropic antenna
df spectral distance between 2 lines with similar power levels
Δfmax maximum frequency shift between any two frequency steps
Δfmin minimum frequency shift between any two frequency steps
E Field strength
E Reference field strength
o
G Blank time period
P Period of time during in which one cycle of the modulation wave form is completed
P mean power within the BW
a
P Power of an individual spectral Line
L
P Radiated power
rad
R distance
R Reference distance
o
τ Pulse width
T Chip period
c
3.3 Abbreviations
For the purposes of the present document, the following abbreviations apply:
ASK Amplitude Shift Keying
CW Continuous Wave
DSS Direct Sequence Signal
e.i.r.p. equivalent isotropically radiated power
ECC Electronic Communications Committee
EMC ElectroMagnetic Compatibility
ERC European Radiocommunication Committee
EUT Equipment Under Test
FM Frequency Modulation
FMCW Frequency Modulated Continuous Wave
FMICW Frequency Modulated Interrupted Continuous Wave
FSK Frequency Shift Keying
IF Intermediate Frequency
IFSK Interrupted Frequency Shift Keying
OATS Open Area Test Site
PN Pseudo Noise
PRF Pulse Repetition Frequency
PRI Pulse Repetition Interval
R&TTE Radio and Telecommunications Terminal Equipment
RBW Resolution BandWidth
RF Radio Frequency
RMS Root Mean Square
Rx Receiver
SRD Short Range Device
Tx Transmitter
VSWR Voltage Standing Wave Ratio
ETSI
11 ETSI EN 301 091-1 V1.2.1 (2004-11)
4 Technical requirements specifications
4.1 Presentation of equipment for testing purposes
Each equipment submitted for testing, where applicable, shall fulfil the requirements of the present document on all
frequencies over which it is intended to operate. EMC type approval testing to Directive 95/54/EEC [6] shall be done on
the vehicle.
The provider shall provide one or more samples of the equipment, as appropriate for testing.
Additionally, technical documentation and operating manuals, sufficient to allow testing to be performed, shall be
supplied.
The performance of the equipment submitted for testing shall be representative of the performance of the corresponding
production model. In order to avoid any ambiguity in that assessment, the present document contains instructions for the
presentation of equipment for testing purposes, conditions of testing (see clause 5) and the measurement methods
(see clauses 7 and 8).
Stand alone equipment for testing shall be offered by the provider complete with any ancillary equipment needed for
testing. The provider shall declare the frequency range(s), the range of operation conditions and power requirements, as
applicable, in order to establish the appropriate test conditions.
The EUT will comprise the sensor, antenna and radome if needed and will be tested as a stand alone assembly. The
EUTs test fixtures may be supplied by the provider to facilitate the tests (see clause 6.1).
These clauses are intended to give confidence that the requirements set out in the document have been met without the
necessity of performing measurements on all frequencies.
4.1.1 Choice of model for testing
If an equipment has several optional features, considered not to affect the RF parameters then the tests need only to be
performed on the equipment configured with that combination of features considered to be the most complex, as
proposed by the provider and agreed by the test laboratory.
4.2 Mechanical and electrical design
The equipment submitted by the provider shall be designed, constructed and manufactured in accordance with good
engineering practice and with the aim of minimizing harmful interference to other equipment and services.
Transmitters and receivers may be individual or combination units.
4.3 Auxiliary test equipment
All necessary test signal sources and set-up information shall accompany the equipment when it is submitted for testing.
4.4 Interpretation of the measurement results
The interpretation of the results recorded on the appropriate test report for the measurements described in the present
document shall be as follows:
• the measured value relating to the corresponding limit shall be used to decide whether an equipment meets the
requirements of the present document;
• the measurement uncertainty value for the measurement of each parameter shall be included in the test report;
• the recorded value of the measurement uncertainty shall, for each measurement, be equal to, or lower than, the
figures in the table of measurement uncertainty (see clause 9).
ETSI
12 ETSI EN 301 091-1 V1.2.1 (2004-11)
5 Test conditions, power sources and ambient
temperatures
5.1 Normal and extreme test conditions
Testing shall be made under normal test conditions, and also, where stated, under extreme test conditions.
The test conditions and procedures shall be as specified in clauses 5.2 to 5.4.
5.2 External test power source
During tests the power source of the equipment shall be an external test power source, capable of producing normal and
extreme test voltages as specified in clauses 5.3.2 and 5.4.2. The internal impedance of the external test power source
shall be low enough for its effect on the test results to be negligible.
The test voltage shall be measured at the point of connection of the power cable to the equipment.
During tests the external test power source voltages shall be within a tolerance of ±1 % relative to the voltage at the
beginning of each test. The level of this tolerance can be critical for certain measurements. Using a smaller tolerance
provides a reduced uncertainty level for these measurements.
5.3 Normal test conditions
5.3.1 Normal temperature and humidity
The normal temperature and humidity conditions for tests shall be any convenient combination of temperature and
humidity within the following ranges:
• temperature: +15°C to +35°C;
• relative humidity: 20 % to 75 %.
When it is impracticable to carry out tests under these conditions, a note to this effect, stating the ambient temperature
and relative humidity during the tests, shall be added to the test report.
5.3.2 Normal test power source
The internal impedance of the test power source shall be low enough for its effect on the test results to be negligible.
For the purpose of the tests, the voltage of the external test power source shall be measured at the input terminals of the
equipment.
5.3.2.1 Mains voltage
The normal test voltage for equipment shall be the nominal mains voltage. For the purpose of the present document, the
nominal voltage shall be the declared voltage, or any of the declared voltages, for which the equipment was designed.
The frequency of the test power source corresponding to the ac mains shall be between 49 Hz and 51 Hz.
5.3.2.2 Other power sources
For operation from other power sources the normal test voltage shall be that declared by the provider. Such values shall
be stated in the test report.
ETSI
13 ETSI EN 301 091-1 V1.2.1 (2004-11)
5.4 Extreme test conditions
5.4.1 Extreme temperatures
5.4.1.1 Procedure for tests at extreme temperatures
Before measurements are made, the equipment shall have reached thermal balance in the test chamber. The equipment
shall not be switched off during the temperature stabilizing period.
If the thermal balance is not checked by measurements, a temperature stabilizing period of at least one hour, or such
period as may be decided by the accredited test laboratory, shall be allowed. The sequence of measurements shall be
chosen, and the humidity content in the test chamber shall be controlled so that excessive condensation does not occur.
5.4.1.2 Extreme temperature ranges
For tests at extreme temperatures, measurements shall be made in accordance with the procedures specified in
clause 5.4.1.1, at the upper and lower temperatures of the following limits:
• temperature: -20°C to +55°C.
5.4.2 Extreme test source voltages
5.4.2.1 Mains voltage
The extreme test voltages for equipment to be connected to an ac mains source shall be the nominal mains voltage
±10 %.
5.4.2.2 Other power sources
For equipment using other power sources, or capable of being operated from a variety of power sources, the extreme
test voltages shall be that declared by the provider. These shall be recorded in the test report.
6 General conditions
Detailed descriptions of the radiated measurement arrangements are included in annexes A and B. In general,
measurements should be carried out under far field conditions; however, relative power measurements in the 76 GHz to
77 GHz frequency band could be carried out in the near field by using the test fixture as described in clause 6.1 and
shown in figure 1.
The far field condition for the EUTs is considered to be fulfilled in a minimum radial distance "X" that shall be a
minimum of 2d /λ , where d = largest dimension of the antenna aperture of the EUT, for a single device measurement.
Absolute power measurements shall be made only in the far field. This prohibits the use of the test fixture shown in
figure 1.
Each test site shall meet the appropriate requirements as defined in published guidelines/standards (e.g. for OATS, the
requirements are defined in CISPR 16-1 [3]).
6.1 Test fixture
The test fixture for radio equipment operating in the 76 GHz to 77 GHz range enables the EUT to be physically
supported, together with a wave guide horn antenna (which is used to couple/sample the transmitted energy), in a fixed
physical relationship. The test fixture shall be designed for use in an anechoic environment and allows certain
measurements to be performed in the near field. Only relative or comparative measurements may be performed, and
only those at the frequencies in the 76 GHz to 77 GHz band over which the test fixture has been calibrated. A sketch of
a test fixture is depicted in figure 1.
ETSI
14 ETSI EN 301 091-1 V1.2.1 (2004-11)
The test fixture incorporates at least one 50 Ω RF connector and a device for electromagnetic coupling to the EUT. It
incorporates a means for repeatable positioning of the EUT. Its compactness enables the whole assembly to be
accommodated within a test chamber, usually a climatic facility. Only after it has been verified that the test fixture does
not affect performance of the EUT, can the EUT be confidently tested.
At set-up, the EUT shall be aligned in the test fixture so that the maximum power is detected at the coupled output.
Orientation of the horn antenna will take into account the polarization of the EUT.
In addition, the test fixture shall provide a connection to an external power supply.
The test fixture shall be provided by the provider together with a full description, which shall meet the approval of the
selected accredited test laboratory.
The performance characteristics of the test fixture shall be measured and shall be approved by the accredited test
laboratory. It shall conform to the following basic parameters:
• the gain of the waveguide horn shall not exceed 20 dB;
• the physical distance between the front face of the EUT and the waveguide horn shall be between 50 cm and
60 cm;
• the physical height between the centre of the EUT and the supporting structure of the test fixture shall be
between 50 cm and 60 cm;
NOTE: Information on uncertainty contributions, and verification procedures are detailed in clauses 5 and 6,
respectively, of TR 102 273-2 [7].
• circuitry associated with the RF coupling shall contain no active or non-linear devices;
• the Voltage Standing Wave Ratio (VSWR) at the waveguide flange at which measurements are made shall not
be greater than 1,5: 1 over the frequency range of the measurements;
• the performance of the test fixture when mounted in the anechoic environment, on an open test site, or in a
temperature chamber, shall be unaffected by the proximity of surrounding objects or people outside the
environment. The performance shall be reproducible if the EUT is removed and then replaced;
• the performance of the test fixture shall remain within the defined limits of the calibration report, when the test
conditions are varied over the limits described in clauses 5.3 and 5.4.
6.1.1 Calibration
The calibration of the test fixture establishes the relationship between the detected output from the test fixture, and the
transmitted power (as sampled at the position of the antenna) from the EUT in the test fixture. This can be achieved by
using a calibrat
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
Loading comments...
