SIST EN 12311-2:2013

Flexible sheets for waterproofing - Determination of tensile properties - Part 2: Plastic and rubber sheets for roof waterproofing

This European Standard specifies test methods for the determination of the tensile properties of plastic and rubber sheets for roof waterproofing.

Abdichtungsbahnen - Bestimmung des Zug-Dehnungsverhaltens - Teil 2: Kunststoff- und Elastomerbahnen für Dachabdichtungen

Diese Europäische Norm legt Verfahren zur Bestimmung der Zugeigenschaften von Kunststoff- und Elastomer¬bahnen zur Dachabdichtung fest.

Feuilles souples d'étanchéité - Détermination des propriétés en traction - Partie 2 : Feuilles d'étanchéité de toiture plastiques et élastomères

La présente Norme européenne décrit des méthodes d’essai pour la détermination des propriétés en traction des feuilles d’étanchéité de toiture plastiques et élastomères.

Hidroizolacijski trakovi - Ugotavljanje nateznih lastnosti - 2. del: Polimerni in elastomerni trakovi za tesnjenje streh

Ta evropski standard določa preskusne metode za ugotavljanje nateznih lastnosti polimernih in elastomernih trakov za tesnjenje streh.

General Information

• Status: Published
• Public Enquiry End Date: 14-Jan-2013
• Publication Date: 01-Aug-2013
• ICS: 91.060.20 - Roofs
• ICS: 91.100.50 - Binders. Sealing materials
• Technical Committee: VLA - Water proofing
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 11-Jun-2013
• Due Date: 16-Aug-2013
• Completion Date: 02-Aug-2013
• Directive: 305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
• Directive: 89/106/EEC - Construction products
• Mandate: M/102 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on membranes
• Ref Project: EN 12311-2:2013 - Flexible sheets for waterproofing - Determination of tensile properties - Part 2: Plastic and rubber sheets for roof waterproofing

Relations

• Replaces: SIST EN 12311-2:2010 - Flexible sheets for waterproofing - Determination of tensile properties - Part 2: Plastic and rubber sheets for roof waterproofing
• Effective Date: 01-Sep-2013

Overview

EN 12311-2:2013 - Flexible sheets for waterproofing: Determination of tensile properties - Part 2 covers standardized laboratory methods to determine the tensile properties of plastic and rubber sheets for roof waterproofing. Published by CEN, this European Standard is used to characterise products as supplied (before installation). It replaces EN 12311-2:2010 and is intended for product specification, quality control and comparison across manufacturers.

Key topics and technical requirements

• Scope: Applies to plastic and elastomeric roof waterproofing sheets; not to installed membrane systems.
• Test principle: Uniform grip-separation at a constant speed until rupture; continuous recording of force and elongation.
• Specimen preparation:
  • Two sets of specimens (5 each) for longitudinal and transverse directions unless otherwise specified.
  • Methods: Method A (rectangular 50 × 200 mm) and Method B (dumb-bell 6 × 115 mm or rectangular 15 × 170 mm).
  • Cut specimens ≥ (100 ± 10) mm from sheet edges; remove non‑permanent surface layers.
  • Conditioning: (23 ± 2) °C and (50 ± 5) % RH for at least 20 h.
• Apparatus & parameters:
  • Tensile testing machine with continuous recording, minimum 2 000 N capacity.
  • Grip separation speeds: (5 ± 1), (100 ± 10) and (500 ± 50) mm/min depending on test objective (e.g., Young’s/ secant modulus, general tensile, or high-elongation products).
  • Grip slip limits: ≤ 1 mm (≤ 3 mm thick products) or ≤ 2 mm (thicker). Use an extensometer when slip exceeds limits.
  • Force-measuring system accuracy: at least Class 2 per EN ISO 7500-1 (±2 %).
• Measured results:
  • Maximum tensile force, elongation at maximum force, elongation at break.
  • Reported as N/50 mm (Method A) or N/mm² (Method B, based on effective thickness per EN 1849-2).
  • Precision data from a Round Robin (nine labs) are given (e.g., general mean max tensile force ≈ 1 224 N/50 mm; reproducibility R = 170).
• Test report: Must reference EN 12311-2 and include sampling details (EN 13416), specimen prep, test speeds, grip distance, and individual values.

Applications and users

• Product manufacturers and quality control labs for roof waterproofing membranes
• Specifiers, testing laboratories and certification bodies assessing tensile strength, elongation and modulus
• R&D teams comparing formulations (PVC, TPO, EPDM, etc.) or reinforcement types
• Procurement and compliance teams requiring harmonized product performance data

Related standards

• EN 1849-2 (thickness / mass per unit area)
• EN 13416 (sampling rules)
• EN ISO 7500-1 (calibration of testing machines)
• EN 1548, EN 1847 (related exposure/characterisation methods)

Keywords: EN 12311-2:2013, tensile properties, flexible sheets for waterproofing, plastic and rubber sheets, roof waterproofing, tensile test, Method A, Method B, tensile stress, elongation.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Hidroizolacijski trakovi - Ugotavljanje nateznih lastnosti - 2. del: Polimerni in elastomerni trakovi za tesnjenje strehAbdichtungsbahnen - Bestimmung des Zug-Dehnungsverhaltens - Teil 2: Kunststoff- und Elastomerbahnen für DachabdichtungenFeuilles souples d'étanchéité - Détermination des propriétés en traction - Partie 2 : Feuilles d'étanchéité de toiture plastiques et élastomèresFlexible sheets for waterproofing - Determination of tensile properties - Part 2: Plastic and rubber sheets for roof waterproofing91.100.50Veziva. Tesnilni materialiBinders. Sealing materials91.060.20StreheRoofsICS:Ta slovenski standard je istoveten z:EN 12311-2:2013SIST EN 12311-2:2013en,fr,de01-september-2013SIST EN 12311-2:2013SLOVENSKI
STANDARDSIST EN 12311-2:20101DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 12311-2
May 2013 ICS 91.100.50 Supersedes EN 12311-2:2010English Version
Flexible sheets for waterproofing - Determination of tensile properties - Part 2: Plastic and rubber sheets for roof waterproofing
Feuilles souples d'étanchéité - Détermination des propriétés en traction - Partie 2 : Feuilles d'étanchéité de toiture plastiques et élastomères
Abdichtungsbahnen - Bestimmung des Zug-Dehnungsverhaltens - Teil 2: Kunststoff- und Elastomerbahnen für Dachabdichtungen This European Standard was approved by CEN on 28 March 2013.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2013 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 12311-2:2013: ESIST EN 12311-2:2013

According to the CEN-CENELEC Internal Regulations, the national standards organisations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom.
EN 1849-2, Flexible sheets for waterproofing — Determination of thickness and mass per unit area — Part 2: Plastic and rubber sheets
EN 13416, Flexible sheets for waterproofing — Bitumen, plastic and rubber sheets for roof waterproofing — Rules for sampling EN ISO 7500-1, Metallic materials — Verification of static uniaxial testing machines — Part 1: Tension/compression testing machines — Verification and calibration of the force-measuring system (ISO 7500-1) 3 Terms and definitions For the purposes of this document, the following terms and definitions apply. 3.1 top surface upper side of the sheet, as used in situ Note 1 to entry: This is usually the inside of the roll. 3.2 maximum tensile force largest value of tensile force recorded during testing 3.3 elongation at maximum tensile force elongation of the test specimen at the maximum tensile force 3.4 elongation at break elongat
...
