SIST EN 12953-6:2025
(Main)Shell Boilers - Part 6: Requirements for equipment for the boiler
Shell Boilers - Part 6: Requirements for equipment for the boiler
This part of this European Standard specifies the minimum requirements for safety related equipment for shell boilers as defined in EN 12953-1, to ensure the boiler operates within the allowable limits (pressure, temperature, etc.) and if the limits are exceeded the energy supply shall be interrupted and locked out without manual (human) intervention at the boiler.
NOTE 1 The maximum time of operation without manual (human) intervention should be defined for each boiler system.
NOTE 2 Annex C (informative) gives recommendations of operation and testing of the boiler system with a maximum time of operation without manual (human) intervention of 72 hours.
Großwasserraumkessel - Teil 6: Anforderungen an die Ausrüstung für den Kessel
Chaudières à tube de fumée - Partie 6: Exigences pour l'équipement de la chaudière
Le présent document spécifie les exigences minimales pour l'équipement relatif à la sécurité des chaudières à tubes de fumée (générateurs et/ou ensembles) spécifiées dans l'EN 12953 1:2012, afin de garantir que la chaudière fonctionne dans les limites admissibles (pression, température, etc.) et, dans le cas où les limites seraient dépassées, que l'alimentation en énergie est interrompue et verrouillée automatiquement, indépendamment du degré d'intervention.
NOTE 1 Dans le cadre du présent document, le terme « chaudière » s'applique aux générateurs et/ou ensembles.
NOTE 2 La durée maximale de fonctionnement sans intervention manuelle (humaine) peut être spécifiée pour chaque système de chaudière.
NOTE 3 L'Annexe C donne des recommandations de fonctionnement et d'essai du système de chaudière avec une durée maximale de fonctionnement sans intervention manuelle (humaine) de 24 h et 72 h.
