SIST EN ISO 19085-12:2025
(Main)Woodworking machines - Safety - Part 12: Tenoning/profiling machines (ISO 19085-12:2024)
Woodworking machines - Safety - Part 12: Tenoning/profiling machines (ISO 19085-12:2024)
This document specifies the safety requirements and measures for manually loaded and unloaded
— single-end tenoning machines with a manual feed sliding table,
— single-end tenoning machines with a mechanical feed sliding table,
— single-end tenoning-profiling machines with mechanical feed,
— double-end tenoning-profiling machines with mechanical feed, also designed to be automatically either loaded or unloaded, or both, and
— angular systems for tenoning and profiling with mechanical feed
with maximum workpiece height capacity of 200 mm for single-end machines and 500 mm for double-end machines, capable of continuous production use, altogether referred to as “machines”.
This document deals with all significant hazards, hazardous situations and events as listed in Annex A, relevant to machines, when operated, adjusted and maintained as intended and under the conditions foreseen by the manufacturer including reasonably foreseeable misuse. Also, transport, assembly, dismantling, disabling and scrapping phases have been taken into account.
The machines are designed to process in one pass one end or two sides, either opposite or perpendicular to each other, of workpieces made of
a) solid wood, and
b) materials with similar physical characteristics to wood (see ISO 19085-1:2021, 3.2); and
c) only the machines with mechanical feed, made of
d) fibre-cement,
e) rock wool and glass wool,
f) gypsum,
g) plasterboard,
h) matrix engineered mineral boards, silicate boards and sulfate boards,
i) composite materials with core consisting of polyurethane or mineral material laminated with light alloy,
j) polymer-matrix composite materials and reinforced thermoplastic, thermoset and elastomeric materials,
k) aluminium light alloy profiles, and
l) composite boards made from the materials listed above.
This document is also applicable to machines fitted with one or more of the following devices or additional working units, whose hazards have been dealt with:
— sanding units;
— fixed or movable workpiece support;
— automatic tool changing;
— automatic workpiece returner;
— glass bead saw unit;
— hinge recessing unit;
— boring unit;
— dynamic processing unit;
— sawing unit installed out of the integral enclosure, between machine halves in double-end machines;
— foiling unit;
— coating unit;
— grooving unit with a milling tool installed out of the integral enclosure, between machine halves;
— brushing unit;
— gluing unit;
— sealing unit;
— dowels inserting unit;
— tongues inserting unit;
— inkjet marking unit;
— laser marking unit;
— labelling unit;
— workpiece back-up device (device that is either anti-chipping or anti-splintering, or both);
— quick tool changing system;
— post-formed edge pre-cutting unit;
— additional workpiece support (at either infeed or outfeed, or both);
— parallel infeed device on single-end machines;
— transversal infeed device on single-end machines;
— intermediate workpiece support on double-end machines;
— automatic infeed device;
— feed chain with dogs.
This document does not deal with any hazards related to:
a) systems for automatic loading and unloading of the workpiece to a single machine other than automatic workpiece returner;
b) single machine being used in combination with any other machine (as part
Holzbearbeitungsmaschinen - Sicherheit - Teil 12: Zapfenschneid- und Schlitzmaschinen/Profiliermaschinen (ISO 19085-12:2024)
Dieses Dokument stellt Sicherheitsanforderungen und Maßnahmen zur Verfügung für stationäre, manuell be- und entladene:
- einseitige Zapfenschneid- und Schlitzmaschinen mit handbetätigtem Vorschubtisch;
- einseitige Zapfenschneid- und Schlitzmaschinen mit mechanischem Vorschubtisch;
- einseitige Zapfenschneid- und Schlitzmaschinen und/oder Profiliermaschinen mit mechanischem Vorschub;
- doppelseitige Zapfenschneid- und Schlitzmaschinen und/oder Profiliermaschinen mit mechanischem Vorschub, auch wenn sie für automatische Beschickung/Entnahme gestaltet sind;
- Winkelanlagen für das Zapfenschneiden/Schlitzen und Profilieren mit mechanischem Vorschub,
mit Handbeschickung und -entnahme und einer größten Werkstückhöhenkapazität von 200 mm für einseitige Maschinen und 500 mm für doppelseitige Maschinen, nachfolgend als „Maschinen“ bezeichnet.
Es behandelt alle im Abschnitt 4 aufgeführten signifikanten Gefährdungen, Gefährdungssituationen und Gefährdungsereignisse, die auf die Maschinen zutreffen, wenn sie bestimmungsgemäß und entsprechend den vorhersehbaren Bedingungen des Herstellers verwendet, eingestellt und gewartet werden, einschließlich der vernünftigerweise vorhersehbaren Fehlanwendung. Ferner wurden Transport, Zusammenbau, Demontage, Rückbau und Verschrottung berücksichtigt.
ANMERKUNG Hinsichtlich zutreffender, aber nicht signifikanter Gefährdungen, z. B. scharfe Kanten des Maschinengestells, siehe ISO 12100:2010.
Die Maschinen sind so gestaltet, dass sie in einem Durchgang einseitig oder zweiseitig, entweder gegenüberliegend oder senkrecht zueinander, Werkstücke aus
1) Massivholz;
2) Werkstoffen mit ähnlichen physikalischen Eigenschaften wie Holz (siehe ISO 19085-1:2017, 3.2);
3) Faserzement-, Stein-/Glaswolle-, Gips-, Gipskartonplatten, nur bei Maschinen mit mechanischem Vorschub
bearbeiten können.
Es gilt auch für Maschinen, die mit einem oder mehreren der folgenden zusätzlichen Arbeitsaggregate ausgestattet sind, deren Gefährdungen berücksichtigt wurden:
- Schleifaggregate;
- feststehende oder bewegliche Werkstückauflagen;
- automatischer Werkzeugwechsel;
- automatische Werkstück-Rückführung;
- Glasleistensägeaggregat;
- Beschlageinlass-Fräsaggregat;
- Postforming-Aggregat;
- Bohraggregat;
- dynamisches Bearbeitungsaggregat;
- außerhalb der Teilkapselung installiertes Sägeaggregat, das bei doppelseitigen Maschinen zwischen den Maschinenhälften angeordnet ist;
- Aggregat zum Folieren;
- Aggregat zum Beschichten;
- Nutaggregat mit Fräswerkzeugen, das außerhalb der Teilkapselung zwischen den Maschinenhälften angeordnet ist;
- Aggregat zum Bürsten;
- Aggregat zum Beleimen;
- Aggregat zum Versiegeln;
- Aggregat zum Dübelsetzen;
- Aggregat zum Einsetzen von Federn;
- Aggregat zum Beschriften mittels Inkjetdruck;
- Aggregat zum Beschriften mittels Laser;
- Aggregat zum Kennzeichnen;
- Werkstückgegenhalter (Splitterreißschutz);
- Werkzeug-Schnellwechselsystem.
Dieses Dokument behandelt keine Gefährdungen im Zusammenhang mit:
a) Systemen zum automatischen Beschicken und Entnehmen des Werkstücks an einer einzelnen Maschine, ausgenommen die automatische Werkstück-Rückführung;
b) Einzelmaschinen, die in Kombination mit irgendeiner anderen Maschine (als Teil einer Linie) verwendet werden;
c) der Verwendung von Werkzeugen, ausgenommen Sägeblätter oder Fräswerkzeuge zum Nuten, die bei doppelseitigen Maschinen zwischen den Maschinenhälften außerhalb der Teilkapselung angeordnet sind;
d) der Verwendung von Werkzeugen, die über die Teilkapselung hervorstehen;
e) den chemischen Eigenschaften von Faserzement-, Stein-/Glaswolle-, Gips-, Gipskartonplatten und deren Stäuben.
Es gilt nicht für Maschinen, die zur bestimmungsgemäßen Verwendung in potentiell explosiven Atmosphären vorgesehen sind oder Maschinen, die vor seinem Ausgabedatum hergestellt werden.
Machines à bois - Sécurité - Partie 12: Machines à tenonner-profiler (ISO 19085-12:2024)
Le présent document donne les exigences et mesures de sécurité pour les machines fixes, à chargement et déchargement manuels:
— tenonneuses simples à table mobile à avance manuelle;
— tenonneuses simples à table mobile à avance mécanisée;
— machines à tenonner et/ou profiler simples à avance mécanisée;
— machines à tenonner et/ou profiler doubles à avance mécanisée, également conçues pour être chargées/déchargées automatiquement;
— systèmes angulaires pour tenonnage et profilage à avance mécanisée;
ayant une capacité de hauteur de pièce maximale de 200 mm pour les machines simples et de 500 mm pour les machines doubles, ci-après désignées «machines».
Il traite de tous les phénomènes dangereux, situations et événements dangereux significatifs, tels qu'énumérés à l'Article 4, applicables aux machines lorsqu'elles sont utilisées, réglées et entretenues comme prévu et dans les conditions prévues par le fabricant, incluant une mauvaise utilisation raisonnablement prévisible. Les phases de transport, d'assemblage, de démontage, de mise hors service et de mise au rebut sont également prises en compte.
NOTE Pour les phénomènes dangereux pertinents mais non significatifs, par exemple, les arêtes vives du bâti de la machine, voir l'ISO 12100:2010.
Les machines sont conçues pour usiner en une seule passe une extrémité ou deux chants, soit opposés, soit perpendiculaires l'un à l'autre, de pièces constituées de:
1) bois massif;
2) matériaux ayant des caractéristiques physiques similaires à celles du bois (voir l'ISO 19085-1:2017, 3.2);
3) fibre-ciment, laine de roche/verre, plâtre, plaque de plâtre, uniquement avec des machines à avance mécanisée.
Il est également applicable aux machines équipées d'une ou plusieurs des unités de travail supplémentaires suivantes, dont les phénomènes dangereux ont été traités:
— unités de ponçage;
— support de pièce fixe ou mobile;
— changement automatique d'outil;
— dispositif de retour automatique de la pièce;
— unité de sciage de parclose;
— unité de mortaisage;
— unité de précoupe de chant postformé;
— unité d'alésage;
— unité dynamique;
— unité de sciage installée à l'extérieur de l'enceinte intégrée, entre les demi-machines dans les machines doubles;
— unité de placage;
— unité d'enrobage;
— unité de rainurage avec outil de fraisage installée à l'extérieur de l'enceinte intégrée, entre les demi-machines;
— unité de brossage;
— unité de collage;
— unité de scellement;
— unité d'insertion de chevilles;
— unité d'insertion de languettes;
— unité de marquage par jet d'encre;
— unité de marquage par laser;
— unité d'étiquetage;
— dispositif de protection de la pièce (dispositif anti-écaillage/anti-flâches);
— système de changement rapide d'outil.
Le présent document ne traite pas des phénomènes dangereux relatifs:
a) aux systèmes de chargement et déchargement automatiques de la pièce d'une machine simple autres qu'un dispositif de retour automatique de la pièce;
b) à une machine simple utilisée en combinaison avec toute autre machine (comme partie d'une ligne);
c) à l'utilisation d'outils autres que des lames de scie ou des outils de fraisage pour le rainurage, installés entre des demi-machines et à l'extérieur de l'enceinte intégrée dans des ma
Lesnoobdelovalni stroji - Varnost - 12. del: Stroji za izdelovanje čepov in utorov/profilni stroji (ISO 19085-12:2024)
1.1 Ta dokument določa varnostne zahteve in ukrepe za ročno naložene in razložene:
– enostranske stroje za izdelovanje čepov in utorov z drsno mizo za ročno podajanje;
– enostranske stroje za izdelovanje čepov in utorov z drsno mizo za mehansko podajanje;
– enostranske stroje za izdelovanje čepov in utorov ter profilov z mehanskim podajanjem;
– dvostranske stroje za izdelovanje čepov in utorov ter profilov z mehanskim podajanjem, zasnovane tudi s funkcijo samodejnega podajanja ali odvzemanja ali obojim; ter
– kotne sisteme za izdelovanje čepov in utorov ter profilov z mehanskim podajanjem,
z maksimalno višino obdelovanca 200 mm za enostranske stroje in 500 mm za dvostranske stroje, ki jih je mogoče uporabljati za neprekinjeno proizvodnjo (v nadaljevanju »stroji«).
1.2 Ta dokument obravnava vse večje nevarnosti, nevarne situacije in dogodke iz dodatka A v zvezi s stroji, kadar se ti uporabljajo, prilagajajo in vzdržujejo v skladu s svojim namenom ter pod pogoji, ki jih je predvidel proizvajalec, vključno z razumno predvideno nepravilno uporabo. Upoštevane so bile tudi faze transporta, sestavljanja, razstavljanja in razrezovanja stroja.
1.3 Stroji so namenjeni obdelavi enega konca ali obeh koncev (nameščenih nasproti ali pravokotno eden na drugega) obdelovancev iz:
a) masivnega lesa; in
b) materialov, ki imajo podobne fizične lastnosti kot les (glej standard ISO 19085-1:2021, točka 3.2); ter samo za stroje z mehanskim podajalnikom, izdelanim iz
c) vlaknatega cementa;
d) mineralne in steklene volne;
e) mavca;
f) mavčne plošče;
g) mineralnih plošč z matrično strukturo, silikatnih in sulfatnih plošč;
h) kompozitnih materialov z jedrom iz poliuretana ali mineralnih materialov, prevlečenih z lahko zlitino;
i) kompozitnih materialov s polimerno matrico in ojačanih termoplastičnih/termoreaktivnih/elastomernih materialov;
j) profilov iz lahke aluminijeve zlitine;
k) kompozitnih plošč iz zgoraj navedenih materialov.
1.4 Ta dokument se uporablja tudi za stroje, ki so opremljeni z eno ali več naslednjimi napravami oziroma dodatnimi delovnimi enotami, katerih nevarnosti so bile obravnavane:
– enote za brušenje;
– pritrjena ali gibljiva podpora obdelovanca;
– samodejna menjava orodja;
– avtomatski vračalnik obdelovancev;
– rezalna enota za steklene kroglice;
– enota za vstavljanje tečajev;
– enota za izstruževanje;
– enota za dinamično obdelavo;
– enota za žaganje, nameščena zunaj integriranega ohišja, med obema deloma pri dvostranskih strojih;
– enota za zaključno obdelavo s folijo;
– enota za premazovanje;
– enota za podrezovanje s frezalom, nameščena zunaj integriranega ohišja, med obema deloma stroja;
– enota za krtačenje;
– enota za lepljenje;
– enota za tesnjenje;
– enota za vstavljanje moznikov;
– enota za vstavljanje zatičev;
– enota za označevanje z brizganjem;
– enota za lasersko označevanje;
– enota za etiketiranje;
– varnostna naprava za obdelovance (naprava, ki preprečuje drobljenje ali cepljenje ali oboje);
– sistem za hitro menjavo orodja;
– enota za predhodno rezanje zaokroženih robov;
– dodatna podpora obdelovanca (na dovajalni in/ali odvajalni strani);
– naprava za vzporedno dovajanje na enostranskih strojih;
– naprava za prečno dovajanje na enostranskih strojih;
– vmesna podpora obdelovanca na dvostranskih strojih;
– naprava za samodejno podajanje;
– dovajalna veriga z zaskočnimi elementi.
1.5 Ta dokument ne obravnava nevarnosti v zvezi z naslednjim:
a) sistemi za samodejno nalaganje in razlaganje obdelovanca na posamezen stroj, razen avtomatskega vračalnika obdelovancev;
b) kombinirana uporaba posameznega stroja in drugih strojev (kot del proizvodnje);
c) uporaba orodij, razen rezil ali orodij za izstruževanje ali frezal za podrezovanje, nameščenih med obema deloma in zunaj integriranega ohišja pri dvostranskih strojih;
d) uporaba orodij, ki molijo iz integriranega ohišja;
e) kemične lastnosti vseh materialov, navedenih v točkah od 1.3 c) do i), in njihov prah.
1.6 T
General Information
- Status
- Published
- Public Enquiry End Date
- 27-Feb-2023
- Publication Date
- 17-Mar-2025
- Technical Committee
- VSN - Safety of machinery
- Current Stage
- 6060 - National Implementation/Publication (Adopted Project)
- Start Date
- 18-Dec-2024
- Due Date
- 22-Feb-2025
- Completion Date
- 18-Mar-2025
Relations
- Effective Date
- 18-Dec-2024
- Effective Date
- 04-May-2022
Overview
SIST EN ISO 19085-12:2025 (identical to EN ISO 19085-12:2024 / ISO 19085-12:2024) specifies safety requirements for tenoning and profiling woodworking machines. It applies to manually loaded or mechanically fed single-end and double-end tenoning/profiling machines and angular systems intended for continuous production. The standard addresses significant hazards during normal use, adjustment, maintenance and foreseeable misuse, and it also covers transport, assembly, dismantling, disabling and scrapping phases.
Key scope points:
- Machines covered: single-end tenoning (manual/mechanical feed), single-end tenoning‑profiling (mechanical feed), double-end tenoning‑profiling (mechanical feed), and angular systems with mechanical feed.
- Workpiece height limits: 200 mm (single-end) and 500 mm (double-end).
- Materials processed: solid wood, wood-like materials (per ISO 19085-1:2021), and-where mechanical feed is used-various mineral, composite and light-alloy materials listed in the standard.
- Includes many integrated/auxiliary units (sanding, boring, gluing, laser/inkjet marking, automatic tool change, foiling, foiling, etc.).
- Exclusions: systems for automatic loading/unloading to a single machine (beyond automatic workpiece returner) and single machines permanently combined with other machines.
Keywords: SIST EN ISO 19085-12:2025, tenoning-profiling machines, woodworking machine safety, ISO 19085-12, safety requirements.
Key Topics and Technical Requirements
- Control systems and ergonomics: safety and reliability of controls, start/stop functions, mode selection and manual reset.
- Protection against mechanical hazards: guard design (fixed and interlocking), tool design and fixation, stability, break-up prevention, ejection risks and run‑down/braking requirements.
- Power and energy safety: electrical and non-electrical energy supply failure handling, isolation, and safe stopping.
- Monitoring and safety functions: standstill detection, speed monitoring, time delays and safe stopping categories including emergency stop.
- Specific device integration: requirements for machines fitted with sanding units, hinge recessing units, marking units (laser/inkjet), glue/inserting units, feed chains and more.
- Documentation and marking: operator information, warnings, instructions and Annex-based hazard listings (Annex A).
Practical Applications & Who Uses This Standard
- Machine manufacturers: design and certify tenoning/profiling machines to meet safety and regulatory expectations.
- Safety engineers / CE compliance teams: demonstrate conformity with machinery directives (relationship to Directive 2006/42/EC is provided).
- Plant managers & purchasing: specify safe equipment for production lines handling wood and analogous materials.
- Testing laboratories and notified bodies: evaluate machine safety, guards, controls and integrated units.
- Operators and maintenance staff: follow required procedures for safe operation, adjustment and servicing.
Related Standards
- ISO 19085-1:2021 (general terms and safety principles for woodworking machines)
- Other parts of the ISO/EN 19085 series covering specific woodworking machine types and harmonized safety requirements.
This standard is essential for ensuring safe tenoning‑profiling machine design, compliance with European machinery directives and minimizing mechanical and operational risks in woodworking production.
Frequently Asked Questions
SIST EN ISO 19085-12:2025 is a standard published by the Slovenian Institute for Standardization (SIST). Its full title is "Woodworking machines - Safety - Part 12: Tenoning/profiling machines (ISO 19085-12:2024)". This standard covers: This document specifies the safety requirements and measures for manually loaded and unloaded — single-end tenoning machines with a manual feed sliding table, — single-end tenoning machines with a mechanical feed sliding table, — single-end tenoning-profiling machines with mechanical feed, — double-end tenoning-profiling machines with mechanical feed, also designed to be automatically either loaded or unloaded, or both, and — angular systems for tenoning and profiling with mechanical feed with maximum workpiece height capacity of 200 mm for single-end machines and 500 mm for double-end machines, capable of continuous production use, altogether referred to as “machines”. This document deals with all significant hazards, hazardous situations and events as listed in Annex A, relevant to machines, when operated, adjusted and maintained as intended and under the conditions foreseen by the manufacturer including reasonably foreseeable misuse. Also, transport, assembly, dismantling, disabling and scrapping phases have been taken into account. The machines are designed to process in one pass one end or two sides, either opposite or perpendicular to each other, of workpieces made of a) solid wood, and b) materials with similar physical characteristics to wood (see ISO 19085-1:2021, 3.2); and c) only the machines with mechanical feed, made of d) fibre-cement, e) rock wool and glass wool, f) gypsum, g) plasterboard, h) matrix engineered mineral boards, silicate boards and sulfate boards, i) composite materials with core consisting of polyurethane or mineral material laminated with light alloy, j) polymer-matrix composite materials and reinforced thermoplastic, thermoset and elastomeric materials, k) aluminium light alloy profiles, and l) composite boards made from the materials listed above. This document is also applicable to machines fitted with one or more of the following devices or additional working units, whose hazards have been dealt with: — sanding units; — fixed or movable workpiece support; — automatic tool changing; — automatic workpiece returner; — glass bead saw unit; — hinge recessing unit; — boring unit; — dynamic processing unit; — sawing unit installed out of the integral enclosure, between machine halves in double-end machines; — foiling unit; — coating unit; — grooving unit with a milling tool installed out of the integral enclosure, between machine halves; — brushing unit; — gluing unit; — sealing unit; — dowels inserting unit; — tongues inserting unit; — inkjet marking unit; — laser marking unit; — labelling unit; — workpiece back-up device (device that is either anti-chipping or anti-splintering, or both); — quick tool changing system; — post-formed edge pre-cutting unit; — additional workpiece support (at either infeed or outfeed, or both); — parallel infeed device on single-end machines; — transversal infeed device on single-end machines; — intermediate workpiece support on double-end machines; — automatic infeed device; — feed chain with dogs. This document does not deal with any hazards related to: a) systems for automatic loading and unloading of the workpiece to a single machine other than automatic workpiece returner; b) single machine being used in combination with any other machine (as part
This document specifies the safety requirements and measures for manually loaded and unloaded — single-end tenoning machines with a manual feed sliding table, — single-end tenoning machines with a mechanical feed sliding table, — single-end tenoning-profiling machines with mechanical feed, — double-end tenoning-profiling machines with mechanical feed, also designed to be automatically either loaded or unloaded, or both, and — angular systems for tenoning and profiling with mechanical feed with maximum workpiece height capacity of 200 mm for single-end machines and 500 mm for double-end machines, capable of continuous production use, altogether referred to as “machines”. This document deals with all significant hazards, hazardous situations and events as listed in Annex A, relevant to machines, when operated, adjusted and maintained as intended and under the conditions foreseen by the manufacturer including reasonably foreseeable misuse. Also, transport, assembly, dismantling, disabling and scrapping phases have been taken into account. The machines are designed to process in one pass one end or two sides, either opposite or perpendicular to each other, of workpieces made of a) solid wood, and b) materials with similar physical characteristics to wood (see ISO 19085-1:2021, 3.2); and c) only the machines with mechanical feed, made of d) fibre-cement, e) rock wool and glass wool, f) gypsum, g) plasterboard, h) matrix engineered mineral boards, silicate boards and sulfate boards, i) composite materials with core consisting of polyurethane or mineral material laminated with light alloy, j) polymer-matrix composite materials and reinforced thermoplastic, thermoset and elastomeric materials, k) aluminium light alloy profiles, and l) composite boards made from the materials listed above. This document is also applicable to machines fitted with one or more of the following devices or additional working units, whose hazards have been dealt with: — sanding units; — fixed or movable workpiece support; — automatic tool changing; — automatic workpiece returner; — glass bead saw unit; — hinge recessing unit; — boring unit; — dynamic processing unit; — sawing unit installed out of the integral enclosure, between machine halves in double-end machines; — foiling unit; — coating unit; — grooving unit with a milling tool installed out of the integral enclosure, between machine halves; — brushing unit; — gluing unit; — sealing unit; — dowels inserting unit; — tongues inserting unit; — inkjet marking unit; — laser marking unit; — labelling unit; — workpiece back-up device (device that is either anti-chipping or anti-splintering, or both); — quick tool changing system; — post-formed edge pre-cutting unit; — additional workpiece support (at either infeed or outfeed, or both); — parallel infeed device on single-end machines; — transversal infeed device on single-end machines; — intermediate workpiece support on double-end machines; — automatic infeed device; — feed chain with dogs. This document does not deal with any hazards related to: a) systems for automatic loading and unloading of the workpiece to a single machine other than automatic workpiece returner; b) single machine being used in combination with any other machine (as part
SIST EN ISO 19085-12:2025 is classified under the following ICS (International Classification for Standards) categories: 13.110 - Safety of machinery; 79.120.10 - Woodworking machines. The ICS classification helps identify the subject area and facilitates finding related standards.
SIST EN ISO 19085-12:2025 has the following relationships with other standards: It is inter standard links to SIST EN ISO 19085-12:2021/A11:2023, SIST EN ISO 19085-12:2021. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
SIST EN ISO 19085-12:2025 is associated with the following European legislation: EU Directives/Regulations: 2006/42/EC; Standardization Mandates: M/396. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.
You can purchase SIST EN ISO 19085-12:2025 directly from iTeh Standards. The document is available in PDF format and is delivered instantly after payment. Add the standard to your cart and complete the secure checkout process. iTeh Standards is an authorized distributor of SIST standards.
Standards Content (Sample)
SLOVENSKI STANDARD
01-april-2025
Nadomešča:
SIST EN ISO 19085-12:2021/A11:2023
Lesnoobdelovalni stroji - Varnost - 12. del: Stroji za izdelovanje čepov in
utorov/profilni stroji (ISO 19085-12:2024)
Woodworking machines - Safety - Part 12: Tenoning/profiling machines (ISO 19085-
12:2024)
Holzbearbeitungsmaschinen - Sicherheit - Teil 12: Zapfenschneid- und
Schlitzmaschinen/Profiliermaschinen (ISO 19085-12:2024)
Machines à bois - Sécurité - Partie 12: Machines à tenonner-profiler (ISO 19085-
12:2024)
Ta slovenski standard je istoveten z: EN ISO 19085-12:2024
ICS:
13.110 Varnost strojev Safety of machinery
79.120.10 Lesnoobdelovalni stroji Woodworking machines
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
EN ISO 19085-12
EUROPEAN STANDARD
NORME EUROPÉENNE
December 2024
EUROPÄISCHE NORM
ICS 13.110; 79.120.10 Supersedes EN ISO 19085-12:2021
English Version
Woodworking machines - Safety - Part 12: Tenoning-
profiling machines (ISO 19085-12:2024)
Machines à bois - Sécurité - Partie 12: Machines à Holzbearbeitungsmaschinen - Sicherheit - Teil 12:
tenonner-profiler (ISO 19085-12:2024) Zapfenschneid- und
Schlitzmaschinen/Profiliermaschinen (ISO 19085-
12:2024)
This European Standard was approved by CEN on 28 September 2024.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this
European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references
concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN
member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by
translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management
Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway,
Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Türkiye and
United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2024 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN ISO 19085-12:2024 E
worldwide for CEN national Members.
Contents Page
European foreword . 3
Annex ZA (informative) Relationship between this European Standard and the essential
requirements of Directive 2006/42/EC aimed to be covered . 4
European foreword
This document (EN ISO 19085-12:2024) has been prepared by Technical Committee ISO/TC 39
"Machine tools" in collaboration with Technical Committee CEN/TC 142 “Woodworking machines -
Safety” the secretariat of which is held by UNI.
This European Standard shall be given the status of a national standard, either by publication of an
identical text or by endorsement, at the latest by June 2025, and conflicting national standards shall be
withdrawn at the latest by June 2025.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CEN shall not be held responsible for identifying any or all such patent rights.
This document supersedes EN ISO 19085-12:2021.
This document has been prepared under a standardization request addressed to CEN by the European
Commission. The Standing Committee of the EFTA States subsequently approves these requests for its
Member States.
For the relationship with EU Legislation, see informative Annex ZA, which is an integral part of this
document.
Any feedback and questions on this document should be directed to the users’ national standards
body/national committee. A complete listing of these bodies can be found on the CEN website.
According to the CEN-CENELEC Internal Regulations, the national standards organizations of the
following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria,
Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland,
Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Republic of
North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Türkiye and the
United Kingdom.
Endorsement notice
The text of ISO 19085-12:2024 has been approved by CEN as EN ISO 19085-12:2024 without any
modification.
Annex ZA
(informative)
Relationship between this European Standard and the essential
requirements of Directive 2006/42/EC aimed to be covered
This European Standard has been prepared under a Commission’s standardization request “M/396
Mandate to CEN and CENELEC for Standardisation in the field of machinery” to provide one voluntary
means of conforming to essential requirements of Directive 2006/42/EC of the European Parliament
and of the Council of 17 May 2006 on machinery, and amending Directive 95/16/EC (recast).
Once this standard is cited in the Official Journal of the European Union under that Directive,
compliance with the normative clauses of this standard given in Table ZA.1 confers, within the limits of
the scope of this standard, a presumption of conformity with the corresponding essential requirements
of that Directive and associated EFTA regulations.
Table ZA.1 — Correspondence between this European Standard and Annex I of Directive
2006/42/EC
The relevant Essential Requirements of Directive Clause(s)/subclause(s) Remarks/Note
2006/42/EC of this EN s
1.1.2 Principles of safety integration
a) fitted for its function Clauses 4, 5, 6, 7
c) intended use and reasonably foreseeable misuse Clauses 4, 5, 6, 7
d) constraints in use Clauses 4, 5, 6, 7
1.1.3 Materials and products 6.3, 6.16
1.1.4 Lighting 6.6, 7.3.1
1.1.5 Design of machinery to facilitate its handling 6.5, 7.3
1.1.6 Ergonomics 6.5
1.2.1 Safety and reliability of control systems 4.1, 4.3, 6.7, 6.8
1.2.2 Control devices 4.2, 4.3, 4.4, 4.6, 4.7
1.2.3 Starting 4.3
1.2.4 Stopping 4.4, 4.5, 5.4
1.2.5 Selection of control or operating mode 4.6
1.2.6 Failure of the power supply 4.8, 6.7, 6.8, 6.16
1.3.1 Risk of loss of stability 5.1, 7.3
1.3.2 Risk of break-up during operation 4.3, 5.2, 5.3, 5.9, 6.14, 7.3
1.3.3 Risks due to falling or ejected objects 5.2, 5.3, 5.5, 5.8, 5.9, 7.3
1.3.6 Risks relating to variations in the operating 4.6, 4.7, 5.6
conditions
1.3.7 Risks related to moving parts 5.5, 5.6, 5.7, 5.8, 7.3
1.3.8 Choice of protection against risks related to moving 5.6, 5.7, 5.8
parts
1.3.9 Risk of uncontrolled movements 4.1, 4.3, 4.5, 4.8, 5.4
1.4.1 General requirements 5.9
1.4.2.1 Fixed guards 5.5.1
1.4.2.2 Interlocking movable guards 5.5.2
1.4.3 Special requirements for protective devices 5.5.3, 5.5.5, 5.5.6
1.5.1 Electricity supply 6.4, 6.13
1.5.2 Static electricity 6.11
1.5.3 Energy supply other than electricity 6.7, 6.8
1.5.4 Errors of fitting 6.12
1.5.5 Extreme temperatures 6.16
1.5.6 Fire 6.1
1.5.8 Noise 6.2, Annex F
1.5.11 External radiation 6.9
1.5.12 Laser equipment 6.10
1.5.13 Emission of hazardous materials and substances 6.3, 6.17
1.6.1 Machinery maintenance 6.14, 7.3
1.6.2 Access to operating position and servicing points 6.14, 7.3
1.6.3 Isolation of energy sources 6.13, 7.3
1.6.4 Operator intervention 6.14, 7.3
1.6.5 Cleaning of internal parts 6.14, 7.3
1.7.1 Information and warnings on the machinery 6.10, 7.1, 7.2
1.7.2 Warning of residual risks 6.10, 7.1
1.7.3 Marking of machinery 7.2
1.7.4 Instructions 6.10, 7.3, Annex F
2.3 Machinery for working wood and analogous
materials
a) guiding 5.1, 5.10
b) ejection 5.9, 7.3
c) brake 4.5, 5.4
d) accidental tool contact 5.6, 7.3
WARNING 1 — Presumption of conformity stays valid only as long as a reference to this European
Standard is maintained in the list published in the Official Journal of the European Union. Users of this
standard should consult frequently the latest list published in the Official Journal of the European
Union.
WARNING 2 — Other Union legislation may be applicable to the product(s) falling within the scope of
this standard.
International
Standard
ISO 19085-12
Second edition
Woodworking machines — Safety —
2024-11
Part 12:
Tenoning-profiling machines
Machines à bois — Sécurité —
Partie 12: Machines à tenonner-profiler
Reference number
ISO 19085-12:2024(en) © ISO 2024
ISO 19085-12:2024(en)
© ISO 2024
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: +41 22 749 01 11
Email: copyright@iso.org
Website: www.iso.org
Published in Switzerland
ii
ISO 19085-12:2024(en)
Contents Page
Foreword .vi
Introduction .vii
1 Scope . 1
2 Normative references . 3
3 Terms and definitions . 3
4 Safety requirements and measures for controls .16
4.1 Safety and reliability of control systems.16
4.2 Control devices .16
4.2.1 General .17
4.2.2 Single-end tenoning machines with a manual feed sliding table .17
4.2.3 Single-end tenoning machines with a mechanical feed sliding table .17
4.2.4 Single-end tenoning-profiling machines with mechanical feed .17
4.2.5 Double-end tenoning-profiling machines with mechanical feed .17
4.2.6 Angular systems for tenoning and profiling with mechanical feed .17
4.3 Start .18
4.3.1 Direct start .18
4.3.2 Start via control power-on .18
4.3.3 Laser marking unit .18
4.4 Safe stops .18
4.4.1 General .18
4.4.2 Normal stop .19
4.4.3 Operational stop .19
4.4.4 Emergency stop .19
4.5 Braking function of tools .19
4.6 Mode selection .19
4.6.1 Manual adjustments mode for tools and other processing units (MODE 2) .19
4.6.2 Feed chains greasing mode (MODE 3) .19
4.7 Tool speed changing . 20
4.7.1 Speed changing by shifting the belts on the pulleys . 20
4.7.2 Speed changing by incremental speed change motor . 20
4.7.3 Infinitely variable speed by frequency inverter . 20
4.8 Failure of any power supply . 20
4.9 Manual reset control .21
4.10 Standstill detection and monitoring .21
4.11 Machine moving parts speed monitoring.21
4.12 Time delay.21
4.13 Teleservice .21
5 Safety requirements and measures for protection against mechanical hazards .21
5.1 Stability .21
5.2 Risk of break-up during operation .21
5.3 Tool and tool fixing design .21
5.3.1 General .21
5.3.2 Spindle locking . 22
5.3.3 Circular saw blade fixing device . 22
5.3.4 Flange dimensions for circular saw blades . 22
5.3.5 Spindle rings. 22
5.4 Braking . 22
5.4.1 Braking of tools . 22
5.4.2 Maximum run-down time . 22
5.4.3 Brake release . 23
5.5 Safeguards . 23
5.5.1 Fixed guards . 23
5.5.2 Interlocking moveable guards . 23
iii
ISO 19085-12:2024(en)
5.5.3 Hold-to-run control . 23
5.5.4 Two hand control . 23
5.5.5 Electro-sensitive protective equipment (ESPE) . 23
5.5.6 Pressure sensitive protective equipment (PSPE) . 23
5.5.7 Enabling control . 23
5.6 Prevention of access to hazardous moving parts . 23
5.6.1 Single-end tenoning machines with a manual feed sliding table . 23
5.6.2 Single-end tenoning machines with a mechanical feed sliding table .24
5.6.3 Single-end tenoning-profiling machines with mechanical feed . 25
5.6.4 Double-end tenoning-profiling machines with mechanical feed .27
5.6.5 Angular systems for tenoning and profiling with mechanical feed . 30
5.6.6 Guarding of drives .31
5.6.7 Guarding of the chain or feed mechanisms .31
5.7 Impact hazard . 33
5.8 Clamping devices . 33
5.8.1 Single-end tenoning machines with sliding table . 34
5.8.2 Machines other than single-end tenoning machines with sliding table . 34
5.9 Measures against ejection . 34
5.9.1 General . 34
5.9.2 Guards materials and characteristics . 34
5.9.3 Devices to minimize the possibility or effect of ejection or kickback . 35
5.10 Workpiece support and guides . 36
5.10.1 Single-end tenoning machines with sliding table . 36
5.10.2 Single-end tenoning-profiling machines with mechanical feed . 36
5.10.3 Double-end tenoning-profiling machines with mechanical feed .37
5.10.4 Angular systems for tenoning and profiling with mechanical feed .37
5.10.5 Automatic workpiece returner .37
5.10.6 Parallel infeed device . 38
5.10.7 Transversal infeed device . 39
5.10.8 Automatic infeed device . 39
5.10.9 Additional workpiece support at the outfeed . 40
6 Safety requirements and measures for protection against other hazards . 41
6.1 Fire .41
6.2 Noise .41
6.2.1 Noise reduction at the design stage .41
6.2.2 Noise emission measurement and declaration .41
6.3 Emission of chips and dust .41
6.4 Electricity .41
6.5 Ergonomics and handling .41
6.6 Lighting .42
6.7 Pneumatics .42
6.8 Hydraulics .42
6.9 Electromagnetic compatibility.42
6.10 Laser .42
6.11 Static electricity.42
6.12 Errors of fitting .42
6.13 Isolation .42
6.14 Maintenance .42
6.15 Relevant but not significant hazards .42
6.16 Extreme temperatures .43
6.17 Substances .43
7 Information for use .43
7.1 Warning devices .43
7.2 Marking .43
7.2.1 General .43
7.2.2 Additional markings .43
7.3 Instruction handbook. 44
7.3.1 General . 44
iv
ISO 19085-12:2024(en)
7.3.2 Additional information . 44
Annex A (informative) List of significant hazards .46
Annex B (informative) Performance levels required .48
Annex C (informative) Stability test .50
Annex D (normative) Test for braking function . 51
Annex E (normative) Impact test for guards . .52
Annex F (normative) Noise test code . .53
Bibliography .62
v
ISO 19085-12:2024(en)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out through
ISO technical committees. Each member body interested in a subject for which a technical committee
has been established has the right to be represented on that committee. International organizations,
governmental and non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely
with the International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are described
in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the different types
of ISO document should be noted. This document was drafted in accordance with the editorial rules of the
ISO/IEC Directives, Part 2 (see www.iso.org/directives).
ISO draws attention to the possibility that the implementation of this document may involve the use of (a)
patent(s). ISO takes no position concerning the evidence, validity or applicability of any claimed patent
rights in respect thereof. As of the date of publication of this document, ISO had not received notice of (a)
patent(s) which may be required to implement this document. However, implementers are cautioned that
this may not represent the latest information, which may be obtained from the patent database available at
www.iso.org/patents. ISO shall not be held responsible for identifying any or all such patent rights.
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and expressions
related to conformity assessment, as well as information about ISO's adherence to the World Trade
Organization (WTO) principles in the Technical Barriers to Trade (TBT), see www.iso.org/iso/foreword.html.
This document was prepared by Technical Committee ISO/TC 39, Machine tools, Subcommittee SC 4,
Woodworking machines, in collaboration with the European Committee for Standardization (CEN) Technical
Committee CEN/TC 142, Woodworking machines – Safety, in accordance with the Agreement on technical
cooperation between ISO and CEN (Vienna Agreement).
This second edition cancels and replaces the first edition (ISO 19085-12:2021), which has been technically
revised. The main changes are as follows:
— the Scope has been revised to specify that machines are intended for continuous production use, and
other workable materials have been added;
— the list of significant hazards has been moved to the new Annex A;
— the feed chains greasing mode (MODE 3) has been added in 4.6.2;
— subclause 6.2 has been updated and a new full noise test code has been added in Annex F;
— optional workpiece supporting devices have been added to the Scope, Clause 3 and 5.10.6 to 5.10.9.
A list of all parts in the ISO 19085 series can be found on the ISO website.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www.iso.org/members.html.
vi
ISO 19085-12:2024(en)
Introduction
The ISO 19085 series provides technical safety requirements for the design and construction of
woodworking machinery, as well as for the content of the relevant instruction handbook. It concerns
designers, manufacturers, suppliers and importers of the machines specified in the Scope.
This document is a type-C standard as stated in ISO 12100:2010.
This document is of relevance, in particular, for the following stakeholder groups representing the market
players with regard to machinery safety:
— machine manufacturers (small, medium and large enterprises);
— health and safety bodies (regulators, accident prevention organisations, market surveillance etc.).
Others can be affected by the level of machinery safety achieved with the means of the document by the
above-mentioned stakeholder groups:
— machine users/employers (small, medium and large enterprises);
— machine users/employees (e.g. trade unions, organizations for people with special needs);
— service providers, e.g. for maintenance (small, medium and large enterprises);
— consumers (in case of machinery intended for use by consumers).
The above-mentioned stakeholder groups have been given the possibility to participate at the drafting
process of this document.
The machinery concerned and the extent to which hazards, hazardous situations or hazardous events are
covered are indicated in the Scope of this document.
When requirements of this type-C standard are different from those which are stated in type-A or type-B
standards, the requirements of this type-C standard take precedence over the requirements of the other
standards for machines that have been designed and built according to the requirements of this type-C
standard.
The full set of requirements for a particular type of woodworking machine are those given in the part of
ISO 19085 applicable to that type, together with the relevant requirements from ISO 19085-1:2021, to the
extent specified in the Scope of the applicable part of the ISO 19085 series.
As far as possible, the safety requirements of parts of the ISO 19085 series refer to the relevant subclauses
of ISO 19085-1:2021. Each part contains replacements and additions to the common requirements given in
ISO 19085-1:2021.
All parts of the ISO 19085 series have the same structure, so that reference to ISO 19085-1:2021 is made
always and only from and to the same subclause number at the last indent level.
Clauses 1 to 3 are specific to each part and, therefore, are distinct from ISO 19085-1:2021, Clauses 1 to 3.
For Clauses 4 to 7 and the annexes, each subclause in ISO 19085-1:2021 is cited as either:
— confirmed as a whole;
— confirmed with additions;
— excluded entirely; or
— replaced with specific text.
This is indicated by one of the following possible statements:
— “ISO 19085-1:2021, [subclause/Annex], applies”;
vii
ISO 19085-12:2024(en)
— “ISO 19085-1:2021, [subclause/Annex], applies with the following additions.” or “ISO 19085-1:2021,
[subclause/Annex], applies with the following additions, subdivided into further specific subclauses.”;
— “ISO 19085-1:2021, [subclause/Annex], does not apply.”;
— “ISO 19085-1:2021, [subclause/Annex], is replaced by the following text.” or “ISO 19085-1:2021,
[subclause/Annex], is replaced by the following text, subdivided into further specific subclauses.”.
Other subclauses and annexes specific to this document are indicated by the introductory sentence:
“Subclause/Annex specific to this document.”.
viii
International Standard ISO 19085-12:2024(en)
Woodworking machines — Safety —
Part 12:
Tenoning-profiling machines
1 Scope
1.1 This document specifies the safety requirements and measures for manually loaded and unloaded
— single-end tenoning machines with a manual feed sliding table,
— single-end tenoning machines with a mechanical feed sliding table,
— single-end tenoning-profiling machines with mechanical feed,
— double-end tenoning-profiling machines with mechanical feed, also designed to be automatically either
loaded or unloaded, or both, and
— angular systems for tenoning and profiling with mechanical feed
with maximum workpiece height capacity of 200 mm for single-end machines and 500 mm for double-end
machines, capable of continuous production use, altogether referred to as “machines”.
1.2 This document deals with all significant hazards, hazardous situations and events as listed in Annex A,
relevant to machines, when operated, adjusted and maintained as intended and under the conditions foreseen
by the manufacturer including reasonably foreseeable misuse. Also, transport, assembly, dismantling,
disabling and scrapping phases have been taken into account.
1.3 The machines are designed to process in one pass one end or two sides, either opposite or perpendicular
to each other, of workpieces made of
a) solid wood, and
b) materials with similar physical characteristics to wood (see ISO 19085-1:2021, 3.2); and
only the machines with mechanical feed, made of
c) fibre-cement,
d) rock wool and glass wool,
e) gypsum,
f) plasterboard,
g) matrix engineered mineral boards, silicate boards and sulfate boards,
h) composite materials with core consisting of polyurethane or mineral material laminated with light alloy,
i) polymer-matrix composite materials and reinforced thermoplastic, thermoset and elastomeric
materials,
j) aluminium light alloy profiles, and
k) composite boards made from the materials listed above.
ISO 19085-12:2024(en)
1.4 This document is also applicable to machines fitted with one or more of the following devices or
additional working units, whose hazards have been dealt with:
— sanding units;
— fixed or movable workpiece support;
— automatic tool changing;
— automatic workpiece returner;
— glass bead saw unit;
— hinge recessing unit;
— boring unit;
— dynamic processing unit;
— sawing unit installed out of the integral enclosure, between machine halves in double-end machines;
— foiling unit;
— coating unit;
— grooving unit with a milling tool installed out of the integral enclosure, between machine halves;
— brushing unit;
— gluing unit;
— sealing unit;
— dowels inserting unit;
— tongues inserting unit;
— inkjet marking unit;
— laser marking unit;
— labelling unit;
— workpiece back-up device (device that is either anti-chipping or anti-splintering, or both);
— quick tool changing system;
— post-formed edge pre-cutting unit;
— additional workpiece support (at either infeed or outfeed, or both);
— parallel infeed device on single-end machines;
— transversal infeed device on single-end machines;
— intermediate workpiece support on double-end machines;
— automatic infeed device;
— feed chain with dogs.
1.5 This document does not deal with any hazards related to:
a) systems for automatic loading and unloading of the workpiece to a single machine other than automatic
workpiece returner;
ISO 19085-12:2024(en)
b) single machine being used in combination with any other machine (as part of a line);
c) use of tools, other than saw blades or boring tools or milling tools for grooving, installed between
machine halves and out of the integral enclosure in double-end machines;
d) use of tools protruding out of the integral enclosure;
e) chemical characteristics of all materials listed in 1.3 c) to i) and their dust.
1.6 This document is not applicable to machines intended for use in potentially explosive atmosphere nor
to machines
...
Die SIST EN ISO 19085-12:2025 ist ein äußerst relevantes Dokument, das die Sicherheitsanforderungen für verschiedene Typen von Maschinen im Bereich der Holzverarbeitung festlegt. Es deckt die Sicherheit für manuell und mechanisch beschickte Tenonier- und Profiliermaschinen ab, einschließlich Einzel- und Doppelendmaschinen mit mechanischem Vorschub. Diese Standardisierung ist besonders wichtig, da sie einen umfassenden Rahmen für den sicheren Betrieb, die Anpassung und die Wartung dieser Maschinen bietet. Ein bedeutender Vorteil dieser Norm ist der umfassende Ansatz zur Risikominderung. Sie behandelt alle wesentlichen Gefahren, Risiken und kritischen Maßnahmen, die während des Betriebs, der Wartung sowie in den Phasen Transport, Montage, Demontage, Deaktivierung und Verschrottung auftreten können. Dies stellt sicher, dass alle Aspekte des Lebenszyklus der Maschinen berücksichtigt werden, was für die Sicherheit und Effizienz in der Holzverarbeitungsindustrie von zentraler Bedeutung ist. Die Dokumentation spezifiziert zudem präzise, dass die Maschinen für die Verarbeitung von Holz sowie von Materialien mit ähnlichen physikalischen Eigenschaften geeignet sind. Diese Breite an Anwendbarkeit macht die Norm für eine Vielzahl von Herstellern und Anwendern relevant, da sie nicht nur den traditionellen Holzverarbeitungsprozess, sondern auch innovative Materialien wie faserzementbasierte Produkte und Verbundwerkstoffe abdeckt. Ein weiterer bemerkenswerter Aspekt ist die Berücksichtigung von Maschinen, die mit zusätzlichen Verarbeitungseinheiten ausgestattet sind. Dies zeigt den Fortschritt in der Technologie und die Notwendigkeit, Sicherheitsstandards zu entwickeln, die mit fortschrittlichen Maschinenkonfigurationen Schritt halten können. Beispielsweise werden Geräte wie automatisierte Werkzeugwechsel, spezielle Bearbeitungseinheiten und andere Hilfseinrichtungen erfasst, was die Umsetzung flexibler und sicherer Arbeitsprozesse ermöglicht. Insgesamt bietet die SIST EN ISO 19085-12:2025 einen soliden und umfassenden Sicherheitsrahmen, der für die Holzverarbeitungsindustrie von entscheidender Bedeutung ist. Durch die präzise Definition der Maschinenarten, die Berücksichtigung umfassender Sicherheitsaspekte sowie die Aufnahme modernster Technologien unterstützt diese Norm die Herstellung sicherer und effizienter Holzverarbeitungsmaschinen, was letztendlich zur Verbesserung der Arbeitsbedingungen und der Produktqualität beiträgt.
SIST EN ISO 19085-12:2025 표준 문서는 목재 가공 기계의 안전성을 높은 수준으로 보장하기 위해 필요한 안전 요구사항과 조치를 명확히 규정하고 있습니다. 특히 이 문서는 수동으로 적재되고 하역되는 단일 엔드 접합 기계, 기계적 공급 슬라이딩 테이블이 장착된 단일 엔드 접합 기계, 기계적 공급 기계가 있는 단일 엔드 접합 및 프로파일링 기계, 자동 하역이 가능하거나 그 이상의 기능을 갖춘 이중 엔드 기계 등의 범위를 포함하고 있습니다. 이 표준은 최대 가공물 높이 200 mm와 500 mm를 가진 기계의 안전 요구사항을 체계적으로 다루며, 문서에서 명시된 모든 주요 위험 요소 및 위험한 상황을 고려하고 있습니다. 이로 인해 사용자들은 기계를 운영하고 조정하며 유지 보수할 때 발생할 수 있는 위험을 사전에 예방할 수 있습니다. 또한, 기계의 운송, 조립, 분해, 비활성화 및 스크랩 단계까지도 고려하여 종합적인 안전성을 확보하고 있습니다. 특히 이 문서에서는 다양한 재료에 대해 착안하였으며, 단단한 목재뿐만 아니라 목재와 유사한 물리적 특성을 가진 다양한 재료들, 복합 재료 및 경량 합금으로 만들어진 알루미늄 프로파일에 대한 가공이 가능하다는 점에서 매우 유용합니다. 더불어 다양한 추가 작업 장치와 장비에 대한 위험을 검토하여, 다양한 가공 요구에 맞춰 적용이 가능합니다. SIST EN ISO 19085-12:2025는 목재 가공 산업에 필수적인 안전 지침을 제공하여 작업자의 안전을 보장할 뿐만 아니라, 기계의 지속 가능한 사용을 위한 기초를 마련하고 있습니다. 이 표준은 목재 가공 기계의 안전성을 높이기 위한 필수 문서로, 해당 산업의 기술적 진보와 안전 표준 준수에 중대한 기여를 하고 있습니다.
SIST EN ISO 19085-12:2025は、木工機械の安全性に関する重要な標準であり、特にテノニングおよびプロファイリング機械に焦点を当てています。このドキュメントは、手動および機械的にフィードされるシングルエンドおよびダブルエンドテノニング機械に関する安全要件と対策を規定しており、最大作業物高さ容量が200mmと500mmの機械に適用されます。 本標準の大きな強みは、関連する全ての重要な危険、危険な状況、及び発生する可能性のある事象に対処している点です。具体的には、Annex Aで列挙されている機械の運用、調整、保守における安全性を確保しています。また、輸送、組み立て、解体、無効化および廃棄に至るまで、あらゆる段階を考慮に入れており、より包括的な安全策を講じています。 さらに、この文書は、様々な素材（無垢材や木材と類似した物理的特性を持つ材料）を処理する機械に適用されるだけでなく、特定の機械的フィードを有する機械が処理可能な多様な材料に関しても取り扱っています。これにより、幅広い加工ニーズに応じた適用性が確保されています。 加えて、機械に取り付けられる追加の作業ユニットや装置についても広範囲にわたる危険要因に対処しており、サンディングユニット、ボーリングユニット、レーザーマーキングユニット等、様々な付属機能が含まれています。このような包括性は、体育的な機械環境における安全性向上に寄与します。 標準が解決しない危険についても明確に記述されており、特定の自動装置等の運用に関する制約が示されています。これにより、ユーザーは適切な安全管理を実行でき、業界での安全性が高まることが期待されます。 全体として、SIST EN ISO 19085-12:2025は、木工機械の安全性向上に向けた重要な指針を提供しており、特に業界での利用が期待される機械の安全基準を確立しています。
Le document de normalisation SIST EN ISO 19085-12:2025 établit des exigences de sécurité précises pour les machines à tenoner et à profiler. Son champ d'application inclut les machines à tenoner à chargement manuel et mécanique, ainsi que celles à double extrémité, adaptées à des configurations spécifiques de production. Cette norme est primordiale pour assurer la sécurité lors de l'opération, de l'ajustement et de l'entretien de ces équipements. Parmi les points forts de cette norme, on peut souligner sa portée approfondie. Elle aborde toutes les dangers significatifs associés aux machines, en tenant compte de différentes situations et événements à risque. Les phases de transport, d’assemblage, de démontage et de destruction sont également incluses, ce qui démontre une approche globale en matière de sécurité. La standardisation des exigences de sécurité définies par la SIST EN ISO 19085-12:2025 est d'une grande pertinence, surtout dans un contexte de production continue. Les spécifications pour différents matériaux à usiner, allant du bois massif aux composites divers, renforcent la flexibilité et l’adaptabilité des machines. Cela permet aux fabricants de satisfaire aux exigences de sécurité tout en répondant aux besoins variés de l'industrie du travail du bois. En outre, la norme traite des machines équipées de divers dispositifs et unités de travail supplémentaires, garantissant ainsi que toutes les facettes des opérations sont couvertes. La reconnaissance des équipements tels que les unités de ponçage, d'usinage dynamique et d'insertion de chevilles montre une anticipation des évolutions technologiques au sein de l'industrie. Enfin, en excluant certaines situations, comme l’utilisation de machines en combinaison avec d'autres équipements, la SIST EN ISO 19085-12:2025 assure une clarté qui facilite son application. Cette norme se présente donc comme un outil essentiel pour les fabricants et les opérateurs de machines à tenoner et à profiler, en visant à créer un environnement de travail sûr et efficace.
The SIST EN ISO 19085-12:2025 standard is a comprehensive document that delineates safety requirements and measures for various tenoning and profiling machines used in woodworking. Its scope is well-defined, covering both manually loaded and unloaded machines, as well as those with mechanical feeds. The standard applies to a diverse range of machines including single-end and double-end tenoning and profiling machines, enhancing its relevance in today’s woodworking industry where versatility and safety are paramount. One of the strengths of this standard is its thorough approach to safety, as it addresses significant hazards associated with these machines. By specifying the circumstances under which machines operate, adjust, and maintain, the standard ensures that manufacturers and operators are aware of potential risks during all operational phases, including transport, assembly, dismantling, disabling, and scrapping. This holistic consideration for safety helps to mitigate hazardous situations that could arise during machine use. Furthermore, the standard's inclusivity in terms of materials processed is a notable strength. It specifies not only solid wood but also a plethora of materials that share similar physical characteristics to wood, thereby accommodating a wide range of applications. This adaptability is crucial for manufacturers that aim to utilize their machinery for various products, thus optimizing production capabilities. The document also introduces guidelines for machines equipped with additional working units and devices, such as sanding units, automatic tool changers, and glue application systems. This allows for enhanced functionality and innovation in woodworking processes. The inclusion of these supplementary features underscores the standard's relevance, as it reflects the ongoing evolution in woodworking technology. Another significant aspect of the SIST EN ISO 19085-12:2025 is its foresight in addressing foreseeable misuse. By recognizing and accounting for reasonable misuse scenarios, the standard reinforces the safety of operators and improves overall trust in the machinery employed in woodworking. In summary, the SIST EN ISO 19085-12:2025 standard offers a robust framework for ensuring the safety of tenoning and profiling machines. Its detailed scope, comprehensive hazard analysis, and consideration of various operational contexts make it an indispensable resource for manufacturers and operators in the woodworking industry. The relevance of this standard in promoting safe machining practices cannot be overstated, as it sets a benchmark for quality and safety in woodworking processes.
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
Loading comments...
