SIST EN ISO 19085-9:2025

Woodworking machines - Safety - Part 9: Circular saw benches (with and without sliding table) (ISO 19085-9:2024)

This document specifies the safety requirements and measures for circular saw benches with or without sliding table and/or demountable power feed unit and capable of continuous production use, also known as “table saws” (in the USA), hereinafter referred to also as “machines”.
The machines are designed to cut wood and material with similar physical characteristics to wood.
It deals with all significant hazards, hazardous situations and events as listed in Annex A relevant to the machines when operated, adjusted and maintained as intended and under the conditions foreseen by the manufacturer; reasonably foreseeable misuse has been considered too. Transport, assembly, dismantling, disabling and scrapping phases have also been taken into account.
It is also applicable to machines fitted with one or more of the following devices, or working unit, whose hazards have been dealt with:
— device for the main saw blade and scoring saw blade to be raised and lowered through the table;
— device to tilt the main saw blade and scoring saw blade for angled cutting;
— device for scoring;
— device for grooving with milling tool with a width not exceeding 20 mm in one pass;
— demountable power feed unit;
— additional manually operated sliding table;
— powered workpiece clamping device.
This document does not apply to:
a) machines intended for outdoor use on building sites;
NOTE 1   Building site saws (contractor saws) are covered by the requirements of ISO 19085 10:2018.
b) handheld woodworking machines including any adaptation permitting their use in a different mode, i.e., bench mounting;
c) machines intended for use in a potentially explosive atmosphere;
d) machines manufactured prior to the date of its publication as an International Standard.

Holzbearbeitungsmaschinen - Sicherheit - Teil 9: Tischkreissägemaschinen (mit und ohne Schiebetisch) (ISO 19085-9:2024)

Machines à bois - Sécurité - Partie 9: Scies circulaires à table de menuisier (avec et sans table mobile) (ISO 19085-9:2024)

Le présent document spécifie les exigences et les mesures de sécurité pour les scies à table de menuisier avec ou sans table mobile ou unité d’avance mécanisée démontable, ou avec table mobile et unité d’avance mécanisée démontable, et capables d’une utilisation en production continue, également connues en tant que «scies à table» (aux États-Unis), ci‑après désignées également «machines».
Les machines sont conçues pour la coupe de bois massif et de matériau présentant des caractéristiques physiques similaires à celles du bois (voir ISO 19085-1:2021, 3.2).
Le présent document traite de tous les phénomènes dangereux, situations dangereuses et événements dangereux significatifs, tels qu’énumérés à l’Annexe A, applicables aux machines lorsqu’elles sont utilisées, réglées et entretenues comme prévu et dans les conditions prévues par le fabricant; une mauvaise utilisation raisonnablement prévisible a été prise en considération également. Les phases de transport, d’assemblage, de démontage, de mise hors service et de mise au rebut ont également été prises en compte.
Le présent document est également applicable aux machines équipées d’un ou plusieurs des dispositifs ou unités de travail suivants, dont les phénomènes dangereux ont été traités:
—     dispositif pour relever et abaisser la lame de scie principale et la lame de scie d’incision par rapport à la table;
—     dispositif pour incliner la lame de scie principale et la lame de scie d'incision pour une coupe en angle;
—     dispositif pour l'incision;
—     dispositif de rainurage à l’aide d’un outil de fraisage ayant une largeur ne dépassant pas 20 mm en une seule passe;
—     unité d’avance mécanisée démontable;
—     table mobile supplémentaire à commande manuelle;
—     dispositif mécanisé de bridage de la pièce.
Le présent document ne s’applique pas:
a)       aux machines destinées à une utilisation en extérieur ou sur les chantiers de construction;
NOTE            Les scies de chantier sont couvertes par les exigences de l’ISO 19085-10:2018.
b)       aux machines à bois portatives, y compris toute adaptation permettant leur utilisation de manière différente, c’est-à-dire, fixées sur un bâti;
c)        aux machines prévues pour une utilisation en atmosphère explosible;
d)       aux machines fabriquées avant la publication du présent document.

Lesnoobdelovalni stroji - Varnost - 9. del: Krožne žage (s podajalno mizo ali brez nje) (ISO 19085-9:2024)

General Information

• Status: Not Published
• Public Enquiry End Date: 11-Sep-2022
• ICS: 13.110 - Safety of machinery
• ICS: 25.080.60 - Sawing machines
• ICS: 79.120.10 - Woodworking machines
• Technical Committee: VSN - Safety of machinery
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 09-Oct-2024
• Due Date: 14-Dec-2024
• Directive: 2006/42/EC - Directive 2006/42/EC of the European Parliament and of the Council of 17 May 2006 on machinery, and amending Directive 95/16/EC (recast)
• Mandate: M/396 - Mandate to CEN and Cenelec for standardisation in the field of machinery
• Ref Project: EN ISO 19085-9:2024 - Woodworking machines - Safety - Part 9: Circular saw benches (with and without sliding table) (ISO 19085-9:2024)

Relations

• Revised: SIST EN ISO 19085-9:2020 - Woodworking machines - Safety - Part 9: Circular saw benches (with and without sliding table) (ISO 19085-9:2019)
• Effective Date: 19-Jan-2023

Standards Content (Sample)

SLOVENSKI STANDARD
oSIST prEN ISO 19085-9:2022
01-september-2022
Lesnoobdelovalni stroji - Varnost - 9. del: Krožne žage (s podajalno mizo ali brez
nje) (ISO/DIS 19085-9:2022)
Woodworking machines - Safety - Part 9: Circular saw benches (with and without sliding
table) (ISO/DIS 19085-9:2022)
Holzbearbeitungsmaschinen - Sicherheit - Teil 9: Tischkreissägemaschinen (mit und
ohne Schiebetisch) (ISO/DIS 19085-9:2022)
Machines à bois - Sécurité - Partie 9: Scies circulaires à table de menuisier (avec et
sans table mobile) (ISO/DIS 19085-9:2022)
Ta slovenski standard je istoveten z: prEN ISO 19085-9
ICS:
13.110 Varnost strojev Safety of machinery
25.080.60 Strojne žage Sawing machines
79.120.10 Lesnoobdelovalni stroji Woodworking machines
oSIST prEN ISO 19085-9:2022 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

oSIST prEN ISO 19085-9:2022
oSIST prEN ISO 19085-9:2022
DRAFT INTERNATIONAL STANDARD
ISO/DIS 19085-9
ISO/TC 39/SC 4 Secretariat: UNI
Voting begins on: Voting terminates on:
2022-06-23 2022-09-15
Woodworking machines — Safety —
Part 9:
Circular saw benches (with and without sliding table)
Machines à bois — Sécurité —
Partie 9: Scies circulaires à table de menuisier (avec et sans table mobile)
ICS: 79.120.10; 13.110
This document is circulated as received from the committee secretariat.
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
ISO/CEN PARALLEL PROCESSING
THEREFORE SUBJECT TO CHANGE AND MAY
NOT BE REFERRED TO AS AN INTERNATIONAL
STANDARD UNTIL PUBLISHED AS SUCH.
IN ADDITION TO THEIR EVALUATION AS
BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
USER PURPOSES, DRAFT INTERNATIONAL
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
POTENTIAL TO BECOME STANDARDS TO
WHICH REFERENCE MAY BE MADE IN
Reference number
NATIONAL REGULATIONS.
ISO/DIS 19085-9:2022(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2022

oSIST prEN ISO 19085-9:2022
ISO/DIS 19085-9:2022(E)
DRAFT INTERNATIONAL STANDARD
ISO/DIS 19085-9
ISO/TC 39/SC 4 Secretariat: UNI
Voting begins on: Voting terminates on:

Woodworking machines — Safety —
Part 9:
Circular saw benches (with and without sliding table)
Machines à bois — Sécurité —
Partie 9: Scies circulaires à table de menuisier (avec et sans table mobile)
ICS: 79.120.10; 13.110
This document is circulated as received from the committee secretariat.
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
© ISO 2022
ISO/CEN PARALLEL PROCESSING
THEREFORE SUBJECT TO CHANGE AND MAY
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
NOT BE REFERRED TO AS AN INTERNATIONAL
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on STANDARD UNTIL PUBLISHED AS SUCH.
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
IN ADDITION TO THEIR EVALUATION AS
or ISO’s member body in the country of the requester. BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
ISO copyright office
USER PURPOSES, DRAFT INTERNATIONAL
CP 401 • Ch. de Blandonnet 8
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
CH-1214 Vernier, Geneva
POTENTIAL TO BECOME STANDARDS TO
Phone: [phone]
WHICH REFERENCE MAY BE MADE IN
Reference number
Email: [e-mail]
NATIONAL REGULATIONS.
Website: www.iso.org ISO/DIS 19085-9:2022(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
Published in Switzerland
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
ii
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2022

oSIST prEN ISO 19085-9:2022
ISO/DIS 19085-9:2022(E)
Contents Page
Foreword . vi
Introduction .vii
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 2
4 Safety requirements and measures for controls . 3
4.1 Safety and reliability of control systems. 3
4.2 Control devices . 3
4.3 Start . 4
4.3.1 Direct start . 5
4.3.2 Start via control power-on . 5
4.4 Safe stops . 5
4.4.1 General . 5
4.4.2 Normal stop . 5
4.4.3 Operational stop . 5
4.4.4 Emergency stop . 5
4.5 Braking function of tools . 5
4.6 Mode selection . 5
4.7 Tool speed changing . 5
4.7.1 Speed changing by shifting the belts on the pulleys . 5
4.7.2 Speed changing by incremental speed change motor . 5
4.7.3 Infinitely variable speed by frequency inverter . 5
4.8 Failure of any power supply . 5
4.9 Manual reset control . 6
4.10 Standstill detection and monitoring . 6
4.11 Machine moving parts speed monitoring. 6
4.12 Time delay. 6
4.13 Teleservice . 6
4.14 Power-operated adjustment of the saw blades and fences . 6
4.14.1 Risk of contact between the saw blades and fences . 6
4.14.2 Crushing hazard for the body . 7
4.14.3 Crushing and shearing hazard for the arm, hand or finger . 7
5 Safety requirements and measures for protection against mechanical hazards .8
5.1 Stability . 8
5.2 Risk of break-up during operation . 8
5.3 Tool and tool fixing design . 8
5.3.1 General . 8
5.3.2 Spindle locking . 8
5.3.3 Circular saw blade fixing device . 8
5.3.4 Flange dimension for circular saw blades . 8
5.3.5 Fixing device for milling tools . 8
5.4 Braking . 8
5.4.1 Braking of tools . 8
5.4.2 Maximum run-down time . 9
5.4.3 Brake release . 9
5.5 Safeguards . 9
5.5.1 Fixed guards . 9
5.5.2 Interlocking movable guards . 9
5.5.3 Hold-to-run control . 9
5.5.4 Two-hand control . 9
5.5.5 Electro-sensitive protective equipment (ESPE) . 9
5.5.6 Pressure-sensitive protective equipment (PSPE) . 9
iii
oSIST prEN ISO 19085-9:2022
ISO/DIS 19085-9:2022(E)
5.5.7 Enabling control . 9
5.6 Prevention of access to hazardous moving parts . 9
5.6.1 Access to the saw blade above the machine table . 10
5.6.2 Access to the saw blade below the machine table .15
5.6.3 Guarding of drives . 15
5.7 Impact hazard . 16
5.8 Clamping device
...
