SIST EN 61249-5-4:1997

• Abstract:

  Details requirements for the qualification of conductive inks, and for conductive inks intended for use as a substitute for metallic finishes on contacts.

• Status: Published
• Publication Date: 31-Jul-1997
• ICS: 31.180 - Printed circuits and boards
• Technical Committee: ITIV - Electronics assembly technology and Environmental standardization
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Aug-1997
• Due Date: 01-Aug-1997
• Completion Date: 01-Aug-1997
• Ref Project: EN 61249-5-4:1996 - Materials for interconnection structures - Part 5: Sectional specification set for conductive foils and films with or without coatings - Section 4: Conductive inks

• Refers: SIST HD 323.2.3 S2:2003 - Basic environmental testing procedures -- Part 2: Tests - Test Ca: Damp heat, steady state
• Effective Date: 03-Feb-2026
• Refers: SIST HD 323.2.20 S3:2003 - Basic environmental testing procedures -- Part 2: Tests - Test T: Soldering
• Effective Date: 03-Feb-2026
• Referred By: SIST EN 115-1:2017 - Safety of escalators and moving walks - Part 1: Construction and installation
• Effective Date: 09-Feb-2026
• Referred By: SIST EN 115-1:2009+A1:2010 - Safety of escalators and moving walks - Part 1: Construction and installation
• Effective Date: 09-Feb-2026

Overview

EN 61249-5-4:1996 (adopted as SIST EN 61249-5-4:1997) is a sectional specification in the EN 61249 family covering materials for interconnection structures. This part specifically addresses conductive inks and sets out the requirements for their qualification and for inks intended to be used as substitutes for metallic contact finishes. The standard is aligned with IEC 1249-5-4:1996 and falls under the printed circuits and boards classification (ICS 31.180).

Key Topics

The standard focuses on the qualification and performance expectations of conductive inks used in interconnection and contact applications. Key technical topics typically covered include:

• Qualification requirements and procedures for conductive inks used in electronic interconnections.
• Performance characteristics relevant to contact applications, such as electrical conductivity and contact resistance (general concept; specific thresholds are in the standard text).
• Compatibility and adhesion to common substrates used in printed circuit boards and flexible interconnects.
• Durability and environmental resistance, including performance under expected operational stresses and ageing.
• Formulation and processing considerations, including suitability for application and curing methods (without prescribing specific chemistries).
• Use as substitutes for metallic finishes on contacts, requiring demonstration of equivalent performance for reliability and service life.

Applications

EN 61249-5-4 is useful wherever conductive inks are selected, qualified or specified for electrical interconnection and contact applications:

• PCB and flexible circuit manufacturers evaluating conductive inks for circuit traces, repair, or selective plating substitutes.
• Ink formulators and material suppliers developing conductive pastes, inks and coatings for contact surfaces.
• Electronic OEMs and contract manufacturers that need to approve conductive-ink-based contact finishes as alternatives to plated metallic contacts.
• Quality, reliability and test laboratories responsible for verifying compliance with qualification criteria before production use.
• Procurement and standards teams writing material specifications for supplier qualification.

Related Standards

• IEC 1249-5-4:1996 - original international reference equivalent to EN 61249-5-4.
• Other parts of the EN/IEC 61249 series covering foils, films and materials for interconnection structures.
• Broader printed circuit board standards (ICS 31.180) governing substrate and assembly requirements.

EN 61249-5-4 is a practical reference for anyone specifying or qualifying conductive inks as reliable conductive layers or replacements for metal contact finishes in electronic assemblies.

SLOVENSKI STANDARD
01-avgust-1997
Materials for interconnection structures - Part 5: Sectional specification set for
conductive films with or without coatings - Section 4: Conductive inks (IEC 1249-5-
4:1996)
Materials for interconnection structures -- Part 5: Sectional specification set for
conductive foils and films with or without coatings -- Section 4: Conductive inks
Materialien für Verbindungsstrukturen -- Teil 5: Rahmenspezifikationen für leitfähige
Folien und Filme mit oder ohne Beschichtungen -- Hauptabschnitt 4: Leitfähige
Druckfarben
Matériaux pour les structures d'interconnexion -- Partie 5: Collection de spécifications
intermédiaires pour feuilles et films conducteurs avec ou sans revêtement -- Section 4:
Encres conductrices
Ta slovenski standard je istoveten z: EN 61249-5-4:1996
ICS:
31.180 7LVNDQDYH]MD7,9LQWLVNDQH Printed circuits and boards
SORãþH
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
...
