ASTM E251-20a
(Test Method)Standard Test Methods for Performance Characteristics of Metallic Bonded Resistance Strain Gages
Standard Test Methods for Performance Characteristics of Metallic Bonded Resistance Strain Gages
SIGNIFICANCE AND USE
4.1 Strain gages are the most widely used devices for the determination of materials, properties and for analyzing stresses in structures. However, performance characteristics of strain gages are affected by both the materials from which they are made and their geometric design. These test methods detail the minimum information that must accompany strain gages if they are to be used with acceptable accuracy of measurement.
4.2 Most performance characteristics of strain gages require mechanical testing that is destructive. Since test strain gages cannot be used again, it is necessary to treat data statistically and then apply values to the remaining population from the same lot or batch. Failure to acknowledge the resulting uncertainties can have serious repercussions. Resistance measurement is non-destructive and can be made for each strain gage.
4.3 Properly designed and manufactured strain gages, whose performance characteristics have been accurately determined and with appropriate uncertainties applied, represent powerful measurement tools. They can determine small dimensional changes in structures with excellent accuracy, far beyond that of other known devices. It is important to recognize, however, that individual strain gages cannot be calibrated. If calibration and traceability to a standard are required, strain gages should not be employed.
4.4 To be used, strain gages must be bonded to a structure. Good results depend heavily on the materials used to clean the bonding surface, to bond the strain gage, and to provide a protective coating. Skill of the installer is another major factor in success. Finally, instrumentation systems must be carefully designed to assure that they do not unduly degrade the performance of the strain gages. In many cases, it is impossible to achieve this goal. If so, allowance must be made when considering accuracy of data. Test conditions can, in some instances, be so severe that error signals from strain gage systems far ...
SCOPE
1.1 The purpose of these test methods are to provide uniform test methods for the determination of strain gage performance characteristics. Suggested testing equipment designs are included.
1.2 Test Methods E251 describes methods and procedures for determining five strain gage performance characteristics:
Section
Part I—General Requirements
7
Part II—Resistance at a Reference Temperature
8
Part III—Gage Factor at a Reference Temperature
9
Part IV—Temperature Coefficient of Gage Factor
10
Part V—Transverse Sensitivity
11
Part VI—Thermal Output
12
1.3 Strain gages are very sensitive devices with essentially infinite resolution. Their response to strain, however, is low and great care must be exercised in their use. The performance characteristics identified by these test methods must be known to an acceptable accuracy to obtain meaningful results in field applications.
1.3.1 Strain gage resistance is used to balance instrumentation circuits and to provide a reference value for measurements since all data are related to a change in the strain gage resistance from a known reference value.
1.3.2 Gage factor is the transfer function of a strain gage. It relates resistance change in the strain gage and strain to which it is subjected. Accuracy of strain gage data can be no better than the accuracy of the gage factor.
1.3.3 Changes in gage factor as temperature varies also affect accuracy although to a much lesser degree since variations are usually small.
1.3.4 Transverse sensitivity is a measure of the strain gage's response to strains perpendicular to its measurement axis. Although transverse sensitivity is usually much less than 10 % of the gage factor, large errors can occur if the value is not known with reasonable precision.
1.3.5 Thermal output is the response of a strain gage to temperature changes. Thermal output is an additive (not multiplica...
General Information
Relations
Buy Standard
Standards Content (Sample)
This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: E251 − 20a
Standard Test Methods for
Performance Characteristics of Metallic Bonded Resistance
1
Strain Gages
This standard is issued under the fixed designation E251; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision.Anumber in parentheses indicates the year of last reapproval.A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
This standard has been approved for use by agencies of the U.S. Department of Defense.
INTRODUCTION
The Organization of International Legal Metrology is a treaty organization with approximately
75member nations. In 1984, OIML issued International Recommendation No. 62, “Performance
Characteristics of Metallic Resistance Strain Gages.” Test Methods E251 has been modified and
expanded to be the United States ofAmerica’s compliant test specification. Throughout this standard
the term “strain gage” represents the longer, but more accurate, “metallic bonded resistance strain
gage.”
1. Scope it is subjected. Accuracy of strain gage data can be no better
than the accuracy of the gage factor.
1.1 The purpose of these test methods are to provide
1.3.3 Changes in gage factor as temperature varies also
uniform test methods for the determination of strain gage
affect accuracy although to a much lesser degree since varia-
performance characteristics. Suggested testing equipment de-
signs are included. tions are usually small.
1.3.4 Transversesensitivityisameasureofthestraingage’s
1.2 Test Methods E251 describes methods and procedures
response to strains perpendicular to its measurement axis.
for determining five strain gage performance characteristics:
Although transverse sensitivity is usually much less than 10%
Section
Part I—General Requirements 7 of the gage factor, large errors can occur if the value is not
Part II—Resistance at a Reference Temperature 8
known with reasonable precision.
Part III—Gage Factor at a Reference Temperature 9
1.3.5 Thermal output is the response of a strain gage to
Part IV—Temperature Coefficient of Gage Factor 10
Part V—Transverse Sensitivity 11
temperature changes. Thermal output is an additive (not
Part VI—Thermal Output 12
multiplicative) error. Therefore, it can often be much larger
1.3 Strain gages are very sensitive devices with essentially
than the strain gage output from structural loading. To correct
infinite resolution. Their response to strain, however, is low
for these effects, thermal output must be determined from
and great care must be exercised in their use.The performance
strain gages bonded to specimens of the same material on
characteristics identified by these test methods must be known
which the tests are to run, often to the test structure itself.
to an acceptable accuracy to obtain meaningful results in field
1.4 Metallic bonded resistance strain gages differ from
applications.
extensometers in that they measure average unit elongation
1.3.1 Strain gage resistance is used to balance instrumenta-
tioncircuitsandtoprovideareferencevalueformeasurements (∆L/L) over a nominal gauge length rather than total elonga-
tion between definite gauge points. Practice E83 is not appli-
since all data are related to a change in the strain gage
resistance from a known reference value. cable to these strain gages.
1.3.2 Gage factor is the transfer function of a strain gage. It
1.5 These test methods do not apply to transducers, such as
relates resistance change in the strain gage and strain to which
load cells and extensometers, that use bonded resistance strain
gages as sensing elements.
1
1.6 Strain gages are part of a complex system that includes
These test methods are under the jurisdiction of ASTM Committee E28 on
Mechanical Testing and are the direct responsibility of Subcommittee E28.01 on
structure, adhesive, strain gage, lead wires, instrumentation,
Calibration of Mechanical Testing Machines and Apparatus.
and (often) environmental protection.As a result, many things
Current edition approved June 1, 2020. Published August 2020. Originally
affect the performance of strain gages, including user tech-
approved in 1964. Last previous edition approved in 2014 as E251–92 (2014).
DOI: 10.1520/E0251-20A. nique.Afurthercomplicationisthatstraingagesonceinstalled
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
E251 − 20a
normally cannot be reinstalled in another location. Therefore, R 2 R ∆R
0
strain gage characteristics can be stated only on a statistical R R
0 0
K 5 5 (1)
basis.
...
This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: E251 − 20 E251 − 20a
Standard Test Methods for
Performance Characteristics of Metallic Bonded Resistance
1
Strain Gages
This standard is issued under the fixed designation E251; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
This standard has been approved for use by agencies of the U.S. Department of Defense.
INTRODUCTION
The Organization of International Legal Metrology is a treaty organization with approximately 75
member 75 member nations. In 1984, OIML issued International Recommendation No. 62, “Perfor-
mance Characteristics of Metallic Resistance Strain Gages.” Test Methods E251 has been modified
and expanded to be the United States of America’s compliant test specification. Throughout this
standard the terms “strain gage” and “gage” are to be understood to represent term “strain gage”
represents the longer, but more accurate, “metallic bonded resistance strain gages.”gage.”
1. Scope
1.1 The purpose of these test methods are to provide uniform test methods for the determination of strain gage performance
characteristics. Suggested testing equipment designs are included.
1.2 Test Methods E251 describes methods and procedures for determining five strain gage parameters:performance
characteristics:
Section
Part I—General Requirements 7
Part II—Resistance at a Reference Temperature 8
Part III—Gage Factor at a Reference Temperature 9
Part IV—Temperature Coefficient of Gage Factor 10
Part V—Transverse Sensitivity 11
Part VI—Thermal Output 12
1.3 Strain gages are very sensitive devices with essentially infinite resolution. Their response to strain, however, is low and great
care must be exercised in their use. The performance characteristics identified by these test methods must be known to an
acceptable accuracy to obtain meaningful results in field applications.
1.3.1 Strain gage resistance is used to balance instrumentation circuits and to provide a reference value for measurements since
all data are related to a change in the strain gage resistance from a known reference value.
1.3.2 Gage factor is the transfer function of a strain gage. It relates resistance change in the strain gage and strain to which it
is subjected. Accuracy of strain gage data can be no better than the precisionaccuracy of the gage factor.
1.3.3 Changes in gage factor as temperature varies also affect accuracy although to a much lesser degree since variations are
usually small.
1.3.4 Transverse sensitivity is a measure of the strain gage’s response to strains perpendicular to its measurement axis. Although
transverse sensitivity is usually much less than 10 % of the gage factor, large errors can occur if the value is not known with
reasonable precision.
1.3.5 Thermal output is the response of a strain gage to temperature changes. Thermal output is an additive (not multiplicative)
error. Therefore, it can often be much larger than the strain gage output from structural loading. To correct for these effects, thermal
output must be determined from strain gages bonded to specimens of the same material on which the tests are to run, often to the
test structure itself.
1
These test methods are under the jurisdiction of ASTM Committee E28 on Mechanical Testing and are the direct responsibility of Subcommittee E28.01 on Calibration
of Mechanical Testing Machines and Apparatus.
Current edition approved May 1, 2020June 1, 2020. Published August 2020. Originally approved in 1964. Last previous edition approved in 2014 as E251 – 92 (2014).
DOI: 10.1520/E0251-92R14.10.1520/E0251-20A.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
E251 − 20a
1.4 Bonded Metallic bonded resistance strain gages differ from extensometers in that they measure average unit elongation
(ΔL/L) over a nominal gagegauge length rather than total elongation between definite gauge points. Practice E83 is not applicable
to these strain gages.
1.5 These test methods do not apply to transducers, such as load cells and extensometers, that use bonded resistance strain gages
as sensing elements.
1.6 Strain gages are part of a complex system that includes structure, adhesive, strain gage, lead wires, instrumentation, and
(often) environmental protection. As a result
...
