EN ISO 8740:1997

Grooved pins - Full-length parallel grooved, with chamfer (ISO 8740:1997)

Zylinderkerbstifte mit Fase (ISO 8740:1997)

Diese Internationale Norm beschreibt die Eigenschaften von Zylinderstiften mit Fase aus Stahl oder aus austenitischem nichtrostendem Stahl, mit drei drei gleichmäßig verteilten Längskerben auf der Außenfläche und einem Einführende zur Erleichterung des Einbaus. Die Kerbstifte haben einen Nenndurchmesser d1 von 1,5 bis einschließlich 25 mm. Der zu jeder Seite der

Goupilles cannelées à cannelures constantes sur toute la longueur débouchantes, à chanfrein (ISO 8740:1997)

La présente Norme internationale prescrit les caractéristiques des goupilles cannelées à chanfrein en acier ou en acier inoxydable austénitique, à trois cannelures constantes sur toute leur longueur, débouchantes d'un côté et régulièrement espacées, de diamètre nominal, d1, de 1,5 mm à 25 mm inclus. Le matériau refoulé de chaque côté des cannelures forme un renflement dont le diamètre d2, supérieur au diamètre nominal d1, permet un ajustement serré de ces goupilles cannelées lorsqu'elles sont emmanchées en force dans un trou de diamètre de perçage égal au diamètre nominal de la goupille d1 (voir article 4).

Zasekani zatiči z brazdami enake globine po vsej dolžini in s posneto končino (ISO 8740:1997)

General Information

• Status: Published
• Publication Date: 31-Oct-1997
• ICS: 21.060 - Fasteners
• Technical Committee: CEN/TC 185 - Threaded and nonthreaded mechanical fasteners and accessories
• Drafting Committee: CEN/TC 185 - Threaded and nonthreaded mechanical fasteners and accessories
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 04-Feb-2008
• Completion Date: 04-Feb-2008
• Ref Project: SIST EN ISO 8740:2001 - Grooved pins - Full-length parallel grooved, with chamfer (ISO 8740:1997)

Relations

• Replaces: EN 28740:1992 - Grooved pins - Full-length parallel grooved, with chamfer (ISO 8740:1986)
• Effective Date: 22-Dec-2008
• Revised: prEN ISO 8740 - Fasteners - Parallel grooved pins, with chamfer point - Full-length diamond grooves (ISO/DIS 8740:2023)
• Effective Date: 18-Jan-2023

Standards Content (Sample)

SLOVENSKI STANDARD
01-julij-2001
1DGRPHãþD
SIST EN 28740:1996
=DVHNDQL]DWLþL]EUD]GDPLHQDNHJORELQHSRYVHMGROåLQLLQVSRVQHWRNRQþLQR,62

Grooved pins - Full-length parallel grooved, with chamfer (ISO 8740:1997)
Zylinderkerbstifte mit Fase (ISO 8740:1997)
Goupilles cannelées a cannelures constantes sur toute la longueur débouchantes, a
chanfrein (ISO 8740:1997)
Ta slovenski standard je istoveten z: EN ISO 8740:1997
ICS:
21.060.50 =DWLþLåHEOML Pins, nails
