EN ISO 10239:2025
(Main)Small craft - Liquefied petroleum gas (LPG) systems (ISO 10239:2025)
Small craft - Liquefied petroleum gas (LPG) systems (ISO 10239:2025)
This document specifies requirements for the installation of permanently installed liquefied petroleum gas (LPG) systems and LPG-burning appliances on small craft.
This document is applicable to portable cooking appliances with internal LPG cartridges, with a capacity of 225 g or less (see Annex D).
This document is applicable to the storage of all LPG cylinders.
NOTE 1 National regulations can apply to the technical requirements of LPG cylinders.
This document does not contain procedures for commissioning new LPG installations or system maintenance or upgrades.
This document does not apply to LPG-fuelled propulsion engines or LPG-driven generators.
NOTE 2 National codes and procedures appropriate to the country concerned can be available.
Kleine Wasserfahrzeuge - Flüssiggas-Anlagen (LPG) (ISO 10239:2025)
Dieses Dokument legt Anforderungen für den Einbau von fest eingebauten Flüssiggas-(LPG)-Anlagen und flüssiggasbetriebenen Geräten auf kleinen Wasserfahrzeugen fest.
Dieses Dokument ist anwendbar auf tragbare Kochgeräte mit integrierten Flüssiggaskartuschen mit einem Fassungsvermögen von 225 g oder weniger (siehe Anhang D).
Dieses Dokument ist anwendbar für die Aufbewahrung aller Flüssiggasflaschen.
ANMERKUNG 1 Für die technischen Anforderungen an Flüssiggasflaschen können nationale Vorschriften gelten.
Dieses Dokument enthält keine Verfahren für die Inbetriebnahme neuer Flüssiggas-Installationen oder Wartung oder Erweiterung von Systemen.
Dieses Dokument ist nicht anwendbar für flüssiggasbetriebene Antriebsmaschinen oder flüssiggasbetriebene Generatoren.
ANMERKUNG 2 Nationale Regeln und in dem entsprechenden Land einschlägige Verfahren können verfügbar sein.
Petits navires - Installations alimentées en gaz de pétrole liquéfiés (GPL) (ISO 10239:2025)
Le présent document spécifie les exigences relatives à l’installation des systèmes alimentés en gaz de pétrole liquéfiés (GPL) installés à demeure et les appareils brûlant du GPL installés sur les petits navires.
Le présent document s’applique aux appareils de cuisson portables comportant des cartouches de GPL internes d’une capacité inférieure ou égale à 225 g (voir Annexe D).
Le présent document s’applique au stockage de toutes les bouteilles de GPL.
NOTE 1 Des réglementations nationales peuvent s’appliquer aux exigences techniques relatives aux bouteilles de GPL.
Le présent document ne contient pas de procédures relatives à la mise en service des nouvelles installations au GPL ou à la maintenance ou l’amélioration des systèmes.
Le présent document ne s’applique pas aux moteurs de propulsion alimentés en GPL ou aux générateurs alimentés en GPL.
NOTE 2 Il peut exister des codes et procédures nationaux en vigueur dans le pays concerné.
Mala plovila - Sistemi za utekočinjeni naftni plin (LPG) (ISO 10239:2025)
General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
oSIST prEN ISO 10239:2023
01-marec-2023
Nadomešča:
SIST EN ISO 10239:2017
Mala plovila - Sistemi za utekočinjeni naftni plin (LPG) (ISO/DIS 10239:2023)
Small craft - Liquefied petroleum gas (LPG) systems (ISO/DIS 10239:2023)
Kleine Wasserfahrzeuge - Flüssiggas-Anlagen (LPG) (ISO/DIS 10239:2023)
Petits navires - Installations alimentées en gaz de pétrole liquéfiés (GPL) (ISO/DIS
10239:2023)
Ta slovenski standard je istoveten z: prEN ISO 10239
ICS:
47.080 Čolni Small craft
75.160.30 Plinska goriva Gaseous fuels
oSIST prEN ISO 10239:2023 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
oSIST prEN ISO 10239:2023
oSIST prEN ISO 10239:2023
DRAFT INTERNATIONAL STANDARD
ISO/DIS 10239
ISO/TC 188 Secretariat: SIS
Voting begins on: Voting terminates on:
2023-01-10 2023-04-04
Small craft — Liquefied petroleum gas (LPG) systems
Petits navires — Installations alimentées en gaz de pétrole liquéfiés (GPL)
ICS: 47.080
This document is circulated as received from the committee secretariat.
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
ISO/CEN PARALLEL PROCESSING
THEREFORE SUBJECT TO CHANGE AND MAY
NOT BE REFERRED TO AS AN INTERNATIONAL
STANDARD UNTIL PUBLISHED AS SUCH.
IN ADDITION TO THEIR EVALUATION AS
BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
USER PURPOSES, DRAFT INTERNATIONAL
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
POTENTIAL TO BECOME STANDARDS TO
WHICH REFERENCE MAY BE MADE IN
Reference number
NATIONAL REGULATIONS.
ISO/DIS 10239:2023(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2023
oSIST prEN ISO 10239:2023
ISO/DIS 10239:2023(E)
DRAFT INTERNATIONAL STANDARD
ISO/DIS 10239
ISO/TC 188 Secretariat: SIS
Voting begins on: Voting terminates on:
Small craft — Liquefied petroleum gas (LPG) systems
Petits navires — Installations alimentées en gaz de pétrole liquéfiés (GPL)
ICS: 47.080
This document is circulated as received from the committee secretariat.
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
© ISO 2023
ISO/CEN PARALLEL PROCESSING
THEREFORE SUBJECT TO CHANGE AND MAY
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
NOT BE REFERRED TO AS AN INTERNATIONAL
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on STANDARD UNTIL PUBLISHED AS SUCH.
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
IN ADDITION TO THEIR EVALUATION AS
or ISO’s member body in the country of the requester. BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
ISO copyright office
USER PURPOSES, DRAFT INTERNATIONAL
CP 401 • Ch. de Blandonnet 8
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
CH-1214 Vernier, Geneva
POTENTIAL TO BECOME STANDARDS TO
Phone: +41 22 749 01 11
WHICH REFERENCE MAY BE MADE IN
Reference number
Email: copyright@iso.org
NATIONAL REGULATIONS.
Website: www.iso.org ISO/DIS 10239:2022(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
Published in Switzerland
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
ii
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2022
oSIST prEN ISO 10239:2023
ISO/DIS 10239:2022(E)
Contents Page
Foreword .iv
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 2
4 General provisions .4
5 Pressure regulation device.5
6 LPG Supply line . 5
6.1 General . 5
6.2 Piping . 6
6.3 Hose . 6
6.4 Materials . 8
6.5 Installation . 8
6.6 Shut-off valves . 9
7 Appliances .10
8 Ducts and flues for air intake and combustion product discharge.11
9 Location and installation of LPG cylinders .12
10 Ventilation .12
11 LPG installation tightness tests .13
12 Ignition protection from electrical devices .13
13 Owner's manual .13
Annex A (informative) Design guidelines for pressure drop due to pipe resistance .14
Annex B (normative) Ventilation .15
Annex C (normative) Instructions to be included with the owner's manual .16
Annex D (normative) Cooking appliances with integral LPG cartridges with a capacity of
225 g or less .18
Annex ZA (informative) Relationship between this European Standard and the essential
requirements of EU Directive 2013/53/EU.19
Bibliography .21
iii
oSIST prEN ISO 10239:2023
ISO/DIS 10239:2022(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www.iso.org/directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www.iso.org/patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to
the World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT), see
www.iso.org/iso/foreword.html.
This document was prepared by Technical Committee ISO/TC 188, Small craft, in collaboration with
the European Committee for Standardization (CEN) Technical Committee CEN/TC 464, Small craft, in
accordance with the Agreement on technical cooperation between ISO and CEN (Vienna Agreement).
This fourth edition cancels and replaces the third edition (ISO 10239:2014), which has been technically
revised. The major technical changes include:
The main changes are as follows:
— scope has been clarified;
— new definitions for room sealed appliance and open flued appliance have been added;
— the location of pressure regulation devices has been clarified.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www.iso.org/members.html.
iv
oSIST prEN ISO 10239:2023
DRAFT INTERNATIONAL STANDARD ISO/DIS 10239:2022(E)
Small craft — Liquefied petroleum gas (LPG) systems
1 Scope
This document addresses the installation of permanently installed liquefied petroleum gas (LPG)
systems and LPG-burning appliances on small craft.
This document does not apply to LPG-fuelled propulsion engines or LPG-driven generators.
This document addresses cooking appliances with internal LPG cartridges, with a capacity of 225 g or
less (See Annex D).
This document addresses storage of all LPG cylinders but is not intended to regulate the technical
requirements for such cylinders that are subject to national regulations.
It does not contain procedures for commissioning new LPG installations or system maintenance or
upgrades. Competent persons responsible for commissioning LPG installations should use relevant
national codes and procedures appropriate to the country concerned.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies.
ISO 7-1:1994, Pipe threads where pressure-tight joints are made on the threads — Part 1: Dimensions,
tolerances and designation
ISO 8434-1:2018, Metallic tube connections for fluid power and general use — Part 1: 24° cone connectors
ISO 8666:2020, Small craft — Principal data
ISO 8846:1990, Small craft — Electrical devices — Protection against ignition of surrounding flammable
gases
ISO 9094:2015, Small craft — Fire protection
ISO 10240:2019, Small craft — Owner’s manual
ISO 11812:2020, Small craft — Watertight or quick-draining recesses and cockpits
EN 751-2:1996, Sealing materials for metallic threaded joints in contact with 1st, 2nd and 3rd family gases
and hot water — Part 2: Non-hardening jointing compounds
EN 751-3:1996, Sealing materials for metallic threaded joints in contact with 1st, 2nd and 3rd family gases
and hot water — Part 3: Unsintered PTFE tapes
EN 1254-2:2021, Copper and copper alloys - Plumbing fittings - Part 2: Compression fittings for use with
copper tubes
EN 1949:2021, Specification for the installation of LPG systems for habitation purposes in leisure
accommodation vehicles and accommodation purposes in other vehicles
EN 14291:2004, Foam producing solutions for leak detection on gas installations
EN 15266:2007, Stainless steel pliable corrugated tubing kits in buildings for gas with an operating
pressure up to 0,5 bar
oSIST prEN ISO 10239:2023
ISO/DIS 10239:2022(E)
EN 16129:2013, Pressure regulators, automatic change-over devices, having a maximu
...
