EN ISO 19054:2006
(Main)Rail systems for supporting medical equipment (ISO 19054:2005)
Rail systems for supporting medical equipment (ISO 19054:2005)
ISO 19054:2005 specifies basic requirements to ensure compatibility between rail systems complying with this International Standard and medical equipment in order to facilitate the transfer of medical equipment from one rail system to another. The specifications for rail systems include dimensions, strength and information to be supplied by the manufacturer.
ISO 19054:2005 applies only to rail systems intended to be mounted horizontally.
ISO 19054:2005 does not specify either the structures to which a rail system can be attached or the types of medical equipment that can be supported nor does it apply to overhead rail systems for supporting curtains and infusion devices.
Schienensysteme zum Halten medizinischer Geräte (ISO 19054:2005)
Diese Internationale Norm legt grundlegende Anforderungen fest, um die Kompatibilität zwischen den dieser Internationalen Norm entsprechenden Schienensystemen und medizinischen Geräten sicherzustellen, um das Umhängen eines medizinischen Gerätes von einem Schienensystem auf ein anderes zu erleichtern. Die Festlegungen für Schienensysteme beinhalten Maße, Stabilität und Informationen des Herstellers.
Diese Internationale Norm gilt nur für Schienensysteme, die horizontal montiert werden sollen.
Diese Internationale Norm enthält keine Festlegungen zu den Konstruktionen, an die die Schienensysteme angebracht werden können, und auch nicht zu den Arten der medizinischen Geräte, die gehalten werden sollen.
Diese Internationale Norm gilt nicht für an der Decke befindliche Schienensysteme zum Halten von Vorhängen und Infusionsgeräten.
ANMERKUNG 1 Einige medizinische Geräte können an eine Schiene mit Hilfe von Vorrichtungen befestigt werden, die nicht im Anwendungsbereich dieser Internationalen Norm liegen.
ANMERKUNG 2 Es wird angenommen, dass spezielle Normen erarbeitet werden, die Anwendungsbereiche abdecken, für die die in dieser Internationalen Norm festgelegten Schienensysteme nicht geeignet sind.
Systèmes de rails de support pour appareils médicaux (ISO 19054:2005)
L'ISO 19054:2005 spécifie les exigences de base en vue d'assurer la compatibilité entre les systèmes de rails conformes à la présente Norme internationale et les appareils médicaux, afin de permettre l'interchangeabilité des appareils médicaux d'un système de rails à un autre. Les spécifications relatives aux systèmes de rails comprennent les dimensions, la résistance et les informations à fournir par le fabricant.
L'ISO 19054:2005 s'applique uniquement aux systèmes de rails destinés à être montés horizontalement.
L'ISO 19054:2005 internationale ne spécifie ni les structures ni les types de matériel médical qu'ils doivent porter ni ne s'applique aux tringles et potences servant à soutenir des rideaux et des dispositifs de perfusion.
Tračni nosilci za pritrditev medicinske opreme (ISO 19054:2005)
Ta mednarodni standard določa osnovne zahteve za zagotavljanje združljivosti med tlačnimi nosilci, ki izpolnjujejo zahteve tega mednarodnega standarda, in medicinsko opremo za lažji prenos medicinske opreme z enega tračnega nosilca na drugega. Specifikacije za tračne nosilce vključujejo dimenzije, moč in informacije, ki jih zagotovi proizvajalec. Ta mednarodni standard se uporablja samo za tračne nosilce za vodoravno montažo. Ta mednarodni standard ne določa konstrukcij, na katere se pritrdi tračne nosilce, ali vrst medicinske opreme, ki je lahko podprta. Ta mednarodni standard se ne uporablja za nadzemne tračne nosilce za podporo zaves in infuzijske opreme.
