EN 12274-2:2018

Slurry surfacing - Test methods - Part 2: Determination of residual binder content including preparation of samples

This European Standard specifies test methods for determining the residual binder content of samples of slurry surfacing mixtures.
This document describes the method for preparing the specimens and for removing water from the samples before carrying out the extraction test.
The method described in this European Standard needs to be used only to determine the quantity of binder and not to investigate its quality.
This European Standard applies to slurry surfacing to be used in surface layers for roads, airfields and other trafficked areas.

Dünne Asphaltdeckschichten in Kaltbauweise - Prüfverfahren - Teil 2: Bestimmung des Bindemittelgehaltes einschließlich Probenvorbereitung

Diese Europäische Norm legt Prüfverfahren zur Bestimmung des Bindemittelgehaltes von Proben aus Mischgut für dünne Asphaltdeckschichten in Kaltbauweise fest.
Dieses Dokument legt das Verfahren der Probenvorbereitung sowie das Verfahren, mit dessen Hilfe den Proben vor Durchführung der Extraktionsprüfung Wasser zu entziehen ist, fest.
Das in dieser Europäischen Norm beschriebene Verfahren wird nur angewendet, um die Menge des Bindemittels zu bestimmen, jedoch nicht zur Untersuchung seiner Qualität.
Diese Europäische Norm gilt für dünne Asphaltdeckschichten in Kaltbauweise, die in Oberflächenschutzschichten für Straßen, Landeplätze und andere Verkehrsflächen verwendet werden

Matériaux bitumineux coulés à froid - Méthode d'essai - Partie 2: Détermination de la teneur en liant résiduel y compris la préparation des échantillons

La présente Norme européenne spécifie les méthodes d'essai pour déterminer la teneur en liant résiduel des échantillons de mélanges de matériaux bitumineux coulés à froid, qu’il s’agisse de Coulis bitumineux ou d’Enrobés coulés à froid.
Le présent document décrit la méthode de préparation et de séchage des échantillons soumis à essais avant de procéder à l'essai d'extraction.
La méthode décrite dans la présente Norme européenne peut uniquement être utilisée pour déterminer la quantité de liant et non pour analyser sa qualité.
La présente Norme européenne s'applique aux matériaux bitumineux coulés à froid (Coulis bitumineux et Enrobés coulés à froid) à utiliser dans le revêtement des routes, des aérodromes et autres surfaces réservées à la circulation.

Tankoplastne prevleke po hladnem postopku - Preskusne metode - 2. del: Ugotavljanje deleža ostankov veziva, vključno s pripravo vzorca

Ta evropski standard določa preskusno metodo za določanje doslednosti površinskih zmesi redke malte.
OPOMBA 1 Metoda se lahko uporablja kot pripomoček za oblikovanje zmesi za določanje količine vode, ki je potrebna za stabilno in uporabno zmes.
OPOMBA 2 Da bi poskrbeli za ustrezno doslednost bo preskus morda potrebno ponoviti z drugimi znanimi odstotki vode.
Ta evropski standard velja za površine iz redke malte za uporabo na cestah, letališčih in drugih prometnih površinah.

General Information

• Status: Published
• Publication Date: 13-Mar-2018
• Withdrawal Date: 29-Sep-2018
• ICS: 93.080.20 - Road construction materials
• Technical Committee: CEN/TC 227 - Road materials
• Drafting Committee: CEN/TC 227/WG 2 - Surface dressing and slurry surfacing
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 29-Jul-2024
• Completion Date: 14-Apr-2025
• Ref Project: SIST EN 12274-2:2018 - Slurry surfacing - Test methods - Part 2: Determination of residual binder content including preparation of samples

Relations

• Replaces: EN 12274-2:2003 - Slurry surfacing - Test methods - Part 2: Determination of residual binder content
• Effective Date: 04-Jun-2014

Overview

EN 12274-2:2018 is a European Standard developed by CEN that specifies test methods for determining the residual binder content in slurry surfacing mixtures. This standard focuses on the accurate preparation of samples and the removal of water prior to the binder extraction test. It is designed exclusively to quantify the amount of binder present in slurry surfacing materials and not to evaluate binder quality.

Primarily applicable to slurry surfacing used in surface layers of roads, airfields, and other trafficked areas, EN 12274-2:2018 ensures consistent and reliable binder content measurement, which is crucial for quality control and performance assessment of slurry surfacing applications.

Key Topics

• Scope and Application

  • Specifies test procedures for residual binder content in slurry surfacing mixtures.
  • Applies to surface layers used in roads, airfields, and trafficked infrastructure.
  • Focuses on binder quantity determination only.

• Sample Preparation

  • Samples must be taken according to EN 12274-1.
  • Sample fragmentation to facilitate water evaporation.
  • Drying at 110 to 170°C until constant mass is achieved.
  • Recommended test portion masses vary based on aggregate size.
  • Alternative drying methods include water collection during solvent extraction as per EN 12697-1:2012, Annex B.

• Testing Procedures

  • Binder extraction conducted according to EN 12697-1:2012 (Annex B) or by ignition methods following EN 12697-39 if correlation is established.
  • Special procedures for polymer-modified binders based on supplier recommendations.
  • Use of rotary evaporator or fractionating column is allowed for binder recovery.

• Reporting

  • Test reports must include client and laboratory details, sample IDs, binder & water content percentages, test methods used, aggregate type, and any deviations from the standard protocol.
  • Essential for traceability and compliance verification.

Applications

• Road Construction and Maintenance

  • Ensures slurry surfacing mixtures meet binder content requirements for durability and wear resistance.
  • Helps optimize mixture design for improved surface performance and longevity.

• Airfield Pavement Surfacing

  • Critical for safety and operational efficiency by verifying binder content in airfield surfaces exposed to heavy and frequent traffic.

• Quality Control in Manufacturing Plants

  • Enables manufacturers to monitor slurry mix consistency.
  • Supports compliance with national and European regulations.

• Research and Development

  • Useful for R&D labs testing new binder formulations or aggregates within slurry surfacing systems.
  • Facilitates innovation while maintaining standardized measurement techniques.

Related Standards

• EN 12274-1:2018 – Sampling of slurry surfacing mixtures for binder extraction.
• EN 12697-1:2012 – Test methods for hot mix asphalt, including soluble binder content measurement.
• EN 12697-3 & EN 12697-4 – Bitumen recovery using rotary evaporator and fractionating column respectively.
• EN 12697-39 – Binder content determination by the ignition method.
• Other parts of the EN 12274 series related to slurry surfacing test methods cover mix consistency, cohesion, application rates, abrasion resistance, and visual defect assessment.

---

EN 12274-2:2018 provides essential standardized procedures that enhance the accuracy and reliability of binder content determination in slurry surfacing mixtures-key for ensuring high-quality pavement surfaces that meet safety and performance expectations in European road and airfield infrastructure.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Dünne Asphaltschicht in Kaltbauweise - Prüfverfahren - Teil 2: Bestimmung des Bindemittelgehaltes einschließlich ProbenvorbereitungMatériaux bitumineux coulés à froid - Méthode d'essai - Partie 2 : Détermination de la teneur en liant résiduel y compris la préparation des échantillonsSlurry surfacing - Test methods - Part 2: Determination of residual binder content including preparation of samples93.080.20Materiali za gradnjo cestRoad construction materialsICS:Ta slovenski standard je istoveten z:EN 12274-2:2018SIST EN 12274-2:2018en,fr,de01-maj-2018SIST EN 12274-2:2018SLOVENSKI
STANDARDSIST EN 12274-2:20041DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 12274-2
March
t r s z ICS
{ uä r z rä t r Supersedes EN
s t t y væ tã t r r uEnglish Version
Slurry surfacing æ Test methods æ Part
tã Determination of residual binder content including preparation of samplesMatßriaux bitumineux coulßs à froid æ Mßthode d 5essai æ Partie
tã Dßtermination de la teneur en liant rßsiduel y compris la prßparation des ßchantillons
Dünne Asphaltdeckschichten in Kaltbauweise æ Prüfverfahren æ Teil
tã Bestimmung des Bindemittelgehaltes einschließlich Probenvorbereitung This European Standard was approved by CEN on
s u November
t r s yä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Serbiaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Rue de la Science 23,
B-1040 Brussels
t r s z CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s t t y væ tã t r s z ESIST EN 12274-2:2018

¯ Test methods
¯ Part
wã Sampling of slurry surfacing mixture — EN 12274-2, Slurry surfacing
¯ Test methods
¯ Part
xã Determination of residual binder content including preparation of samples — EN 12274-3, Slurry surfacing
¯ Test methods
¯ Part
yã Consistency — EN 12274-4, Slurry surfacing
¯ Test methods
¯ Part
zã Determination of cohesion of the mix — EN 12274-5, Slurry surfacing
¯ Test methods
¯ Part
{ã Determination of the minimum binder content and wearing resistance — EN 12274-6, Slurry surfacing
¯ Test methods
¯ Part
|ã Rate of application — EN 12274-7, Slurry surfacing
¯ Test methods
¯ Part
}ã Shaking abra
...
