This document establishes the functional requirements for stations for the injection of biomethane, substitute natural gas (SNG) and hydrogen fuel gas into gas transmission and distribution systems operated with fuel gases (natural gas, biomethane, SNG, hydrogen fuel gas, fuel gas mixtures) in accordance with European technical rules that ensure the interoperability of systems.
Figure 1 describes the general approach including all the relevant functions that can be installed in different configurations.
This document also applies to refeeding stations that feed such gases back into upstream gas supply networks; see Figure 2.
This document represents the state of the art at the time of its preparation.
This document does not apply to injection stations operating prior to the publication of this document.
This document specifies common basic principles for gas infrastructure. Users of this document are expected to be aware that more detailed national standards and/or codes of practice can exist in the CEN member countries. This document is intended to be applied in association with these national standards and/or codes of practice setting out the above-mentioned basic principles.
In the event of terms of additional requirements in national legislation/regulation than in this document, CEN/TR 13737 (all parts) illustrates these terms.
CEN/TR 13737 (all parts) gives:
- legislation/regulations applicable in a member state;
- if appropriate, more restrictive national requirements;
- a national contact point for the latest information.
Gasinfrastruktur - Einspeiseanlagen - Teil 1: Allgemeine Anforderungen
Dieses Dokument legt die funktionalen Anforderungen für Anlagen für die Einspeisung von Biomethan, synthetischem Methan (en: substitute natural gas, SNG) und Wasserstoff in Gastransport- und Verteilungssysteme (Erdgas, Biomethan, SNG, Wasserstoff, Brenngasgemischen) in Übereinstimmung mit den europäischen technischen Vorschriften, die die Interoperabilität von Systemen sicherstellen, fest.
Bild 1 beschreibt den allgemeinen Ansatz einschließlich aller relevanten Funktionen, die in verschiedenen Konfigurationen installiert werden können.
Dieses Dokument ist ebenfalls für Rückspeiseanlagen der genannten Gase anwendbar. (Siehe Bild 2)
Dieses Dokument entspricht dem Stand der Technik zum Zeitpunkt seiner Erstellung.
Dieses Dokument ist nicht für vor der Veröffentlichung desselben in Betrieb genommene Einspeiseanlagen anwendbar.
Dieses Dokument legt gemeinsame Grundprinzipien für die Gasinfrastruktur fest. Die Anwender dieses Dokuments sollten sich bewusst sein, dass ausführlichere nationale Normen und/oder Verfahrensregeln in den CEN-Mitgliedstaaten bestehen können. Dieses Dokument soll in Verbindung mit diesen, die oben erwähnten allgemeinen Grundsätze darlegenden nationalen Normen und/oder Grundprinzipien angewendet werden.
Im Fall von zusätzlichen Anforderungen in nationalen gesetzlichen Vorschriften/Verordnungen zu diesem Dokument verdeutlicht CEN/TR 13737 (alle Teile) diese Anforderungen.
CEN/TR 13737 (alle Teile) enthält:
- gesetzliche Vorschriften/Verordnungen in einem Mitgliedsstaat;
- weitergehende strengere nationale Anforderungen, sofern zutreffend;
- einen nationalen Ansprechpartner für die Weitergabe neuester Informationen.
Infrastructures gazières - Stations d'injection - Partie 1 : Exigences générales
Le présent document établit les exigences fonctionnelles relatives aux stations d'injection de biométhane, de gaz naturel de substitution (GNS) et de gaz combustible hydrogène dans les réseaux de transport et de distribution de gaz exploités avec des gaz combustibles (gaz naturel, biométhane, GNS, gaz combustible hydrogène, mélanges de gaz combustibles) conformément aux règles techniques européennes qui assurent l'interopérabilité des systèmes.
La Figure 1 décrit l'approche générale, y compris toutes les fonctions pertinentes pouvant être installées dans différentes configurations.
Le présent document s'applique également aux stations de rebours qui réinjectent ces gaz dans les réseaux d'approvisionnement en gaz en amont ; voir la Figure 2.
Le présent document représente l'état de l'art au moment de son élaboration.
Le présent document ne s'applique pas aux stations d'injection en fonctionnement avant la publication du présent document.
Le présent document spécifie les principes de base communs pour les infrastructures gazières. Il convient que les utilisateurs du présent document gardent à l'esprit l'existence éventuelle, dans les pays membres du CEN, de codes de pratique et/ou de Normes nationales plus détaillés. Le présent document est destiné à être appliqué conjointement avec ces normes nationales et/ou codes de pratique, qui détaillent les principes de base précités.
Si la législation/réglementation nationale contient des termes relatifs à des exigences supplémentaires, en plus de ceux du présent document, le CEN/TR 13737 (toutes les parties) illustre ces termes.
Le CEN/TR 13737 (toutes les parties) donne :
- la législation/les réglementations applicables dans un État membre ;
- si applicable, des exigences nationales plus contraignantes ;
- un point de contact national pour les informations les plus récentes.
