EN 60352-1:1997
(Main)Solderless connections - Part 1: Wrapped connections - General requirements, test methods and practical guidance
Solderless connections - Part 1: Wrapped connections - General requirements, test methods and practical guidance
Determines the suitability of wrapped connections under specified mechanical, electrical and atmospheric conditions, and provides a means of comparing test results when the tools used to make the connections are of different design.
Lötfreie Verbindungen - Teil 1: Wickelverbindungen - Allgemeine Anforderungen, Prüfverfahren und Anwendungshinweise
Connexions sans soudure - Partie 1: Connexions enroulées - Règles générales, méthodes d'essai et guide pratique
Détermine la conformité des connexions enroulées dans des conditions mécaniques, électriques et atmosphériques spécifiées. Fournit un moyen de comparaison des résultats d'essai quand les outils utilisés pour faire les connexions sont de conception différente.
Solderless connections - Part 1: Wrapped connections - General requirements, test methods and practical guidance (IEC 60352-1:1997)
General Information
Standards Content (Sample)
SLOVENSKI STANDARD
01-september-2002
Solderless connections - Part 1: Wrapped connections - General requirements,
test methods and practical guidance (IEC 60352-1:1997)
Solderless connections -- Part 1: Wrapped connections - General requirements, test
methods and practical guidance
Lötfreie Verbindungen -- Teil 1: Wickelverbindungen - Allgemeine Anforderungen,
Prüfverfahren und Anwendungshinweise
Connexions sans soudure -- Partie 1: Connexions enroulées - Règles générales,
méthodes d'essai et guide pratique
Ta slovenski standard je istoveten z: EN 60352-1:1997
ICS:
29.120.20 Spojni elementi Connecting devices
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
NORME
CEI
INTERNATIONALE
IEC
60352-1
INTERNATIONAL
Troisième édition
STANDARD
Third edition
1997-08
Connexions sans soudure –
Partie 1:
Connexions enroulées –
Règles générales, méthodes d'essai
et guide pratique
Solderless connections –
Part 1:
Wrapped connections –
General requirements, test methods
and practical guidance
IEC 1997 Droits de reproduction réservés Copyright - all rights reserved
Aucune partie de cette publication ne peut être reproduite ni No part of this publication may be reproduced or utilized in
utilisée sous quelque forme que ce soit et par aucun any form or by any means, electronic or mechanical,
procédé, électronique ou mécanique, y compris la photo- including photocopying and microfilm, without permission in
copie et les microfilms, sans l'accord écrit de l'éditeur. writing from the publisher.
International Electrotechnical Commission 3, rue de Varembé Geneva, Switzerland
Telefax: +41 22 919 0300 e-mail: inmail@iec.ch IEC web site http: //www.iec.ch
CODE PRIX
Commission Electrotechnique Internationale
V
PRICE CODE
International Electrotechnical Commission
Pour prix, voir catalogue en vigueur
For price, see current catalogue
60352-1 © IEC:1997 – 3 –
CONTENTS
Page
FOREWORD . 5
INTRODUCTION. 7
Clause
1 Scope and object. 9
2 Normative references. 9
3 Definitions. 11
4 Requirements. 15
4.1 Workmanship . 15
4.2 Tools. 15
4.3 Posts . 17
4.4 Wrapping wires. 25
4.5 Wrapped connections . 27
5 Tests. 31
5.1 Testing. 31
5.2 Type tests. 31
5.3 Test schedules . 37
6 Practical guidance. 47
6.1 Current-carrying capacity .47
6.2 Tool information. 47
6.3 Post information . 51
6.4 Wire information. 59
6.5 Connection information .61
60352-1 © IEC:1997 – 5 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
_________
SOLDERLESS CONNECTIONS –
Part 1: Wrapped connections –
General requirements, test methods and practical guidance
FOREWORD
1) The IEC (International Electrotechnical Commission) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of the IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, the IEC publishes International Standards. Their preparation is
entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. The IEC collaborates closely with the International Organization
for Standardization (ISO) in accordance with conditions determined by agreement between the two
organizations.
2) The formal decisions or agreements of the IEC on technical matters express, as nearly as possible, an
international consensus of opinion on the relevant subjects since each technical committee has representation
from all interested National Committees.
3) The documents produced have the form of recommendations for international use and are published in the form
of standards, technical reports or guides and they are accepted by the National Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
5) The IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with one of its standards.
6) Attention is drawn to the possibility that some of the elements of this International Standard may be the subject
of patent rights. The IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60352-1 has been prepared by subcommittee 48B: Connectors, of
IEC technical committee 48: Electromechanical components and mechanical structures for
electronic equipment.
This third edition cancels and replaces the second edition published in 1983, of which it
constitutes a technical revision.
The text of this standard is based on the following documents:
FDIS Report on voting
48B/590/FDIS 48B/635/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
The contents of the corrigendum of October 1998 have been included in this copy.
60352-1 © IEC:1997 – 7 –
INTRODUCTION
This part of IEC 60352 includes requirements, tests and practical guidance information.
Two test schedules are provided.
The basic test schedule applies to wrapped connections which conform to all the requirements
of clause 4.
These requirements are derived from experience with successful applications of such wrapped
connections.
The full test schedule applies to wrapped connections which do not fully conform to all the
requirements of clause 4, for example those which are manufactured using materials or
finishes not included in clause 4.
This approach permits cost- and time-effective performance verification using a limited basic
test schedule for established wrapped connections and an expanded full test schedule for
wrapped connections requiring more extensive performance validation.
60352-1 © IEC:1997 – 9 –
SOLDERLESS CONNECTIONS –
Part 1: Wrapped connections –
General requirements, test methods and practical guidance
1 Scope and object
This part of IEC 60352 is applicable to wrapped connections made with single solid round wires
with nominal diameters of 0,16 mm minimum and appropriately designed posts for use in
telecommunications equipment and in electronic devices employing similar techniques.
Information on materials and data from industrial experience are included in addition to the test
procedures to provide electrically stable connections under prescribed environmental conditions.
The object of this standard is to determine the suitability of wrapped connections under
specified mechanical, electrical and atmospheric conditions, and to provide a means of
comparing test results when the tools used to make the connections are of different design or
manufacture.
2 Normative references
The following normative documents contain provisions which, through reference in this text,
constitute provisions of this part of IEC 60352. At the time of publication, the editions indicated
were valid. All normative documents are subject to revision, and parties to agreements based
on this part of IEC 60352 are encouraged to investigate the possibility of applying the most
recent editions of the normative documents indicated below. Members of IEC and ISO maintain
registers of currently valid International Standards.
IEC 60050(581): 1978, International Electrotechnical Vocabulary (IEV) – Chapter 581: Electro-
mechanical components for electronic equipment
IEC 60068-1: 1988, Environmental testing – Part 1: General and guidance
Amendment 1 (1992)
IEC 60352-5: 1995, Solderless connections – Part 5: Solderless press-in connections –
General requirements, test methods and practical guidance
IEC 60512-1: 1994, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 1: General
IEC 60512-2: 1985, Electromechanical components for electronic equipment; basic testing
procedures and measuring methods – Part 2: General examination, electrical continuity and
contact resistance tests, insulation tests and voltage stress tests
Amendment 1 (1994)
IEC 60512-6: 1984, Electromechanical components for electronic equipment; basic testing
procedures and measuring methods – Part 6: Climatic tests and soldering tests
IEC 60512-8: 1993, Electromechanical components for electronic equipment; basic testing
procedures and measuring methods – Part 8: Connector tests (mechanical) and mechanical
tests on contacts and terminations
IEC 60979: 1989, Wires for wire wrapping applications
ISO 468: 1982, Surface roughness – Parameters, their values and general rules for specifying
requirements
ISO 1337: 1980, Wrought coppers (having minimum copper contents of 99,85 %) – Chemical
composition and forms of wrought products
ISO 6507-1: 1982, Metallic materials – Hardness test – Vickers test – Part 1: HV 5 to HV 100
60352-1 © IEC:1997 – 11 –
3 Definitions
For the purpose of this part of IEC 60352, the terms and definitions included in IEC 60050(581)
and IEC 60512-1 and the following additional terms and definitions apply.
3.1 wrap post: A termination generally rectangular with sharp corners made to accept a
wrapped connection. [IEV 581-03-34, modified]
NOTE – In this standard, the term "wrap post" is shortened to "post".
3.2 wrapped connection: A solderless connection achieved by wrapping a solid conductor
around a wrap post (see figure 1). [IEV 581-03-10, modified]
IEC 1 019/97
Figure 1 – Wrapped connection
3.3 conventional wrapped connection: A solderless connection achieved by wrapping a
solid conductor around a wrap post without any contact of the wire insulation to the post (see
figure 2a). [IEV 581-03-45]
3.4 modified wrapped connection: A solderless connection achieved by wrapping a solid
conductor around a wrap post with the wire insulation wrapped around at least three corners of
the post (see figure 2b). [IEV 581-03-44]
3.5 turn of wire: A single helical ring of wire wrapped 360° around a wrap post. [IEV 581-03-65]
3.6 reference corner: That corner of the wrap post at which the stripped wire makes
its first indentation and from which the number of wrapped turns is counted (see figure 2).
[IEV 581-03-38]
60352-1 © IEC:1997 – 13 –
IEC 1 020/97 IEC 1 021/97
Figure 2a – Conventional Figure 2b – Modified
wrapped connection wrapped connection
Figure 2 – Reference corner
60352-1 © IEC:1997 – 15 –
3.7 end tail: The final portion of the last turn of wire in a wrapped connection which extends
beyond the last corner of contact (see figure 3). [IEV 581-03-54]
Figure 3 – End tail
3.8 gas-tight area: The part of the contact area that is not affected by gases under specified
conditions (see figure 1). [IEV 581-03-64]
3.9 stripping force: The force applied to the wrapped connection along the major axis of the
post which breaks the gas-tight areas. [IEV 581-03-55]
NOTE – The gas-tight areas are broken by the initial movement of the connection along the post.
3.10 effective wrapping length: That portion of a wrap post suitable and available for the
application of the wrapped connection for which all requirements are fixe
...
