Rubber, vulcanized or thermoplastic — Determination of
hardness — Part 8: Apparent hardness of rubber-covered rollers
by Pusey and Jones method
WARNING 1 — Persons using this document should be familiar with normal laboratory practice. This
document does not purport to address all of the safety problems, if any, associated with its use. It is the
responsibility of the user to establish appropriate safety and health practices and to determine the
applicability of any other restrictions.WARNING 2 — Certain procedures specified in this document might involve the use or generation of
substances, or the generation of waste, that could constitute a local environmental hazard. Reference
should be made to appropriate documentation on safe handling and disposal after use.
1 ScopeThis document specifies a method for the determination of the apparent hardness of vulcanized‐ or
thermoplastic‐rubber roller covers, expressed as the Pusey and Jones indentation value.
The Pusey and Jones plast...
