SIST EN 1465:2009

Adhesives - Determination of tensile lap-shear strength of bonded assemblies

This European Standard specifies a method for determining the tensile lap-shear strength of bonded assemblies when tested on a standard specimen and under specified conditions of preparation and testing.
NOTE   This test procedure is not applicable for calculations needed for bond design in structural joints.

Klebstoffe - Bestimmung der Zugscherfestigkeit von Überlappungsklebungen

Diese Europäische Norm legt ein Verfahren zur Bestimmung der Zugscherfestigkeit von Überlappungs¬klebungen fest, wenn sie an einer Normalprobe und unter festgelegten Vorbehandlungs- und Prüf¬bedingungen bestimmt wird.
ANMERKUNG   Dieses Prüfverfahren ist nicht für Berechnungen geeignet, die für die Auslegung von Klebever¬bindungen bei strukturellen Verbindungen benötigt werden.

Adhésifs - Détermination de la résistance au cisaillement en traction d'assemblages collés à recouvrement simple

La présente Norme européenne spécifie une méthode de détermination de la résistance au cisaillement
d’assemblages collés par essai de traction d’une éprouvette normalisée et dans des conditions de préparation
et d’essai spécifiées.
NOTE 1 Cette méthode d’essai ne peut pas être appliquée pour déterminer les caractéristiques nécessaires aux
calculs et à la conception des joints d’assemblages structuraux.
NOTE 2 Ces méthodes d’essai pour la détermination de la résistance au cisaillement en traction d’assemblages collés
à recouvrement simple avec des adhésifs pour bois sont aussi spécifiées dans l’EN 205 et l’EN 302-1.

Lepila - Določanje strižne trdnosti prekritih spojev dveh togih lepljencev z nategom

General Information

• Status: Published
• Publication Date: 06-Apr-2009
• ICS: 83.180 - Adhesives
• Technical Committee: IPMA - Polimer materials and products
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 02-Apr-2009
• Due Date: 07-Jun-2009
• Completion Date: 07-Apr-2009
• Directive: 305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
• Directive: 89/106/EEC - Construction products
• Mandate: M/127 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on construction adhesives
• Ref Project: EN 1465:2009 - Adhesives - Determination of tensile lap-shear strength of bonded assemblies

Relations

• Replaces: SIST EN 1465:1998 - Adhesives - Determination of tensile lap-shear strength of rigid-to-rigid bonded assemblies (ISO 4587:1979 modified)
• Effective Date: 01-May-2009

Overview

EN 1465:2009 - Adhesives: Determination of tensile lap-shear strength of bonded assemblies - is a CEN test method that defines how to measure the tensile lap-shear strength of single-overlap bonded specimens under specified preparation and test conditions. The standard describes specimen geometry, apparatus requirements, conditioning, test procedure, result expression and reporting. Note: this test is intended for comparative and quality testing and is not applicable for structural bond design calculations.

Key topics and requirements

• Specimen geometry and dimensions: standard single lap joint with recommended overlap L = (12.5 ± 0.25) mm (typical for aluminium alloys and materials of similar or higher modulus).
• Adherend preparation: surface treatment per manufacturer instructions or EN 13887; bond thickness control (typical 0.2 mm) using spacers (wire or glass spheres).
• Apparatus: Class 1 testing machine with short response time and self-aligning grips to avoid bending; grips that bolt through adherends are discouraged.
• Testing conditions: condition and test in standard atmospheres per EN ISO 291.
• Loading rate: apply tensile load so that the average joint fails in (65 ± 20) s; if constant load rate cannot be achieved, use a jaw separation rate approximating the required loading (see EN ISO 527‑1).
• Number of specimens: at least 5 observations are recommended for reliable results.
• Results and statistics: report individual breaking forces (N) and/or breaking stress (MPa = force / shear area), arithmetic mean and coefficient of variation. Guidance on precision: repeatability and reproducibility criteria are provided for reference.
• Test report content: complete identification of adhesive and adherends, surface treatment, bonding and curing details, bond thickness control, specimen details, conditioning, loading rate, individual results, failure mode (per EN ISO 10365) and any deviations.

Practical applications

• Comparative evaluation of adhesive performance (lap-shear strength) for product development.
• Quality control and batch verification in manufacturing of bonded components.
• Material selection and screening for adhesives and substrate combinations.
• Research and development where standardized, repeatable shear-strength measurement is required.
• Supplier testing and verification for non-structural bonded assemblies.

Who should use this standard

• Adhesive manufacturers and formulators
• Test laboratories and quality control teams
• Materials engineers and R&D departments
• OEMs and suppliers involved in bonded product manufacture (automotive, aerospace, electronics, general industrial)
• Certification bodies and procurement teams needing objective performance data

Related standards

• EN 13887 - Surface preparation guidelines for metals/plastics prior to bonding
• EN ISO 291 - Standard atmospheres for conditioning and testing
• EN ISO 527‑1 and EN ISO 10365 - Tensile test principles and failure pattern designation
• EN 205 / EN 302‑1 - Related methods for wood adhesives

Keywords: EN 1465:2009, tensile lap-shear strength, adhesives test method, bonded assemblies, lap-shear test, adhesive testing, bond strength measurement.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.QDWHJRPKlebstoffe - Bestimmung der Zugscherfestigkeit von ÜberlappungsklebungenAdhésifs - Détermination de la résistance au cisaillement en traction d'assemblages collés à recouvrement simpleAdhesives - Determination of tensile lap-shear strength of bonded assemblies83.180LepilaAdhesivesICS:Ta slovenski standard je istoveten z:EN 1465:2009SIST EN 1465:2009en,fr,de01-maj-2009SIST EN 1465:2009SLOVENSKI
STANDARDSIST EN 1465:19981DGRPHãþD

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 1465February 2009ICS 83.180Supersedes EN 1465:1994
English VersionAdhesives - Determination of tensile lap-shear strength ofbonded assembliesAdhésifs - Détermination de la résistance au cisaillementen traction d'assemblages collés à recouvrement simpleKlebstoffe - Bestimmung der Zugscherfestigkeit vonÜberlappungsklebungenThis European Standard was approved by CEN on 27 December 2008.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre:
Avenue Marnix 17,
B-1000 Brussels© 2009 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 1465:2009: ESIST EN 1465:2009

1 Scope This European Standard specifies a method for determining the tensile lap-shear strength of bonded assemblies when tested on a standard specimen and under specified conditions of preparation and testing. NOTE 1 This test procedure is not applicable for calculations needed for bond design in structural joints. NOTE 2 This test Test methods for the determination of tensile lap-shear strength of bonded assemblies with wood adhesives are also specified in EN 205 and EN 302-1 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 13887, Structural Adhesives - Guidelines for surface preparation of metals and plastics prior to adhesive bonding EN ISO 291, Plastics - Standard atmospheres for conditioning and testing (ISO 291:2005) EN ISO 527-1, Plastics - Determination of tensile properties - Part 1: General principles (ISO 527-1:1993 including Corr 1:1994) EN ISO 10365, Adhesives - Designation of main failure patterns (ISO 10365:1992) 3 Principle Adhesive lap-shear bond strength is determined by stressing in shear of a single overlap joint
(see Fig
...
