SIST EN 60317-36:2014/A1:2019

Specifications for particular types of winding wires - Part 36: Solderable polyesterimide enamelled round copper wire, class 180, with a bonding layer (IEC 60317-36:2013/A1:2019)

Technische Lieferbedingungen für bestimmte Typen von Wickeldrähten - Teil 36: Runddrähte aus Kupfer, verzinnbar und verbackbar, lackisoliert mit Polyesterimid, Klasse 180 (IEC 60317-36:2013/A1:2019)

Spécifications pour types particuliers de fils de bobinage - Partie 36: Fil brasable de section circulaire en cuivre émaillé avec polyesterimide, classe 180, avec une couche adhérente (IEC 60317-36:2013/A1:2019)

Specifikacije za posebne vrste navijalnih žic - 36. del: S poliesterimidom emajlirana okrogla bakrena žica, za spajkanje, razred 180, s spajalno plastjo - Dopolnilo A1 (IEC 60317-36:2013/A1:2019)

General Information

• Status: Published
• Publication Date: 18-Aug-2019
• ICS: 29.060.10 - Wires
• ICS: 77.150.30 - Copper products
• Technical Committee: I09 - Imaginarni 09
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Aug-2019
• Due Date: 06-Oct-2019
• Completion Date: 19-Aug-2019
• Ref Project: EN 60317-36:2014/A1:2019 - Specifications for particular types of winding wires - Part 36: Solderable polyesterimide enamelled round copper wire, class 180, with a bonding layer

Relations

• Amends: SIST EN 60317-36:2014 - Specifications for particular types of winding wires - Part 36: Solderable polyesterimide enamelled round copper wire, class 180, with a bonding layer
• Effective Date: 31-Jul-2018

Overview

EN 60317-36:2014/A1:2019 (aligned with IEC 60317-36:2013/A1:2019) specifies requirements for solderable polyesterimide enamelled round copper winding wire, class 180, with a bonding layer. This European amendment (A1, 2019) updates the original EN 60317-36 technical requirements and, in particular, refines the solderability clause to define mandatory test conditions for tinning and immersion. The standard is intended for manufacturers, test laboratories and users of winding wires used in high-temperature electrotechnical applications.

Key Topics

• Wire type and construction
  • Round copper conductor, polyesterimide enamel insulation with a bonding (adhesive) layer.
  • Insulation class 180 (for high-temperature operation).
• Solderability requirements (amendment highlights)
  • Solder bath temperature: 470 ± 5 °C.
  • Surface requirement: tinned wire must be smooth and free from holes and enamel residues.
  • Immersion times:
    • For nominal conductor diameters ≤ 0.100 mm: maximum immersion 3 s.
    • For diameters > 0.100 mm: maximum immersion time expressed as a multiple of conductor diameter (mm) with minimum 3 s:
      • Grade 1B: 12 s/mm
      • Grade 2B: 16 s/mm
• Quality and inspection
  • Visual and functional checks for tinning quality, adhesion of bonding layer, and absence of enamel residues.
• Standards governance
  • Published by CENELEC/CENELEC members; originates from IEC TC 55 “Winding wires.”

Applications

• Used where a combination of high temperature resistance and solderability is required:
  • Electric motors, transformers, chokes, inductors, relays and solenoids.
  • Automotive and industrial actuators that require robust enamel insulation and the ability to be soldered during assembly.
• Who uses this standard:
  • Winding wire manufacturers and suppliers (production specs and test criteria).
  • Design engineers and OEMs specifying materials for coils and windings.
  • Quality assurance and test laboratories performing solderability and acceptance tests.
  • Procurement teams verifying compliance of supplied wire to EN/IEC requirements.

Related Standards

• IEC/EN 60317 series (other parts covering different enamel types and test methods).
• National adoptions and translations of EN 60317-36:2014/A1:2019 (CENELEC member standards).

Keywords: EN 60317-36, IEC 60317-36, solderable polyesterimide enamelled wire, class 180, winding wires, solderability, bonding layer, immersion time.

Standards Content (Sample)

SLOVENSKI STANDARD
01-oktober-2019
Specifikacije za posebne vrste navijalnih žic - 36. del: S poliesterimidom
emajlirana okrogla bakrena žica, za spajkanje, razred 180, s spajalno plastjo -
Dopolnilo A1 (IEC 60317-36:2013/A1:2019)
Specifications for particular types of winding wires - Part 36: Solderable polyesterimide
enamelled round copper wire, class 180, with a bonding layer (IEC 60317-
36:2013/A1:2019)
Technische Lieferbedingungen für bestimmte Typen von Wickeldrähten - Teil 36:
Runddrähte aus Kupfer, verzinnbar und verbackbar, lackisoliert mit Polyesterimid, Klasse
180 (IEC 60317-36:2013/A1:2019)
Spécifications pour types particuliers de fils de bobinage - Partie 36: Fil brasable de
section circulaire en cuivre émaillé avec polyesterimide, classe 180, avec une couche
adhérente (IEC 60317-36:2013/A1:2019)
Ta slovenski standard je istoveten z: EN 60317-36:2014/A1:2019
ICS:
29.060.10 Žice Wires
77.150.30 Bakreni izdelki Copper products
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EUROPEAN STANDARD EN 60317-36:2014/A1

NORME EUROPÉENNE
EUROPÄISCHE NORM
July 2019
ICS 29.060.10
English Version
Specifications for particular types of winding wires - Part 36:
Solderable polyesterimide enamelled round copper wire, class
180, with a bonding layer
(IEC 60317-36:2013/A1:2019)
Spécifications pour types particuliers de fils de bobinage - Technische Lieferbedingungen für bestimmte Typen von
Partie 36: Fil brasable de section circulaire en cuivre Wickeldrähten - Teil 36: Runddrähte aus Kupfer, verzinnbar
émaillé avec polyesterimide, classe 180, avec une couche und verbackbar, lackisoliert mit Polyesterimid, Klasse 180
adhérente (IEC 60317-36:2013/A1:2019)
(IEC 60317-36:2013/A1:2019)
This amendment A1 modifies the European Standard EN 60317-36:2014; it was approved by CENELEC on 2019-07-17. CENELEC
members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this amendment the
status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This amendment exists in three official versions (English, French, German). A version in any other language made by translation under the
responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the same status as
the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Turkey and the United Kingdom.

European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2019 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Ref. No. EN 60317-36:2014/A1:2019 E
...
