SIST EN 13872:2004

Methods of test for hydraulic setting floor smoothing and/or levelling compounds - Determination of dimensional change

This European Standard specifies the measurement of dimensional change of a hydraulic setting smoothing and/or levelling compound which is referred to in the following as "smoothing and/or levelling compound".

Prüfverfahren für hydraulisch erhärtende Boden-Spachtelmassen - Bestimmung der Maßänderung

Diese Europäische Norm legt ein Verfahren zur Bestimmung der Maßänderung von hydraulisch erhärtenden Boden-Spachtelmassen fest, die im folgenden "Boden-Spachtelmassen" genannt werden.

Méthode d'essai pour les mortiers de lissage et/ou d'égalisation a prise hydraulique - Détermination des variations des dimensions

La présente Norme européenne spécifie le mesurage des variations dimensionnelles d'un mortier de lissage et/ou d'égalisation à prise hydraulique, désigné ci-après par « mortier de lissage et/ou d'égalisation.

Metode za preskušanje talnih izravnalnih in/ali livelirnih mas za hidravlično nanašanje – Ugotavljanje krčenja

General Information

• Status: Published
• Publication Date: 30-Sep-2004
• ICS: 91.100.99 - Other construction materials
• Technical Committee: IPMA - Polimer materials and products
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Oct-2004
• Due Date: 01-Oct-2004
• Completion Date: 01-Oct-2004
• Directive: 305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
• Directive: 89/106/EEC - Construction products
• Ref Project: EN 13872:2004 - Methods of test for hydraulic setting floor smoothing and/or levelling compounds - Determination of dimensional change

Overview

EN 13872:2004 is a CEN test method for measuring the dimensional change (shrinkage or expansion) of hydraulic setting floor smoothing and levelling compounds. The standard defines specimen geometry, measuring apparatus, test atmosphere and storage times to quantify length change of cast specimens and to report results as percent change. It is intended for manufacturers, testing laboratories, specifiers and quality-control personnel in the floor covering and construction-materials sectors.

Key topics & technical requirements

• Scope: Measurement of dimensional change of hydraulic setting smoothing and/or levelling compounds.
• Specimen size: Test specimens cast from moulds of nominal dimensions 10 ± 0.5 mm × 40 ± 0.5 mm × 160 ± 1.0 mm (three specimens minimum).
• Measuring accuracy: Appparatus capable of ±0.005 mm resolution; examples shown for vertical and horizontal measuring set-ups and for various measuring peg shapes (A–D).
• Standard atmosphere: Conditioning and testing at (23 ± 2) °C and (50 ± 5) % RH in accordance with ISO 554.
• Storage & measurement schedule: Initial measurement after demoulding (1 day), then at 3, 7, 14 and 28 days (storage A). Optional additional 28 days water immersion after the 28‑day dry storage with wet measurements (storage B).
• Result expression: Dimensional change reported as shrinkage (negative) or expansion (positive) in percent relative to the reference length (immediately after demoulding for storage A; immediately prior to immersion for storage B). Results are the arithmetic mean of three specimens, rounded to 0.01 %.
• Test report content: Must include reference to EN 13872, compound designation and batch, mixing method and time (per EN 1937), dimensional change values, any curling/twisting, influencing factors and test date.

Practical applications

• Verify product performance and dimensional stability of floor smoothing and levelling compounds used under floor coverings.
• Support quality control during production and batch verification.
• Provide objective data for product datasheets, technical approvals and comparison between formulations.
• Aid specifiers, flooring contractors and certification bodies in assessing risk of curl, shrinkage or expansion that could affect finishing layers.

Who uses this standard

• Manufacturers of hydraulic setting smoothing/levelling compounds
• Materials testing laboratories and QA departments
• Flooring product specifiers, consultants and certification bodies
• R&D teams optimizing formulation and dimensional stability

Related standards

• EN 1937:1999 - Test method for hydraulic setting floor smoothing and/or levelling compounds (mixing procedures)
• EN 196-1 - Methods of testing cement - Part 1: Determination of strength (relevant apparatus and mould practice)
• ISO 554 - Standard atmospheres for conditioning and/or testing

Keywords: EN 13872:2004, dimensional change, shrinkage, floor smoothing compound testing, levelling compounds, hydraulic setting, CEN test method, construction materials testing.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Prüfverfahren für hydraulisch erhärtende Boden-Spachtelmassen - Bestimmung der MaßänderungMéthode d'essai pour les mortiers de lissage et/ou d'égalisation a prise hydraulique - Détermination des variations des dimensionsMethods of test for hydraulic setting floor smoothing and/or levelling compounds - Determination of dimensional change91.100.99Drugi gradbeni materialiOther construction materialsICS:Ta slovenski standard je istoveten z:EN 13872:2004SIST EN 13872:2004en,fr,de01-oktober-2004SIST EN 13872:2004SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 13872February 2004ICS 91.100.99English versionMethod of test for smoothing and/or levelling compounds -Determination of shrinkageMéthode d'essai pour les mortiers de lissage et/oud'égalisation - Détermination du retraitPrüfverfahren für Boden-Spachtelmassen - Bestimmungder SchrumpfungThis European Standard was approved by CEN on 10 December 2003.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2004 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 13872:2004: ESIST EN 13872:2004
...
