ABSTRACT
This specification covers the principal design and type of material for manufacturing fittings for watertight/gastight/airtight, weathertight, and non-tight doors, for marine use. The fittings are intended for use on all doors for marine use, except joiner and expanded metal doors. The dogs and hinges shall be classified as follows: Dog A and B; hinge A and B. All securing screws and fasteners shall be of stainless steel.
SCOPE
1.1 This specification covers the principal design and type of material for manufacturing fittings for watertight/gastight/airtight, weathertight, and non-tight doors, for marine use. Note that “gastight” is commercial terminology which also means “airtight” in naval terminology.
1.2 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
1.3 The fittings are intended for use on all doors for marine use, except joiner and expanded metal doors.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
General Information
Relations
Buy Standard
Standards Content (Sample)
This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: F1073 −19 An American National Standard
Standard Specification for
Door Fittings, for Watertight /Gastight /Airtight,
1
Weathertight, and Non-Tight Doors, for Marine Use
This standard is issued under the fixed designation F1073; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope B210 Specification for Aluminum and Aluminum-Alloy
Drawn Seamless Tubes (Metric) B0210_B0210M
1.1 This specification covers the principal design and type
B211 Specification for Aluminum and Aluminum-Alloy
of material for manufacturing fittings for watertight/gastight/
Rolled or Cold-Finished Bar, Rod, and Wire (Metric)
airtight,weathertight,andnon-tightdoors,formarineuse.Note
B0211_B0211M
that “gastight” is commercial terminology which also means
3
2.2 Military Standards:
“airtight” in naval terminology.
MIL-C-81706 Coating, Aluminum and Aluminum Alloys
1.2 The values stated in inch-pound units are to be regarded
MIL-DRL-24441D
as standard. The values given in parentheses are mathematical
MIL-DTL-24441/20B(SH) Paint, Epoxy-Polyamide, Green
conversions to SI units that are provided for information only
Primer, Formula 150, Type III
and are not considered standard.
MIL-DTL-24441/21B(SH) Paint, Epoxy-Polyamide, Haze
1.3 The fittings are intended for use on all doors for marine Gray Formula 151, Type III
use, except joiner and expanded metal doors. MIL-P-17578A Packing Material, Plastic (for Dogs for Wa-
tertight Closures) (Symbol 1425)
1.4 This international standard was developed in accor-
NAVSEA SI 009-32 Cleaning and Painting Requirements;
dance with internationally recognized principles on standard-
Accomplish
ization established in the Decision on Principles for the
3
2.3 Federal Specifications:
Development of International Standards, Guides and Recom-
QQ-C-390B (Notice 2) Copper Alloy Castings (see this
mendations issued by the World Trade Organization Technical
notice for ASTM references)
Barriers to Trade (TBT) Committee.
MIL-PRF-24635 Performance Specification: Coating
Systems, Weather-Resistant, Exterior Use
2. Referenced Documents
2.4 ANSI Standard:
2
2.1 ASTM Standards:
4
A2.6 Standard for Fire Tests of Window Assemblies
A36/A36M Specification for Carbon Structural Steel
2.5 AISI Standard:
A240/A240M Specification for Chromium and Chromium-
5
316 Low Alloy Stainless Steel (Cres 316)
Nickel Stainless Steel Plate, Sheet, and Strip for Pressure
Vessels and for General Applications
3. Classification
A276 Specification for Stainless Steel Bars and Shapes
3.1 The dogs and hinges shall be classified as given in Table
A563 Specification for Carbon and Alloy Steel Nuts
1.
A668/A668M Specification for Steel Forgings, Carbon and
Alloy, for General Industrial Use
4. Ordering Information
B140/B140M Specification for Copper-Zinc-Lead (Red
4.1 Ordering for fittings shall be indicated on the purchase
Brass or Hardware Bronze) Rod, Bar, and Shapes
order prepared for doors, with reference to this specification
noted.
1 4.2 When ordering fittings, indicate the following:
This specification is under the jurisdiction of ASTM Committee F25 on Ships
and Marine Technology and is the direct responsibility of Subcommittee F25.03 on
Outfitting and Deck Machinery.
3
Current edition approved March 1, 2019. Published April 2019. Originally Available from Standardization Documents Order Desk, DODSSP, Bldg. 4,
approved in 1987. Last previous edition approved in 2012 as F1073 – 87 (2012). Section D, 700 Robbins Ave., Philadelphia, PA 19111-5098, http://
DOI: 10.1520/F1073-19. www.dodssp.daps.mil.
2 4
For referenced ASTM standards, visit the ASTM website, www.astm.org, or Available from American National Standards Institute (ANSI), 25 W. 43rd St.,
contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM 4th Floor, New York, NY 10036, http://www.ansi.org.
5
Standards volume information, refer to the standard’s Document Summary page on Available from American Iron and Steel Institute (AISI), 1140 Connecticut
the ASTM website. Ave., NW, Suite 705, Washington, DC 20036, http://www.steel.org.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
F1073 − 19
TABLE 1 Classification of Dogs and Hinges
Type Description
Dog:
A Fitted to door
B Fitted to door frame
Hinge:
A With clenched pin
B With clenched pin secured with cotter pin
4.2.1 Type, 7.2.1 Mild steel fittings
...
This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: F1073 − 87 (Reapproved 2012) F1073 − 19 An American National Standard
Standard Specification for
Door Fittings, for Watertight /Gastight /Airtight,
1
Weathertight, and Non-Tight Doors, for Marine Use
This standard is issued under the fixed designation F1073; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope
1.1 This specification covers the principal design and type of material for manufacturing fittings for watertight/gastight/airtight,
weathertight, and non-tight doors, for marine use. Note that “gastight” is commercial terminology which also means “airtight” in
naval terminology.
1.2 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical
conversions to SI units that are provided for information only and are not considered standard.
1.3 The fittings are intended for use on all doors for marine use, except joiner and expanded metal doors.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2
2.1 ASTM Standards:
A36/A36M Specification for Carbon Structural Steel
A240/A240M Specification for Chromium and Chromium-Nickel Stainless Steel Plate, Sheet, and Strip for Pressure Vessels and
for General Applications
A276 Specification for Stainless Steel Bars and Shapes
A563 Specification for Carbon and Alloy Steel Nuts
A668/A668M Specification for Steel Forgings, Carbon and Alloy, for General Industrial Use
B140/B140M Specification for Copper-Zinc-Lead (Red Brass or Hardware Bronze) Rod, Bar, and Shapes
B210 Specification for Aluminum and Aluminum-Alloy Drawn Seamless Tubes (Metric) B0210_B0210M
B211 Specification for Aluminum and Aluminum-Alloy Rolled or Cold-Finished Bar, Rod, and Wire (Metric) B0211_B0211M
3
2.2 Military Standards:
MIL-P-24441MIL-C-81706 Epoxy-Polyamide PaintCoating, Aluminum and Aluminum Alloys
MIL-DRL-24441D
MIL-DTL-24441/20B(SH) Paint, Epoxy-Polyamide, Green Primer, Formula 150, Type III
MIL-DTL-24441/21B(SH) Paint, Epoxy-Polyamide, Haze Gray Formula 151, Type III
MIL-P-17578A Packing Material, Plastic (for Dogs for Watertight Closures) (Symbol 1425)
MIL-C-81706NAVSEA SI 009-32 Coating, Aluminum and Aluminum AlloysCleaning and Painting Requirements; Accomplish
DOD-STD-2138 Metal Sprayed Coating Systems for Corrosion Protection
3
2.3 Federal Specifications:
QQ-C-390QQ-C-390B (Notice 2) Copper Alloy Castings (see this notice for ASTM references)
TT-E-490MIL-PRF-24635 Enamel-Silicone Alkyd Copolymer, Semi-gloss, ExteriorPerformance Specification: Coating
Systems, Weather-Resistant, Exterior Use
1
This specification is under the jurisdiction of ASTM Committee F25 on Ships and Marine Technology and is the direct responsibility of Subcommittee F25.03 on
Outfitting and Deck Machinery.
Current edition approved Oct. 1, 2012March 1, 2019. Published October 2012April 2019. Originally approved in 1987. Last previous edition approved in 20072012 as
F1073 – 87 (2012).(2007). DOI: 10.1520/F1073-87R12.10.1520/F1073-19.
2
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
3
Available from Standardization Documents Order Desk, DODSSP, Bldg. 4, Section D, 700 Robbins Ave., Philadelphia, PA 19111-5098, http://www.dodssp.daps.mil.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
F1073 − 19
2.4 ANSI Standard:
4
A2.6 Standard for Fire Tests of Window Assemblies
2.5 AISI Standard:
5
316 Low Alloy Stainless Steel (Cres 316)
3. Classification
3.1 The dogs and hinges shall be classified as given in Table 1.
4. Ordering Information
4.1 Ordering for fittings shall be indicated on the purchase order prepared for doors, with reference to this specification noted.
4.2 When ordering fittings, indicate the following:
4.2.1 Type,
4.2.2 Quantity,
4.2.3 Marking (see Section 8), and
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
