EN ISO 636:2008
(Main)Welding consumables - Rods, wires and deposits for tungsten inert gas welding of non-alloy and fine-grain steels - Classification (ISO 636:2004)
Welding consumables - Rods, wires and deposits for tungsten inert gas welding of non-alloy and fine-grain steels - Classification (ISO 636:2004)
ISO 636:2004 specifies requirements for classification of rods and wires in the as-welded condition and in the post-weld heat-treated condition for tungsten inert gas welding of non-alloy and fine grain steels with a minimum yield strength of up to 500 MPa or a minimum tensile strength of up to 570 MPa.
ISO 636:2004 is a combined specification providing classification utilizing a system based upon the yield strength and the average impact energy of 47 J of all-weld metal, or utilizing a system based upon the tensile strength and the average impact energy of 27 J of all-weld metal.
Schweißzusätze - Stäbe, Drähte und Schweißgut zum Wolfram-Inertgasschweißen von unlegierten Stählen und Feinkornstählen - Einteilung (ISO 636:2004)
Diese Internationale Norm legt Anforderungen zur Einteilung von Stäben und Drähten zum Wolfram-Inertgas-Schweißen von unlegierten Stählen und Feinkornstählen mit einer Mindeststreckgrenze bis 500 MPa oder einer Mindestzugfestigkeit bis 570 MPa im Schweißzustand und nach einer Wärmenachbehandlung fest.
Diese Internationale Norm enthält eine gemeinsame Spezifikation zur Einteilung entweder nach der Streckgrenze und der durchschnittlichen Kerbschlagarbeit von 47 J des reinen Schweißgutes oder nach der Zugfestigkeit und der durchschnittlichen Kerbschlagarbeit von 27 J des reinen Schweißgutes.
1) Abschnitte und Tabellen, gekennzeichnet durch ein nachgestelltes „A“, können nur für Stäbe und Drähte angewendet werden, die nach der Streckgrenze und der durchschnittlichen Kerbschlagarbeit von 47 J des reinen Schweißgutes nach dieser Internationalen Norm eingeteilt werden.
2) Abschnitte und Tabellen, gekennzeichnet durch ein nachgestelltes „B“, können nur für Stäbe und Drähte angewendet werden, die nach der Zugfestigkeit und der durchschnittlichen Kerbschlagarbeit von 27 J des reinen Schweißgutes nach dieser Internationalen Norm eingeteilt werden.
3) Abschnitte und Tabellen, die kein nachgestelltes „A“ oder „B“ enthalten, sind für alle nach dieser Internationalen Norm eingeteilten Stäbe und Drähte anwendbar.
Produits consommables pour le soudage - Baguettes et fils pour dépôts par soudage TIG des aciers non alliés et des aciers à grains fins - Classification (ISO 636:2004)
L'ISO 636:2004 spécifie les exigences relatives à la classification des baguettes et des fils à l'état brut de soudage et à l'état traité thermiquement après soudage, en soudage TIG (soudage à l'arc sous protection de gaz inerte avec électrode de tungstène) des aciers non alliés et des aciers à grains fins ayant une limite d'élasticité minimale pouvant atteindre 500 MPa ou une résistance à la traction minimale pouvant atteindre 570 MPa.
L'ISO 636:2004 propose une spécification mixte permettant une classification utilisant un système fondé soit sur la limite d'élasticité et l'énergie de rupture moyenne de 47 J pour le métal fondu hors dilution, soit sur la résistance à la traction et l'énergie de rupture moyenne de 27 J pour le métal fondu hors dilution.
Dodajni materiali za varjenje - Palice, žice in čisti vari pri varjenju nelegiranih in drobnozrnatih jekel po TIG - Razvrstitev (ISO 636:2004)
General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
01-september-2008
1DGRPHãþD
SIST EN 1668:1999
'RGDMQLPDWHULDOL]DYDUMHQMH3DOLFHåLFHLQþLVWLYDULSULYDUMHQMXQHOHJLUDQLKLQ
GUREQR]UQDWLKMHNHOSR7,*5D]YUVWLWHY ,62
Welding consumables - Rods, wires and deposits for tungsten inert gas welding of non-
alloy and fine-grain steels - Classification (ISO 636:2004)
Schweißzusätze - Stäbe, Drähte und Schweißgut zum Wolfram-Inertgasschweißen von
unlegierten Stählen und Feinkornstählen - Einteilung (ISO 636:2004)
Produits consommables pour le soudage - Baguettes et fils pour dépôts par soudage
TIG des aciers non alliés et des aciers à grains fins - Classification (ISO 636:2004)
Ta slovenski standard je istoveten z: EN ISO 636:2008
ICS:
25.160.20 Potrošni material pri varjenju Welding consumables
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
EUROPEAN STANDARD
EN ISO 636
NORME EUROPÉENNE
EUROPÄISCHE NORM
May 2008
ICS 25.160.20 Supersedes EN 1668:1997
English Version
Welding consumables - Rods, wires and deposits for tungsten
inert gas welding of non-alloy and fine-grain steels -
Classification (ISO 636:2004)
Produits consommables pour le soudage - Baguettes et fils Schweißzusätze - Stäbe, Drähte und Schweißgut zum
pour dépôts par soudage TIG des aciers non alliés et des Wolfram-Inertgasschweißen von unlegierten Stählen und
aciers à grains fins - Classification (ISO 636:2004) Feinkornstählen - Einteilung (ISO 636:2004)
This European Standard was approved by CEN on 5 April 2008.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European
Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national
standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the
official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,
France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,
Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: rue de Stassart, 36 B-1050 Brussels
© 2008 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN ISO 636:2008: E
worldwide for CEN national Members.
Contents Page
Foreword.3
Foreword
The text of ISO 636:2004 has been prepared by Technical Committee ISO/TC 44 “Welding and allied
processes” of the International Organization for Standardization (ISO) and has been taken over as EN ISO
636:2008 by Technical Committee CEN/TC 121 “Welding” the secretariat of which is held by DIN.
This European Standard shall be given the status of a national standard, either by publication of an identical
text or by endorsement, at the latest by November 2008, and conflicting national standards shall be withdrawn
at the latest by November 2008.
Attention is drawn to the possibility that some of the elements of this document may be the subject of patent
rights. CEN [and/or CENELEC] shall not be held responsible for identifying any or all such patent rights.
This document supersedes EN 1668:1997.
According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following
countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Cyprus, Czech
Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain,
Sweden, Switzerland and the United Kingdom.
Endorsement notice
The text of ISO 636:2004 has been approved by CEN as a EN ISO 636:2008 without any modification.
INTERNATIONAL ISO
STANDARD 636
Third edition
2004-05-15
Welding consumables — Rods, wires and
deposits for tungsten inert gas welding of
non-alloy and fine-grain steels —
Classification
Produits consommables pour le soudage — Baguettes et fils pour
dépôts par soudage TIG des aciers non alliés et des aciers à grains
fins — Classification
Reference number
ISO 636:2004(E)
©
ISO 2004
ISO 636:2004(E)
PDF disclaimer
This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but
shall not be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In
downloading this file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat
accepts no liability in this area.
Adobe is a trademark of Adobe Systems Incorporated.
Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation
parameters were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In
the unlikely event that a problem relating to it is found, please inform the Central Secretariat at the address given below.
© ISO 2004
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means,
electronic or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or
ISO's member body in the country of the requester.
ISO copyright office
Case postale 56 • CH-1211 Geneva 20
Tel. + 41 22 749 01 11
Fax + 41 22 749 09 47
E-mail copyright@iso.org
Web www.iso.org
Published in Switzerland
ii © ISO 2004 – All rights reserved
ISO 636:2004(E)
Contents Page
Foreword. iv
Introduction . v
1 Scope. 1
2 Normative references . 1
3 Classification. 2
4 Symbols and requirements. 2
4.1 Symbol for the product/process. 2
4.2 Symbol for strength and elongation of all-weld metal . 2
4.3 Symbol for impact properties of all-weld metal. 3
4.4 Symbol for the chemical composition of rods or wires. 4
5 Mechanical tests . 8
5.1 Preheating and interpass temperatures . 8
5.2 Welding conditions and pass sequence. 9
5.3 PWHT condition . 9
6 Chemical analysis . 9
7 Retests . 9
8 Technical delivery conditions. 10
9 Designation. 10
ISO 636:2004(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards bodies
(ISO member bodies). The work of preparing International Standards is normally carried out through ISO
technical committees. Each member body interested in a subject for which a technical committee has been
established has the right to be represented on that committee. International organizations, governmental and
non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the
International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization.
International Standards are drafted in accordance with the rules given in the ISO/IEC Directives, Part 2.
The main task of technical committees is to prepare International Standards. Draft International Standards
adopted by the technical committees are circulated to the member bodies for voting. Publication as an
International Standard requires approval by at least 75 % of the member bodies casting a vote.
Attention is drawn to the possibility that some of the elements of this document may be the subject of patent
rights. ISO shall not be held responsible for identifying any or all such patent rights.
ISO 636 was prepared by Technical Committee ISO/TC 44, Welding and allied processes, Subcommittee
SC 3, Welding consumables.
This third edition cancels and replaces the second edition (ISO 636:1989), which has been technically revised.
iv © ISO 2004 – All rights reserved
ISO 636:2004(E)
Introduction
This International Standard provides a classification for the designation of rods and wires in terms of their
chemical composition and, where required, in terms of the yield strength, tensile strength and elongation of
the all-weld metal. The ratio of yield to tensile strength of weld metal is generally higher than that of parent
metal. Users should note that matching weld metal yield strength to parent metal yield strength will not
necessarily ensure that the weld metal tensile strength matches that of the parent material. Where the
application requires matching tensile strengths, selection of consumable should be made by reference to
column 3 of Table 1A or Table 1B.
It should be noted that the mechanical properties of all-weld metal test specimens used to classify the rods
and wires vary from those obtained in production joints because of differences in welding procedure such as
diameter, width of weave, welding position and material composition.
The classification according to system A is mainly based on EN 1668:1997, Welding consumables — Rods,
wires and deposits for tungsten inert gas welding of non alloy and fine grain steels — Classification. The
classification according to system B is mainly based upon standards used around the Pacific Rim.
Requests for official interpretations of any aspect of this International Standard should be directed to the
Secretariat of ISO/TC 44/SC 3, via your national standards body, a complete listing of which can be found at
www.iso.org.
INTERNATIONAL STANDARD ISO 636:2004(E)
Welding consumables — Rods, wires and deposits for tungsten
inert gas welding of non-alloy and fine-grain steels —
Classification
1 Scope
This International Standard specifies requirements for classification of rods and wires in the as-welded
condition and in the post-weld heat-treated condition for tungsten inert gas welding of non-alloy and fine grain
steels with a minimum yield strength of up to 500 MPa or a minimum tensile strength of up to 570 MPa.
This International Standard is a combined specification providing classification utilizing a system based upon
the yield strength and the average impact energy of 47 J of all-weld metal, or utilizing a system based upon
the tensile strength and the average impact energy of 27 J of all-weld metal.
1) Paragraphs and tables which carry the suffix letter “A” are applicable only to rods and wires classified
to the system based upon the yield strength and the average impact energy of 47 J of all-weld metal
in accordance with this International Standard.
2) Paragraphs and tables which carry the suffix letter “B” are applicable only to rods and wires classified
to the system based upon the tensile strength and the average impact energy of 27 J of all-weld
metal in accordance with this International Standard.
3) Paragraphs and tables which have neither the suffix letter “A” nor the suffix letter “B” are applicable
to all rods and wires classified in accordance with this International Standard.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 31-0:1992, Quantities and units — Part 0: General principles
ISO 544, Welding consumables — Technical delivery conditions for welding filler materials — Type of product,
dimensions, tolerances and markings
ISO 13916, Welding — Guidance on the measurement of preheating temperature, interpass temperature and
preheat maintenance temperature
...
