Metallic and other non-organic coatings - Review of methods of measurement of thickness (ISO 3882:1986)

Metallische und andere anorganische Schichten - Übersicht von Verfahren der Schichtdickenmessung (ISO 3882:1986)

Diese Internationale Norm fasst die verschiedenen Verfahren, die für die Messung von Schichtdicken verwendet werden, zusammen und beschreibt deren Arbeitsprinzipien. Verfahren zur Schichtdickenmessung können entweder zerstörend oder zerstörungsfrei sein (siehe Tabelle 1). Die in Tabelle 2 und 3 aufgeführten Angaben sollen bei der Auswahl der für einen bestimmten Zweck geeignetsten Verfahren helfen.

Revêtements métalliques et autres revêtements non organiques - Vue d'ensemble sur les méthodes de mesurage de l'épaisseur (ISO 3882:1986)

Kovinske in druge anorganske prevleke - Pregled postopkov za merjenje debeline (ISO 3882:1986)

General Information

Status
Withdrawn
Publication Date
27-Oct-1994
Withdrawal Date
14-Apr-2003
Current Stage
9960 - Withdrawal effective - Withdrawal
Start Date
15-Apr-2003
Completion Date
15-Apr-2003

Relations

Buy Standard

Standard
EN ISO 3882:1999
English language
8 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)

SLOVENSKI STANDARD
SIST EN ISO 3882:1999
01-oktober-1999
Kovinske in druge anorganske prevleke - Pregled postopkov za merjenje debeline
(ISO 3882:1986)
Metallic and other non-organic coatings - Review of methods of measurement of
thickness (ISO 3882:1986)
Metallische und andere anorganische Schichten - Übersicht von Verfahren der
Schichtdickenmessung (ISO 3882:1986)
Revetements métalliques et autres revetements non organiques - Vue d'ensemble sur
les méthodes de mesurage de l'épaisseur (ISO 3882:1986)
Ta slovenski standard je istoveten z: EN ISO 3882:1994
ICS:
17.040.20 Lastnosti površin Properties of surfaces
25.220.20 Površinska obdelava Surface treatment
25.220.40 Kovinske prevleke Metallic coatings
SIST EN ISO 3882:1999 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------

SIST EN ISO 3882:1999

---------------------- Page: 2 ----------------------

SIST EN ISO 3882:1999

---------------------- Page: 3 ----------------------

SIST EN ISO 3882:1999

---------------------- Page: 4 ----------------------

SIST EN ISO 3882:1999

---------------------- Page: 5 ----------------------

SIST EN ISO 3882:1999

---------------------- Page: 6 ----------------------

SIST EN ISO 3882:1999
International Standard
INTERNATIONAL ORGANIZATION FOR STANDARDIZATION.MEIKflYHAPOAHAR OPrAHM3ALWlR fl0 CTAH~APTt43A~MM*ORGANISATlON INTERNATIONALE DE NORMALISATION
Metallic and other non-organic coatings - Review of
methods of measurement of thickness
Rev&ements m&alliques et autres revetements non organiques -
Vue d’ensemble SW les mhthodes de mesurage de l’epaisseur
Second edition - 1986-04-01
UDC 669.058 : 531.717 Ref. No. ISO 38824986 (E)
dimensional measurement, thickness.
Descriptors : coatings, metal coatings, non metallic coatings, tests,
Price based on 5 pages

---------------------- Page: 7 ----------------------

SIST EN ISO 3882:1999
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of
national Standards bodies (ISO member bodies). The work of preparing International
Standards is normally carried out through ISO technical committees. Esch member
body interested in a subject for which a technical committee has been established has
the right to be represented on that committee. International organizations, govern-
mental and non-governmental, in liaison with ISO, also take part in the work.
Draft International Standards adopted by the technical committees are circulated to
the member bodies for approval before their acceptance as International Standards by
the ISO Council. They are approved in accordance with ISO procedures requiring at
least 75 % approval by the member bodies voting.
International Standard ISO 3882 was prepared by Technical Committee ISO/TC 107,
Metall’ic and other non-organic coatings.
This second edition cancels and replaces the first edition (ISO 3882-1976), table 2 of
which has been technically revised.
Users should note that all International Standards undergo revision from time to time
and that any reference made herein to any other International Standard implies its
latest edition, unless otherwise stated.
International Organkation for Standardkation, 1986
0
Printed in Switzerland

---------------------- Page: 8 ----------------------

SIST EN ISO 3882:1999
ISO 38824986 (EI
INTERNATIONAL STANDARD
Metallic and other non-organic coatings - Review of
methods of measurement of thickness
0 Introduction ISO 2361, Electrodeposited nicke1 coatings on magnetic and
non-magnetic Substrates -
Measuremen t of cos ting thickness
- Magnetit method.
This International Standard summarizes the various methods
used for the measurement of coating thickness and describes
their working principles. Methods of measuring coating ISO 3497, Metallic cos tings - Measuremen t of cos ting
thickness may be either destructive or non-destructive (see thickness - X-ray spectrometric methods.
table 1). The information given in table 2 and table 3 will assist
in the choice of the method most suited to a particular purpose.
ISO 3543, Metallic and non-metallic coatings - Measurement
of thickness - Beta backscatter method.
The thickness ranges covered by the different methods depend
on the coating materials, Substrates and instruments used.
ISO 3868, Metallic and other non-organic coatings - Measure-
men t o f cos ting thicknesses - Fizeau multiple-beam in-
terferometry method.
ISO 4518, Metallic coatings - Measurement of coating
1 Scope and field of application
thickness - Pro filome tric me thod.
This International Standard reviews methods for measuring the
thickness of metallic and other non-organic coatings on both
metallic and non-metallic Substrates. lt is limited to tests
3 Definitions
already specified, or to be specified, in International Standards,
and excludes certain tests which are employed for special
For the purpose of this International Standard, the definitions
applications.
of ISO 2064 apply.
4 Non-destructive methods
2 References
4.1 Magnetit methods
ISO 1463, Metallic and Oxide coatings - Measuremen t of
coating thickness - Microscopical method.
Instruments for these methods measure either the magnetic at-
traction between a magnet and the basis metal, as influenced
ISO 2664, Metallic and other non-organic coatings - Defini-
by the presence of the coating, or the reluctance of a magnetic
tions and conventions concerning the measurement of
flux path passing through the coating and the basis metal.
thickness.
The measurement uncertainty of the method is normally less
ISO 2128, Anodizing of aluminium and its alle ys - Determina-
than 10 % of the thickness or 1,5 Fm, whichever is the greater.
tion of thickness of anodic Oxide coatings - Non-destructive
measuremen t b y Split-beam microscope.
These methods are limited in practice to non-magnetic coatings
on a magnetic Substrate (see ISO 2178) and to electroplated
ISO 2177, Metallic coatings - Measurement of coating
nicke1 coatings on magnetic or non-magnetic Substrates (sec
thickness - Coulometric method by anodic dissolution.
ISO 2361).
ISO 2178, Non-magnetic coatings on magnetic Substrates -
4.2 Eddy current method
Measuremen t of coating thickness - Magnetit method.
This method is based on differentes in electrical conductivity
ISO 2360, Non-conductive coatings on non-magnetic basis
between coatings and Substrates. lt is used primarily for
me tals - Measurement of coating thickness - Eddy current
measuring the thicknesses of non-conductive coatings on non-
me thod.
1

---------------------- Page: 9 ----------------------

SIST EN ISO 3882:1999
I 38824986 (EI
magnetic metals and sf Single layer metal coatings on non-
csnductors. lf this method is used for measuring thicknesses of
method (sec ISO 21281
metallic coatings on metallic Substrates, great care is necessary
if acceptable results are to be obtained. This equipment was originally designed for the measurement of
surface roughness, but it is also used for measuring the
XJ-J
measurement of
2360 only covers the the thickness of a thickness of transparent and translucent coatings, in particular
n a non-magnetic basis metal.
non -conductive coating o anodic oxide coatings on aluminium. A light beam is projected
on to the surface at an angle of 45”. Part of the beam is
measuremen t un certainty of the method is usually less
--i-he reflected from the surface of the coating while the other part
than 10 % or 0,5 whichever is the greater. penetrates the coating and is reflected from the coating/metaI
WJ
Substrate interface. The distance which separates the two im-
ages observed in the eyepiece of the microscope is proportional
4.3 X-ray spectrometric methods
to the thickness ~f the coating and tan be measured by means
of a vernier screw which controls a calibrated graticule. The
These methods use emission and absorption X-ray spec-
method tan be used where sufficient light is reflected from the
trometry for determining thickness sf metallic coatings.
coating/metaI Substrate interface to give a clear image in the
microscope. For transparent or translucent coatings, such as
X-rays are made to hit a fixed area sf the coated surface and the
anodic oxide films, this method is non-destructive.
intensity of the secondary radiation emitted by the coating, or
by the Substrate and attenuated by the coating, is measured. A
For measuring the thickness of opaque coatings, a small area of
correlation exists between the intensity of the X-rays and the
the coating has to be removed and in this application the
coating thickness; this is established using calibration stan-
method is destructive. The step between the surface of the
dards.
coating and the basis metal produces a deflection of the light
beam which gives an absolute measure of the coating
The X-ray method is generally appl i ca ble but its accuracy is
thickness.
reduced in the following situations :
The
...
