prEN ISO 6789-1
(Main)Assembly tools for screws and nuts - Hand torque tools - Part 1: Requirements and methods for design conformance testing and quality conformance testing: minimum requirements for declaration of conformance (ISO/DIS 6789-1:2025)
Assembly tools for screws and nuts - Hand torque tools - Part 1: Requirements and methods for design conformance testing and quality conformance testing: minimum requirements for declaration of conformance (ISO/DIS 6789-1:2025)
This document specifies the conformance testing and marking requirements for hand torque tools used for controlled tightening of screws and nuts. It also specifies the minimum requirements for a manufacturer’s declaration of conformance for hand torque tools.
This document applies to hand torque tools which are classified as indicating torque tools (Type I) and setting torque tools (Type II).
NOTE Hand torque tools covered by this document are those identified in ISO 1703:2018 by reference numbers 7 1 00 01 0 to 7 1 00 14 0 inclusive. Torque limiting hand torque tools do not yet have reference numbers and will not do so until the next revision of ISO 1703
This document does not specify requirements of calibration certificates for hand torque tools. These are described in ISO 6789‑2.
This document does not specify requirements for verifying the performance of hand torque tools. These are described in ISO 6789-3.
Outils de manoeuvre pour vis et écrous - Outils dynamométriques à commande manuelle - Partie 1: Exigences et méthodes d'essai pour vérifier la conformité de conception et la conformité de qualité: exigences minimales pour déclaration de conformité (ISO/DIS 6789-1:2025)
ISO 6789-1:2017 spécifie les exigences d'essai de conformité et de marquage relatives aux outils dynamométriques à commande manuelle utilisés pour le serrage contrôlé de vis et écrous. Elle spécifie également les exigences minimales relatives à la déclaration de conformité des outils dynamométriques à commande manuelle.
ISO 6789-1:2017 s'applique aux outils dynamométriques à commande manuelle classés en tant qu'outils dynamométriques à lecture directe (Type I) et outils dynamométriques à déclenchement (Type II).
NOTE Les outils dynamométriques à commande manuelle couverts par le présent document sont ceux identifiés dans l'ISO 1703:2005 sous les numéros de référence 6 1 00 11 0, 6 1 00 11 1 et 6 1 00 12 0, 6 1 00 12 1 et 6 1 00 14 0, 6 1 00 15 0. L'ISO 1703 est en cours de révision. Dans la prochaine édition, les outils dynamométriques seront traités dans un article distinct, et du fait de cette modification, les numéros de référence changeront également et des numéros de référence supplémentaires seront ajoutés.
